TEP 40-3611UIR TEP 40-3611UIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB69513CCE56A20C7&compId=tep40uir_datasheet.pdf?ci_sign=52d48e8c45efe0d46857f66a437bada0fb52db64 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷75VDC; Uout: 5VDC; Iout: 8A; PCB; TEP 40
Type of converter: DC/DC
Power: 40W
Input voltage: 9...75V DC
Output voltage: 5V DC
Output current: 8A
Case: Quarter Brick
Mounting: PCB
Manufacturer series: TEP 40
Body dimensions: 57.9x36.8x12.7mm
Efficiency: 89%
Operating temperature: -40...85°C
Switching frequency: 180kHz
Protection: short circuit protection SCP
Insulation voltage: 3kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 160-2412WIRCM TEP 160-2412WIRCM TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE6BB0EC1FF20C4&compId=tep160wir-datasheet.pdf?ci_sign=609f4bccf0be89cc961705f823f4b36a0772a806 Category: DC/DC Converters
Description: Converter: DC/DC; 160W; Uin: 9÷36VDC; Uout: 12VDC; Iout: 12A; 250kHz
Type of converter: DC/DC
Power: 160W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output current: 12A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 160WIR
Body dimensions: 61x57.9x12.7mm
Efficiency: 88...92%
Operating temperature: -40...75°C
Switching frequency: 250kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TPP 450-115B-M TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB98C246D2729320C7&compId=TPP450B-M-DTE.pdf?ci_sign=422ad5dc87813e38632d0da47e6b10a64ec619c5 Category: Built-in Power Supplies
Description: Power supply: switching; for building in,modular; 450W; 15VDC
Supply voltage: 85...264V AC; 120...370V DC
Operating temperature: -40...80°C
Electrical connection: connector with snap lock
Kind of power supply: for building in; modular
Manufacturer series: TPP 450B-M
Caution!: rated parameters obtained at full load
Type of power supply: switching
Body dimensions: 148.2x80x40.6mm
Output current: 30A
Power consumption without load: <0.5W
Number of outputs: 1
Output voltage: 15V DC
Efficiency: 92%
Power: 450W
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Application: medical applications
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TPP 450-115BA-M TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB98C242B795D100C7&compId=TPP450BA-M-DTE.pdf?ci_sign=3123e429bb46cfa51e3b5dfcfbb197167e306670 Category: Built-in Power Supplies
Description: Power supply: switching; for building in,modular; 450W; 15VDC
Supply voltage: 85...264V AC; 120...370V DC
Operating temperature: -40...80°C
Electrical connection: connector with snap lock
Kind of power supply: for building in; modular
Manufacturer series: TPP 450BA-M
Caution!: rated parameters obtained at full load
Type of power supply: switching
Body dimensions: 127x76.2x40.1mm
Output current: 30A
Power consumption without load: <0.5W
Number of outputs: 1
Output voltage: 15V DC
Efficiency: 92%
Power: 450W
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Application: medical applications
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TSH 0505D TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9D9B8FE1E9D5C0C4&compId=tsh_datasheet.pdf?ci_sign=061481c0c6ee12d697754189f20c2826b8652e12 Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 4.5÷5.5VDC; Uout: 5VDC; Uout2: -5VDC; SMD
Type of converter: DC/DC
Power: 2W
Input voltage: 4.5...5.5V DC
Output voltage: 5V DC
Output current: 0.2A
Case: SMD
Mounting: PCB
Manufacturer series: TSH
Body dimensions: 15.3x9.3x8.9mm
Efficiency: 77%
Operating temperature: -40...85°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1kV
Number of outputs: 2
Output voltage 2: -5V DC
Output current 2: 0.2A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TSH 0505S TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9D9B8FE1E9D5C0C4&compId=tsh_datasheet.pdf?ci_sign=061481c0c6ee12d697754189f20c2826b8652e12 Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 4.5÷5.5VDC; Uout: 5VDC; Iout: 400mA; SMD
Type of converter: DC/DC
Power: 2W
Input voltage: 4.5...5.5V DC
Output voltage: 5V DC
Output current: 0.4A
Case: SMD
Mounting: PCB
Manufacturer series: TSH
Body dimensions: 12.7x9.3x8.9mm
Efficiency: 77%
Operating temperature: -40...85°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4811 TEN 12-4811 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACC3A5C1CDE2745&compId=ten12wi-datasheet.pdf?ci_sign=bf791a4cdfe5e7f2691a769db3acb12677040224 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 5VDC; Iout: 2000mA; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 5V DC
Output current: 2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 82%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4822WI THD 12-4822WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.5A
Output current 2: 0.5A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4812WI THD 12-4812WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMR 12-4813WI TMR 12-4813WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB281E1FD09B8CE42653EAA0E1&compId=TMR12WI.pdf?ci_sign=9db751c97267e80bfe6d80ed3b079226f009fda7 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; SIP8
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: SIP8
Mounting: THT
Manufacturer series: TMR 12
Body dimensions: 22x9.6x12mm
Efficiency: 89%
Operating temperature: -40...85°C
