Produkte > UNI-T > UPO1054
UPO1054
  • UPO1054
  • UPO1054
  • UPO1054

UPO1054 UNI-T

pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBB830677F65180D6&compId=UPO1000.pdf?ci_sign=870434eef44c4146bee6e5acc7a1cf5be0c67d0c pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBB830713CBD2A0D6&compId=UPO1000-UM.pdf?ci_sign=5771a693e15ce3db53773e5ff571eaed66e8bb3e Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 50MHz; 2Gsps; 56Mpts; LCD TFT 7"; ≤7ns
Interface: AUX; EXT Trig; LAN; USB device; USB Host
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; video signal; with delay
Kind of display used: LCD TFT 7"
Standard equipment: mains cable; oscilloscope probe; USB cable
Time base: 1n...1ks/div
Rise time: ≤7ns
Dimensions: 306x138x107mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Max. input voltage: 400V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Band: 50MHz
Memory record length: 56Mpts
Sampling: 2Gsps
Input coupling: AC, DC, GND
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+476.25 EUR
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details UPO1054 UNI-T

Category: Digital Oscilloscopes, Description: Oscilloscope: digital; Ch: 4; 50MHz; 2Gsps; 56Mpts; LCD TFT 7"; ≤7ns, Interface: AUX; EXT Trig; LAN; USB device; USB Host, Type of oscilloscope: digital, Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; video signal; with delay, Kind of display used: LCD TFT 7", Standard equipment: mains cable; oscilloscope probe; USB cable, Time base: 1n...1ks/div, Rise time: ≤7ns, Dimensions: 306x138x107mm, Supply voltage: 100...240V AC, Number of channels: 4, Vertical resolution: 8bit, Max. input voltage: 400V, Display resolution: 800x480, Input impedance: 1MΩ/16pF, Band: 50MHz, Memory record length: 56Mpts, Sampling: 2Gsps, Input coupling: AC, DC, GND.
