TSZZ20/015M

TSZZ20/015M INDEL

pVersion=0046&contRep=ZT&docId=005056AB752F1EE384ACF48550ADACAD&compId=54_10.pdf?ci_sign=23717eb4a33560afeb3c2aa41273d76179e387a0 Hersteller: INDEL
Category: PCB transformers
Description: Transformer: encapsulated; 20VA; 230VAC; 7.5V; 2.66A; PCB; IP00
Mounting: PCB
Power: 20VA
Insulation class: II
A dimension: 58.8mm
Conform to the norm: PN EN 61558
Type of transformer: encapsulated
Primary voltage: 230V AC
Primary winding terminals: 1-7
Secondary voltage 1: 7.5V
Secondary winding terminals: 9-13
Secondary winding current 1: 2.66A
Thermal class: Ta40B
A1 dimension: 40.2mm
B1 dimension: 38.6mm
C1 dimension: 33.8mm
D1 dimension: 37.5mm
P dimension: 5mm
M dimension: 30mm
B dimension: 49.8mm
C dimension: 42.2mm
D dimension: 65mm
Electrical insulation strength: 4kV/60s
IP rating: IP00
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
6+13.56 EUR
7+11.24 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details TSZZ20/015M INDEL

Category: PCB transformers, Description: Transformer: encapsulated; 20VA; 230VAC; 7.5V; 2.66A; PCB; IP00, Mounting: PCB, Power: 20VA, Insulation class: II, A dimension: 58.8mm, Conform to the norm: PN EN 61558, Type of transformer: encapsulated, Primary voltage: 230V AC, Primary winding terminals: 1-7, Secondary voltage 1: 7.5V, Secondary winding terminals: 9-13, Secondary winding current 1: 2.66A, Thermal class: Ta40B, A1 dimension: 40.2mm, B1 dimension: 38.6mm, C1 dimension: 33.8mm, D1 dimension: 37.5mm, P dimension: 5mm, M dimension: 30mm, B dimension: 49.8mm, C dimension: 42.2mm, D dimension: 65mm, Electrical insulation strength: 4kV/60s, IP rating: IP00.
