Produkte > DANFOSS > FC-051PK37S2E20H3XXCXXXSXXX
FC-051PK37S2E20H3XXCXXXSXXX

FC-051PK37S2E20H3XXCXXXSXXX DANFOSS


VLT-Micro-Drive-FC-51-INS-EN.pdf Hersteller: DANFOSS
Category: One Phase Inverters
Description: Vector inverter; Max motor power: 0.37kW; Usup: 200÷240VAC; IN: 6
Type of module: vector inverter
Max motor power: 0.37kW
Inverter output voltage: 3 x 230V AC
Input 1 properties: current analog
The programming method: keypad; PC
Electrical connection: screw terminals
Protection: anti-overload OPP; short circuit protection SCP
Mounting: for DIN rail mounting; for wall mounting
Operating temperature: 0...50°C
Output frequency: 0...400Hz
Number of inputs: 6
Number of analog inputs: 1
Number of analog outputs: 2
Current rating: 2.2A
Body dimensions: 150x70x148mm
Current output: 0/4mA...20mA
Manufacturer series: VLT Micro Drive FC 51
Supply voltage: 200...240V AC
Voltage output: 0...10V
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar

Produktrezensionen
Produktbewertung abgeben

Technische Details FC-051PK37S2E20H3XXCXXXSXXX DANFOSS

Category: One Phase Inverters, Description: Vector inverter; Max motor power: 0.37kW; Usup: 200÷240VAC; IN: 6, Type of module: vector inverter, Max motor power: 0.37kW, Inverter output voltage: 3 x 230V AC, Input 1 properties: current analog, The programming method: keypad; PC, Electrical connection: screw terminals, Protection: anti-overload OPP; short circuit protection SCP, Mounting: for DIN rail mounting; for wall mounting, Operating temperature: 0...50°C, Output frequency: 0...400Hz, Number of inputs: 6, Number of analog inputs: 1, Number of analog outputs: 2, Current rating: 2.2A, Body dimensions: 150x70x148mm, Current output: 0/4mA...20mA, Manufacturer series: VLT Micro Drive FC 51, Supply voltage: 200...240V AC, Voltage output: 0...10V, Anzahl je Verpackung: 1 Stücke.