Switching frequency: 460kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4812 THD 12-4812 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CFF239AE6FB00C4&compId=thd12_datasheet.pdf?ci_sign=fd1098505c16b69eefa67dea009b1a9f04ab157a Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4822WI TEL 12-4822WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07A8AE559C0C7&compId=TEL12WI-DTE.pdf?ci_sign=e184e8fbc2018ddfacd9606c09704a496e3b6863 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.5A
Output current 2: 0.5A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12WI
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4823WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.4A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -15V DC
Output current 2: 0.4A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4813WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; DIP24
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4812 TEL 12-4812 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07409C43A40C7&compId=TEL12-DTE.pdf?ci_sign=39f0cb36c2064729aa48c0a9dcaf38aaf81b261e Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4812WI TEL 12-4812WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07A8AE559C0C7&compId=TEL12WI-DTE.pdf?ci_sign=e184e8fbc2018ddfacd9606c09704a496e3b6863 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12WI
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4823 TEL 12-4823 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07409C43A40C7&compId=TEL12-DTE.pdf?ci_sign=39f0cb36c2064729aa48c0a9dcaf38aaf81b261e Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 15V DC
Output current: 0.4A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -15V DC
Output current 2: 0.4A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4810 TRACO POWER pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 3.3VDC; Iout: 2400mA
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 3.3V DC
Output current: 2.4A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 78%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4813 TRACO POWER pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 84%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4821 TRACO POWER pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8 Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 5VDC; Uout2: -5VDC; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 5V DC
Output current: 1A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 82%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -5V DC
Output current 2: 1A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4811E TEN 40-4811E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
1+71.5 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423WI TEN 40-2423WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; PCB
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.35A
Output current 2: 1.35A
Case: 2"x2"
Mounting: PCB
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 86%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
auf Bestellung 17 Stücke:
Lieferzeit 14-21 Tag (e)
1+126.08 EUR
5+120.86 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422WIE TEN 40-2422WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 12VDC; Uout2: -12VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 5 Stücke:
Lieferzeit 14-21 Tag (e)
1+72.13 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422E TEN 40-2422E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 6 Stücke:
Lieferzeit 14-21 Tag (e)
2+58.32 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2410E TEN 40-2410E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 3.3VDC; Iout: 12200mA
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 3.3V DC
Output current: 12.2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
2+58.32 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4810E TEN 40-4810E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 3.3VDC; Iout: 12200mA
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 3.3V DC
Output current: 12.2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
2+59.1 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4822E TEN 40-4822E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
2+59.86 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4813WIE TEN 40-4813WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 2666mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 2666mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
2+69.58 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812E TEN 40-4812E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812N TEN 40-4812N TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5254F3E6100C4&compId=ten40n-datasheet.pdf?ci_sign=ba8086412386ce3d50f7900fa678d7c58c3ad2d8 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 3330mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 3.33A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40N
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...80°C
Switching frequency: 320kHz
Protection: anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIE TEN 40-4812WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2425WIE TEN 40-2425WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Uout2: -24VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output voltage 2: -24V DC
Output current: 0.833A
