UPO3252E UNI-T
Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Standard equipment: mains cable; manual (CD); oscilloscope probe; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: I2C; negative-edge-triggered; Nth Edge; positive-edge-triggered; RS232; timeout; window; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Rise time: ≤1.4ns
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Standard equipment: mains cable; manual (CD); oscilloscope probe; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: I2C; negative-edge-triggered; Nth Edge; positive-edge-triggered; RS232; timeout; window; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Rise time: ≤1.4ns
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details UPO3252E UNI-T
Category: Digital Oscilloscopes, Description: Oscilloscope: digital; Ch: 2; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8", Number of channels: 2, Input impedance: 1MΩ/18pF, Dimensions: 370x195x125mm, Standard equipment: mains cable; manual (CD); oscilloscope probe; USB cable, Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function, Sampling: 2,5Gsps, Type of oscilloscope: digital, Trigger: I2C; negative-edge-triggered; Nth Edge; positive-edge-triggered; RS232; timeout; window; with delay, Input coupling: AC, DC, GND, Vertical resolution: 8bit, Band: 250MHz, Rise time: ≤1.4ns, Input sensitivity: 1mV/div...20V/div, Time base: 2n...40s/div, Memory record length: 70Mpts, Kind of display used: LCD TFT 8", Supply voltage: 100...240V AC, Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA, Display resolution: 800x480.
