GKS-003 305 170 A 2000

GKS-003 305 170 A 2000 INGUN

pVersion=0046&contRep=ZT&docId=005056AB281E1EDD9FF18A65F76A60D3&compId=INGUN_GKS-003-0040_EN.pdf?ci_sign=64e97d14570e7a584122d1ecb76eea7ec1007f10 Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4.4mm; 6.35mm; 8A; CuBe; Ø: 1.7mm
Type of test accessories: test needle
Operational spring compression: 4.4mm
Maksimum spring compression: 6.35mm
Current rating: 8A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.7mm
Blade tip shape: round
Manufacturer series: GKS-003
Max. contact resistance:: 20mΩ
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: magnetic
Related items: KS-00330G
Length: 33.1mm
Spring compression force: 2N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details GKS-003 305 170 A 2000 INGUN

Category: Contact Probes, Description: Test needle; Spring compression: 4.4mm; 6.35mm; 8A; CuBe; Ø: 1.7mm, Type of test accessories: test needle, Operational spring compression: 4.4mm, Maksimum spring compression: 6.35mm, Current rating: 8A, Contact material: CuBe, Contact plating: gold-plated, Tip diameter: 1.7mm, Blade tip shape: round, Manufacturer series: GKS-003, Max. contact resistance:: 20mΩ, Operating temperature: -40...80°C, Mounting: push-in, Test accessories features: magnetic, Related items: KS-00330G, Length: 33.1mm, Spring compression force: 2N.
