BK9182B B&K PRECISION


pVersion=0046&contRep=ZT&docId=005056AB90B41EDAADEE49D6CA08E0C7&compId=BK9170B.pdf?ci_sign=cd0998819beb1dab0695386f38f1dbc3b7c1449e pVersion=0046&contRep=ZT&docId=005056AB90B41EDB82AA285A9BB220C7&compId=BK9171B.pdf?ci_sign=74b1af0a7974e9091afa705c76277aafe24c3731 Hersteller: B&K PRECISION
Category: Programmable Power Supplies
Description: Power supply: programmable laboratory; Ch: 1; 20VDC; 20A; 200W
Kind of display used: LCD
Supply voltage: 100...240V AC
Output voltage: 20V DC
Output current: 20A
Interface: USB
Number of channels: 1
Maximum power: 200W
Dimensions: 210x130.5x415mm
Standard equipment: fuse; mains cable; manufacturer's calibration certificate; USB cable
Protection: anti-overvoltage OVP; over current OCP
Measuring instrument features: dual range (high and low range operation) for more voltage or more current
Output voltage resolution: 1mV
Output current resolution: 1mA
Kind of power supply: adjustable; programmable; single-channel
Voltage (regulated) ripple and noise: ≤0.35mVrms
Current stabilisation: ≤0.01%+ 250µA
Voltage stabilisation: ≤0.01%+ 1mV
Software: LabVIEW
Type of laboratory power supply: programmable laboratory
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar

Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details BK9182B B&K PRECISION

Category: Programmable Power Supplies, Description: Power supply: programmable laboratory; Ch: 1; 20VDC; 20A; 200W, Kind of display used: LCD, Supply voltage: 100...240V AC, Output voltage: 20V DC, Output current: 20A, Interface: USB, Number of channels: 1, Maximum power: 200W, Dimensions: 210x130.5x415mm, Standard equipment: fuse; mains cable; manufacturer's calibration certificate; USB cable, Protection: anti-overvoltage OVP; over current OCP, Measuring instrument features: dual range (high and low range operation) for more voltage or more current, Output voltage resolution: 1mV, Output current resolution: 1mA, Kind of power supply: adjustable; programmable; single-channel, Voltage (regulated) ripple and noise: ≤0.35mVrms, Current stabilisation: ≤0.01%+ 250µA, Voltage stabilisation: ≤0.01%+ 1mV, Software: LabVIEW, Type of laboratory power supply: programmable laboratory, Anzahl je Verpackung: 1 Stücke.