Output current 2: 833mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2413WIE TEN 40-2413WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Iout: 2666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output current: 2666mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 93%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2413WI TEN 40-2413WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Iout: 2650mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output current: 2.65A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415E TEN 40-2415E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 24VDC; Iout: 1666mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WIE TEN 40-2411WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4815WIR TEN 40-4815WIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 24VDC; Iout: 1666mA; PCB
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: PCB
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415WIE TEN 40-2415WIE TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Iout: 1666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423E TEN 40-2423E TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.333A
Output current 2: 1333mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 12VDC; Uout2: -12VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.65A
Output current 2: 1.65A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 86%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415WIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Iout: 1666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIN TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE53A737676E0C4&compId=ten40win-datasheet.pdf?ci_sign=a33d0a97c57333d3ac16eed0e368bef829ae73a1 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3330mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.33A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...75°C
Switching frequency: 320kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423WIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.333A
Output current 2: 1333mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE44AD29DFC40C4&compId=ten40-datasheet.pdf?ci_sign=4bb8a68f35643f244a6beb5b0e45055b02e986a2 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 89%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WIR TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849 Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMPS 10-109 TMPS 10-109 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BDF9825D160EE143&compId=tmps10-datasheet.pdf?ci_sign=57deaef7954706e311943bddeab2088825111ef8 Category: PCB AC/DC converters
Description: Converter: AC/DC; 10W; Uin: 85÷264VAC,120÷370VDC; Uout: 9VDC; 83%
Type of converter: AC/DC
Power: 10W
Input voltage: 85...264V AC; 120...370V DC
Output voltage: 9V DC
Output current: 1.1A
Efficiency: 83%
Manufacturer series: TMPS
Body dimensions: 38.1x25.4x15.74mm
Mounting: PCB
Insulation voltage: 4kV
Operating temperature: -25...70°C
Protection: anti-overvoltage OVP; short circuit protection SCP
auf Bestellung 9 Stücke:
Lieferzeit 14-21 Tag (e)
3+31.99 EUR
5+30.24 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
TMPS 03-109 TMPS 03-109 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACE2C40C0470745&compId=tmps03-datasheet.pdf?ci_sign=37b86bd010ab5cb435bd0674a856f0ad3e18627f Category: PCB AC/DC converters
Description: Converter: AC/DC; 3W; Uin: 85÷264VAC,120÷370VDC; Uout: 9VDC; 77%
Type of converter: AC/DC
Power: 3W
Input voltage: 85...264V AC; 120...370V DC
Output voltage: 9V DC
Output current: 0.333A
Efficiency: 77%
Manufacturer series: TMPS
Body dimensions: 25.4x25.4x16.3mm
Mounting: PCB
Insulation voltage: 4.2kV
Operating temperature: -25...70°C
Protection: anti-overload OPP; short circuit protection SCP
auf Bestellung 16 Stücke:
Lieferzeit 14-21 Tag (e)
4+20.78 EUR
5+19.63 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15215C TMP 15215C TRACO POWER tmp.pdf Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 15VDC; 500mA; 79%
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: -15V DC
Output current: 0.5A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.5A
Output voltage: 15V DC
Efficiency: 79%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
2+50.58 EUR
10+50.45 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15212C TRACO POWER tmp.pdf Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 12VDC; 650mA; 79%
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: -12V DC
Output current: 0.65A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.65A
Output voltage: 12V DC
Efficiency: 79%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15212 TRACO POWER tmp.pdf Category: PCB AC/DC converters
Description: Converter: AC/DC; 15W; Uin: 85÷264VAC,120÷370VDC; Uout: 12VDC; 79%
Mounting: PCB
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Output voltage 2: -12V DC
Output current: 0.65A
Body dimensions: 74x54x19.5mm
Power: 15W
Output current 2: 0.65A
Output voltage: 12V DC
Input voltage: 85...264V AC; 120...370V DC
Efficiency: 79%
Insulation voltage: 3kV
Type of converter: AC/DC
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15215 TRACO POWER tmp.pdf Category: PCB AC/DC converters
Description: Converter: AC/DC; 15W; Uin: 85÷264VAC,120÷370VDC; Uout: 15VDC; 79%
Mounting: PCB
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Output voltage 2: -15V DC
Output current: 0.5A
Body dimensions: 74x54x19.5mm
Power: 15W
Output current 2: 0.5A
Output voltage: 15V DC
Input voltage: 85...264V AC; 120...370V DC
Efficiency: 79%
Insulation voltage: 3kV
Type of converter: AC/DC
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15252C TRACO POWER tmp.pdf Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 5VDC; 1.5A; TMP 15
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: 12V DC
