Suchergebnisse für "las1gq30-11e/w/24v/s" : 3

Art der Ansicht :
Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
GQ30-L-11E/J/W/24V/S GQ30-L-11E/J/W/24V/S ONPOW pVersion=0046&contRep=ZT&docId=005056AB281E1FD0848BBD1D6F76A0DC&compId=GQ-L.pdf?ci_sign=562fc2b16da293fbdfaccd3939169ccbc1dabeef Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: white
Illumination voltage: 24V
Test voltage: 1.5kV
Leads: for soldering
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø30mm
Body material: stainless steel
Manufacturer series: GQ30-L
Operating temperature: -25...55°C
Dimensions: Ø35x35.5mm
Mechanical impact resistance: IK09
auf Bestellung 20 Stücke:
Lieferzeit 14-21 Tag (e)
5+15.24 EUR
10+13.71 EUR
20+13.34 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
LAS1GQ30-11E/W/24V/S LAS1GQ30-11E/W/24V/S ONPOW Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: white
Illumination voltage: 24V
Test voltage: 1.5kV
Leads: connectors
Leads dimensions: 2.8x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Mechanical durability: 1000000 cycles
Button shape: flat
Mounting hole diameter: Ø30mm
Body colour: silver
Body material: stainless steel
Manufacturer series: LAS1GQ22
Ring shape: rounded
Contact material: silver alloy
Actuator colour: silver
Min. insulation resistance: 1GΩ
Operating temperature: -25...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
GQ30-L-11E/J/W/24V/S pVersion=0046&contRep=ZT&docId=005056AB281E1FD0848BBD1D6F76A0DC&compId=GQ-L.pdf?ci_sign=562fc2b16da293fbdfaccd3939169ccbc1dabeef
GQ30-L-11E/J/W/24V/S
Hersteller: ONPOW
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: white
Illumination voltage: 24V
Test voltage: 1.5kV
Leads: for soldering
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø30mm
Body material: stainless steel
Manufacturer series: GQ30-L
Operating temperature: -25...55°C
Dimensions: Ø35x35.5mm
Mechanical impact resistance: IK09
auf Bestellung 20 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
5+15.24 EUR
10+13.71 EUR
20+13.34 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
LAS1GQ30-11E/W/24V/S
LAS1GQ30-11E/W/24V/S
Hersteller: ONPOW
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: white
Illumination voltage: 24V
Test voltage: 1.5kV
Leads: connectors
Leads dimensions: 2.8x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Mechanical durability: 1000000 cycles
Button shape: flat
Mounting hole diameter: Ø30mm
Body colour: silver
Body material: stainless steel
Manufacturer series: LAS1GQ22
Ring shape: rounded
Contact material: silver alloy
Actuator colour: silver
Min. insulation resistance: 1GΩ
Operating temperature: -25...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
