EF50151B2-1B00U-A99 SUNON
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; 4200rpm
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V
Current rating: 54mA
Leads: lead x2
Cable length: 0.305m
Operating temperature: -10...70°C
Power consumption: 0.64W
Current and power consumption tolerance: ±15%
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball bearing
Fan efficiency: 5.94m3/h
Noise level: 34dBA
Rotational rate/speed: 4200rpm
Anzahl je Verpackung: 1 Stücke
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; 4200rpm
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V
Current rating: 54mA
Leads: lead x2
Cable length: 0.305m
Operating temperature: -10...70°C
Power consumption: 0.64W
Current and power consumption tolerance: ±15%
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball bearing
Fan efficiency: 5.94m3/h
Noise level: 34dBA
Rotational rate/speed: 4200rpm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 168 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
6+ | 14.26 EUR |
10+ | 12.91 EUR |
50+ | 12.1 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details EF50151B2-1B00U-A99 SUNON
Category: DC12V Fans, Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; 4200rpm, Supply voltage: 12V DC, Operating voltage: 4.5...13.8V, Current rating: 54mA, Leads: lead x2, Cable length: 0.305m, Operating temperature: -10...70°C, Power consumption: 0.64W, Current and power consumption tolerance: ±15%, Additional functions: autorestart, Kind of fan: blower, Min. insulation resistance: 10MΩ, Enclosure material: thermoplastic, Type of fan: DC, Fan dimensions: 51.6x51.7x15mm, Fan motor: brushless DC, Impeller material: thermoplastic, Flammability rating: UL94V-0, Insulation class: A, Kind of Bearing: ball bearing, Fan efficiency: 5.94m3/h, Noise level: 34dBA, Rotational rate/speed: 4200rpm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote EF50151B2-1B00U-A99 nach Preis ab 12.1 EUR bis 14.26 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
EF50151B2-1B00U-A99 | Hersteller : SUNON |
Category: DC12V Fans Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; 4200rpm Supply voltage: 12V DC Operating voltage: 4.5...13.8V Current rating: 54mA Leads: lead x2 Cable length: 0.305m Operating temperature: -10...70°C Power consumption: 0.64W Current and power consumption tolerance: ±15% Additional functions: autorestart Kind of fan: blower Min. insulation resistance: 10MΩ Enclosure material: thermoplastic Type of fan: DC Fan dimensions: 51.6x51.7x15mm Fan motor: brushless DC Impeller material: thermoplastic Flammability rating: UL94V-0 Insulation class: A Kind of Bearing: ball bearing Fan efficiency: 5.94m3/h Noise level: 34dBA Rotational rate/speed: 4200rpm |
auf Bestellung 168 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||
EF50151B2-1B00U-A99 | Hersteller : Sunon Fans |
Description: Thermal Products Packaging: Bulk Part Status: Active Features: Auto Restart Voltage - Rated: 12VDC Size / Dimension: Rectangular/Rounded - 51.7mm L x 51.6mm H Bearing Type: Ball RPM: 4200 RPM Air Flow: 3.5 CFM (0.098m³/min) Width: 15.00mm Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Blower Noise: 34.0dB(A) Static Pressure: 0.400 in H2O (99.6 Pa) Power (Watts): 650 mW |
Produkt ist nicht verfügbar |
||||||||||
EF50151B2-1B00U-A99 | Hersteller : Sunon | Blowers & Centrifugal Fans Blower, 50x50x15mm, 12VDC, 3.5CFM, 0.4"H2O, Ball, Wire, Auto Restart |
Produkt ist nicht verfügbar |
