Produkte > H-OLD > GL.96 19MM
GL.96 19MM

GL.96 19MM H-OLD


GL.96.pdf Hersteller: H-OLD
Category: Insulating tapes
Description: Tape: electrical insulating; W: 19mm; L: 50m; Thk: 170um; white; 5%
Colour: white
Length: 50m
Operating temperature: 180°C
Tape application: coils; motor windings; transformers
Tensile strength: 300N/cm
Elongation at rupture: 5%
Tape material: glass cloth
Width: 19mm
Flammability rating: UL510
Resistance to: temperature
Thickness: 0.17mm
Dielectric strength: 2.5kV
Type of tape: electrical insulating
Kind of adhesive: silicone
Adhesion to steel: 2.3N/cm
Tape features: enables labelling; high mechanical strength
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar

Produktrezensionen
Produktbewertung abgeben

Technische Details GL.96 19MM H-OLD

Category: Insulating tapes, Description: Tape: electrical insulating; W: 19mm; L: 50m; Thk: 170um; white; 5%, Colour: white, Length: 50m, Operating temperature: 180°C, Tape application: coils; motor windings; transformers, Tensile strength: 300N/cm, Elongation at rupture: 5%, Tape material: glass cloth, Width: 19mm, Flammability rating: UL510, Resistance to: temperature, Thickness: 0.17mm, Dielectric strength: 2.5kV, Type of tape: electrical insulating, Kind of adhesive: silicone, Adhesion to steel: 2.3N/cm, Tape features: enables labelling; high mechanical strength, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote GL.96 19MM

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis ohne MwSt
GL.96 19MM GL.96 19MM Hersteller : H-OLD GL.96.pdf Category: Insulating tapes
Description: Tape: electrical insulating; W: 19mm; L: 50m; Thk: 170um; white; 5%
Colour: white
Length: 50m
Operating temperature: 180°C
Tape application: coils; motor windings; transformers
Tensile strength: 300N/cm
Elongation at rupture: 5%
Tape material: glass cloth
Width: 19mm
Flammability rating: UL510
Resistance to: temperature
Thickness: 0.17mm
Dielectric strength: 2.5kV
Type of tape: electrical insulating
Kind of adhesive: silicone
Adhesion to steel: 2.3N/cm
Tape features: enables labelling; high mechanical strength
Produkt ist nicht verfügbar
