Produkte > ELECTRO-PJP > 2351-IEC-100BC
2351-IEC-100BC
  • 2351-IEC-100BC
  • 2351-IEC-100BC

2351-IEC-100BC ELECTRO-PJP

pVersion=0046&contRep=ZT&docId=005056AB281E1FD096970ADD349C40E1&compId=Datasheet_2350-IEC.pdf?ci_sign=e47efb8c660a51d476c77dc2d69cb01528dbeff2 Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 12A; banana plug 4mm,angular banana plug 4mm; Len: 1m
Type of test accessories: test lead
Current rating: 12A
Test lead configuration: angular banana plug 4mm; banana plug 4mm
Connector variant: insulated
Cable length: 1m
Colour: white
Wire cross-section: 0.75mm2
Conform to the norm: CAT II 1000V; CAT III 1000V; CAT IV 600V; EN 60529; EN 61010-031
Operating temperature: -60...180°C
Contact material: brass
Contact plating: nickel plated
Wire insulation material: silicone
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details 2351-IEC-100BC ELECTRO-PJP

Category: Single Test Leads, Description: Test lead; 12A; banana plug 4mm,angular banana plug 4mm; Len: 1m, Type of test accessories: test lead, Current rating: 12A, Test lead configuration: angular banana plug 4mm; banana plug 4mm, Connector variant: insulated, Cable length: 1m, Colour: white, Wire cross-section: 0.75mm2, Conform to the norm: CAT II 1000V; CAT III 1000V; CAT IV 600V; EN 60529; EN 61010-031, Operating temperature: -60...180°C, Contact material: brass, Contact plating: nickel plated, Wire insulation material: silicone.
