P 1665 PEAKTECH
Hersteller: PEAKTECHCategory: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 48mm; LCD
Type of meter: multifunction
Kind of meter: digital; pincers type
Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator
Kind of display used: LCD
Display parameters: 3,83 digit (6000)
Max. diameter of measured cable: 48mm
AC current measuring range: 60A; 600A; 1kA
AC current measuring accuracy: ±(2.5% + 8 digit)
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(1.5% + 3 digit)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring accuracy: ±(1.5% + 5 digit)
True effective value measurement: True RMS
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 400µF; 4mF
Capacitance measuring accuracy: ±(3%+ 5 digit)
Frequency measuring range: 0...10MHz
Frequency measuring accuracy: ±(1%+5 digit)
Temperature measuring range: -20...760°C
Temperature measurement accuracy: ±(3% + 5 digit)
Continuity test: acoustic indication; <50Ω
Dimensions: 76x230x40mm
Power supply: battery 6LR61 9V x1
Standard equipment: case; K-type thermocouple; test leads; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Resistance measuring accuracy: ±(1.5%+2 digit)
DC current measuring accuracy: ±(2.5% + 8 digit)
Sampling: 3x/s
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
DC current measuring range: 60A; 600A; 1kA
Diode test: 1mA @3V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 172.67 EUR |
| 3+ | 170.84 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details P 1665 PEAKTECH
Category: Meters and AC/DC Clamp Probes, Description: Meter: multifunction; digital,pincers type; Øcable: 48mm; LCD, Type of meter: multifunction, Kind of meter: digital; pincers type, Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator, Kind of display used: LCD, Display parameters: 3,83 digit (6000), Max. diameter of measured cable: 48mm, AC current measuring range: 60A; 600A; 1kA, AC current measuring accuracy: ±(2.5% + 8 digit), DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV, DC voltage measuring accuracy: ±(1.5% + 3 digit), AC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV, AC voltage measuring accuracy: ±(1.5% + 5 digit), True effective value measurement: True RMS, Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ, Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 400µF; 4mF, Capacitance measuring accuracy: ±(3%+ 5 digit), Frequency measuring range: 0...10MHz, Frequency measuring accuracy: ±(1%+5 digit), Temperature measuring range: -20...760°C, Temperature measurement accuracy: ±(3% + 5 digit), Continuity test: acoustic indication; .