Output current: 1.5A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.625A
Output voltage: 5V DC
Efficiency: 72%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TDN 5-4813WI TDN 5-4813WI TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CCD4FBB5E5100C4&compId=tdn5wi-datasheet.pdf?ci_sign=5c68ce749642182b287fe987125b4b334d8a10cb Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 333mA; DIP
Type of converter: DC/DC
Power: 5W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.333A
Case: DIP
Mounting: THT
Manufacturer series: TDN5
Body dimensions: 13.2x9.1x10.2mm
Efficiency: 83%
Operating temperature: -40...75°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 9 Stücke:
Lieferzeit 14-21 Tag (e)
3+32.78 EUR
5+31.17 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
TES5-4823WI TES5-4823WI TRACO POWER Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷75VDC; Uout: 15VDC; Uout2: -15VDC; SMT
Type of converter: DC/DC
Power: 5W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 165mA
Output current 2: 165mA
Mounting: SMT
Efficiency: 83%
Operating temperature: -40...71°C
Switching frequency: 340kHz
Insulation voltage: 1.5kV
Number of outputs: 2
auf Bestellung 8 Stücke:
Lieferzeit 14-21 Tag (e)
8+28.81 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
TCK-092 TCK-092 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9FF80C21A6BB40C4&compId=tck-092.pdf?ci_sign=3a371ea330bfb947ce166570239de708c7a4678b Category: Inductors
Description: Inductor: wire; THT; 45uH; 1.4mΩ; ±35%; 16x16.2x12.5mm; 31.4A
Type of inductor: wire
Mounting: THT
Inductance: 45µH
Resistance: 1.4mΩ
Tolerance: ±35%
Dimensions: 16x16.2x12.5mm
Max. operating current: 31.4A
Max. voltage: 500V DC
Operating temperature: -40...105°C
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
7+10.21 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211-CM TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14 Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; on panel
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211 TEP 100-1211 TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14 Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; PCB
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: PCB
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211-CMF TRACO POWER pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14 Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; on panel
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 40-3611UIR pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB69513CCE56A20C7&compId=tep40uir_datasheet.pdf?ci_sign=52d48e8c45efe0d46857f66a437bada0fb52db64
TEP 40-3611UIR
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷75VDC; Uout: 5VDC; Iout: 8A; PCB; TEP 40
Type of converter: DC/DC
Power: 40W
Input voltage: 9...75V DC
Output voltage: 5V DC
Output current: 8A
Case: Quarter Brick
Mounting: PCB
Manufacturer series: TEP 40
Body dimensions: 57.9x36.8x12.7mm
Efficiency: 89%
Operating temperature: -40...85°C
Switching frequency: 180kHz
Protection: short circuit protection SCP
Insulation voltage: 3kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 160-2412WIRCM pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE6BB0EC1FF20C4&compId=tep160wir-datasheet.pdf?ci_sign=609f4bccf0be89cc961705f823f4b36a0772a806
TEP 160-2412WIRCM
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 160W; Uin: 9÷36VDC; Uout: 12VDC; Iout: 12A; 250kHz
Type of converter: DC/DC
Power: 160W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output current: 12A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 160WIR
Body dimensions: 61x57.9x12.7mm
Efficiency: 88...92%
Operating temperature: -40...75°C
Switching frequency: 250kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TPP 450-115B-M pVersion=0046&contRep=ZT&docId=005056AB90B41EDB98C246D2729320C7&compId=TPP450B-M-DTE.pdf?ci_sign=422ad5dc87813e38632d0da47e6b10a64ec619c5
Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in,modular; 450W; 15VDC
Supply voltage: 85...264V AC; 120...370V DC
Operating temperature: -40...80°C
Electrical connection: connector with snap lock
Kind of power supply: for building in; modular
Manufacturer series: TPP 450B-M
Caution!: rated parameters obtained at full load
Type of power supply: switching
Body dimensions: 148.2x80x40.6mm
Output current: 30A
Power consumption without load: <0.5W
Number of outputs: 1
Output voltage: 15V DC
Efficiency: 92%
Power: 450W
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Application: medical applications
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TPP 450-115BA-M pVersion=0046&contRep=ZT&docId=005056AB90B41EDB98C242B795D100C7&compId=TPP450BA-M-DTE.pdf?ci_sign=3123e429bb46cfa51e3b5dfcfbb197167e306670
Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in,modular; 450W; 15VDC
Supply voltage: 85...264V AC; 120...370V DC
Operating temperature: -40...80°C
Electrical connection: connector with snap lock
Kind of power supply: for building in; modular
Manufacturer series: TPP 450BA-M
Caution!: rated parameters obtained at full load
Type of power supply: switching
Body dimensions: 127x76.2x40.1mm
Output current: 30A
Power consumption without load: <0.5W
Number of outputs: 1
Output voltage: 15V DC
Efficiency: 92%
Power: 450W
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Application: medical applications
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TSH 0505D pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9D9B8FE1E9D5C0C4&compId=tsh_datasheet.pdf?ci_sign=061481c0c6ee12d697754189f20c2826b8652e12
