RY-12W-K FUJITSU
Hersteller: FUJITSU
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/120VAC; PCB
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 120V AC
DC contacts rating @R: 1A / 24V DC
Switched voltage: max. 60V DC; max. 120V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 960Ω
Operate time: 6ms
Body dimensions: 20.2x9.8x12.5mm
Release time: 3ms
Coil power consumption: 150mW
Operating temperature: -30...90°C
Relay series: RY
Contact resistance: 100mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 5mm
Contact plating: gold-plated
Anzahl je Verpackung: 1 Stücke
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/120VAC; PCB
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 120V AC
DC contacts rating @R: 1A / 24V DC
Switched voltage: max. 60V DC; max. 120V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 960Ω
Operate time: 6ms
Body dimensions: 20.2x9.8x12.5mm
Release time: 3ms
Coil power consumption: 150mW
Operating temperature: -30...90°C
Relay series: RY
Contact resistance: 100mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 5mm
Contact plating: gold-plated
Anzahl je Verpackung: 1 Stücke
auf Bestellung 4374 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
33+ | 2.2 EUR |
36+ | 1.99 EUR |
50+ | 1.43 EUR |
53+ | 1.36 EUR |
500+ | 1.32 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details RY-12W-K FUJITSU
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/120VAC; PCB, Type of relay: electromagnetic, Contacts configuration: DPDT, Rated coil voltage: 12V DC, Contact current max.: 1A, AC contacts rating @R: 0.5A / 120V AC, DC contacts rating @R: 1A / 24V DC, Switched voltage: max. 60V DC; max. 120V AC, Relay variant: miniature, Mounting: PCB, Coil resistance: 960Ω, Operate time: 6ms, Body dimensions: 20.2x9.8x12.5mm, Release time: 3ms, Coil power consumption: 150mW, Operating temperature: -30...90°C, Relay series: RY, Contact resistance: 100mΩ, Contact material: AgPd/Au 0,2μm, Terminal pitch: 5mm, Contact plating: gold-plated, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote RY-12W-K nach Preis ab 1.32 EUR bis 9.36 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
RY-12W-K | Hersteller : FUJITSU |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/120VAC; PCB Type of relay: electromagnetic Contacts configuration: DPDT Rated coil voltage: 12V DC Contact current max.: 1A AC contacts rating @R: 0.5A / 120V AC DC contacts rating @R: 1A / 24V DC Switched voltage: max. 60V DC; max. 120V AC Relay variant: miniature Mounting: PCB Coil resistance: 960Ω Operate time: 6ms Body dimensions: 20.2x9.8x12.5mm Release time: 3ms Coil power consumption: 150mW Operating temperature: -30...90°C Relay series: RY Contact resistance: 100mΩ Contact material: AgPd/Au 0,2μm Terminal pitch: 5mm Contact plating: gold-plated |
auf Bestellung 4374 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 2729 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 4480 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 5900 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 3896 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 3896 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : FCL Components | Low Signal Relays - PCB Mini Signal 12VDC |
auf Bestellung 326 Stücke: Lieferzeit 14-28 Tag (e) |
|
|||||||||||||||||
RY-12W-K | Hersteller : Fujitsu | Signal Relay 12VDC 1A DPDT(20.2x9.8x12.5)mm THT |
auf Bestellung 3896 Stücke: Lieferzeit 14-21 Tag (e) |
||||||||||||||||||
RY12W-K | Hersteller : NAIS | 07+ |
auf Bestellung 20000 Stücke: Lieferzeit 21-28 Tag (e) |
