Produkte > SCHÜTZINGER > VSFK 8700 / 1 / 150 / GNGE
VSFK 8700 / 1 / 150 / GNGE

VSFK 8700 / 1 / 150 / GNGE SCHÜTZINGER


pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8993AC5CFA0780D5&compId=VSFK87001100-OR.pdf?ci_sign=8e1fb1e87986667ef03c9ffa75c64ceb3875b870 Hersteller: SCHÜTZINGER
Category: Single Test Leads
Description: Test lead; 16A; banana plug 4mm,both sides; Urated: 1kV; Len: 1.5m
Type of test accessories: test lead
Current rating: 16A
Test lead configuration: banana plug 4mm; both sides
Connector variant: insulated; with 4mm axial socket
Rated voltage: 1kV
Cable length: 1.5m
Colour: yellow-green
Wire cross-section: 1mm2
Conform to the norm: CAT III 1000V; EN 61010
Operating temperature: -10...70°C
Max. contact resistance:: 25mΩ
Contact plating: nickel plated
Wire insulation material: PVC
Produkt ist nicht verfügbar

Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details VSFK 8700 / 1 / 150 / GNGE SCHÜTZINGER

Category: Single Test Leads, Description: Test lead; 16A; banana plug 4mm,both sides; Urated: 1kV; Len: 1.5m, Type of test accessories: test lead, Current rating: 16A, Test lead configuration: banana plug 4mm; both sides, Connector variant: insulated; with 4mm axial socket, Rated voltage: 1kV, Cable length: 1.5m, Colour: yellow-green, Wire cross-section: 1mm2, Conform to the norm: CAT III 1000V; EN 61010, Operating temperature: -10...70°C, Max. contact resistance:: 25mΩ, Contact plating: nickel plated, Wire insulation material: PVC.