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 4.5÷5.5VDC; Uout: 5VDC; Uout2: -5VDC; SMD
Type of converter: DC/DC
Power: 2W
Input voltage: 4.5...5.5V DC
Output voltage: 5V DC
Output current: 0.2A
Case: SMD
Mounting: PCB
Manufacturer series: TSH
Body dimensions: 15.3x9.3x8.9mm
Efficiency: 77%
Operating temperature: -40...85°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1kV
Number of outputs: 2
Output voltage 2: -5V DC
Output current 2: 0.2A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TSH 0505S pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9D9B8FE1E9D5C0C4&compId=tsh_datasheet.pdf?ci_sign=061481c0c6ee12d697754189f20c2826b8652e12
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 4.5÷5.5VDC; Uout: 5VDC; Iout: 400mA; SMD
Type of converter: DC/DC
Power: 2W
Input voltage: 4.5...5.5V DC
Output voltage: 5V DC
Output current: 0.4A
Case: SMD
Mounting: PCB
Manufacturer series: TSH
Body dimensions: 12.7x9.3x8.9mm
Efficiency: 77%
Operating temperature: -40...85°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4811 pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACC3A5C1CDE2745&compId=ten12wi-datasheet.pdf?ci_sign=bf791a4cdfe5e7f2691a769db3acb12677040224
TEN 12-4811
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 5VDC; Iout: 2000mA; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 5V DC
Output current: 2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 82%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4822WI pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7
THD 12-4822WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.5A
Output current 2: 0.5A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4812WI pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7
THD 12-4812WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMR 12-4813WI pVersion=0046&contRep=ZT&docId=005056AB281E1FD09B8CE42653EAA0E1&compId=TMR12WI.pdf?ci_sign=9db751c97267e80bfe6d80ed3b079226f009fda7
TMR 12-4813WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; SIP8
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: SIP8
Mounting: THT
Manufacturer series: TMR 12
Body dimensions: 22x9.6x12mm
Efficiency: 89%
Operating temperature: -40...85°C
Switching frequency: 460kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4812 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CFF239AE6FB00C4&compId=thd12_datasheet.pdf?ci_sign=fd1098505c16b69eefa67dea009b1a9f04ab157a
THD 12-4812
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4822WI pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07A8AE559C0C7&compId=TEL12WI-DTE.pdf?ci_sign=e184e8fbc2018ddfacd9606c09704a496e3b6863
TEL 12-4822WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.5A
Output current 2: 0.5A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12WI
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4823WI pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.4A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -15V DC
Output current 2: 0.4A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
THD 12-4813WI pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACCD12793754745&compId=thd12wi-datasheet.pdf?ci_sign=1a34d812bde87d128ec0449e8d7ad1eb4330c7d7
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; DIP24
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: DIP24
Mounting: THT
Manufacturer series: THD 12WI
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 85%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4812 pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07409C43A40C7&compId=TEL12-DTE.pdf?ci_sign=39f0cb36c2064729aa48c0a9dcaf38aaf81b261e
TEL 12-4812
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4812WI pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07A8AE559C0C7&compId=TEL12WI-DTE.pdf?ci_sign=e184e8fbc2018ddfacd9606c09704a496e3b6863
TEL 12-4812WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 1000mA; THT
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 1A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12WI
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEL 12-4823 pVersion=0046&contRep=ZT&docId=005056AB90B41EDB99C07409C43A40C7&compId=TEL12-DTE.pdf?ci_sign=39f0cb36c2064729aa48c0a9dcaf38aaf81b261e
TEL 12-4823
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 36÷75VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 12W
Input voltage: 36...75V DC
Output voltage: 15V DC
Output current: 0.4A
Case: DIP16
Mounting: THT
Manufacturer series: TEL 12
Body dimensions: 23.8x10.2x13.7mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 480kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -15V DC
Output current 2: 0.4A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4810 pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 3.3VDC; Iout: 2400mA
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 3.3V DC
Output current: 2.4A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 78%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4813 pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 800mA; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 84%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 12-4821 pVersion=0046&contRep=ZT&docId=E1C05A674D0D42F1A6F5005056AB5A8F&compId=ten12wi.pdf?ci_sign=a26ffbb48fa97c15a2a676230e93dcdf1c77fff8
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 12W; Uin: 18÷75VDC; Uout: 5VDC; Uout2: -5VDC; 2"x1"
Type of converter: DC/DC
Power: 12W
Input voltage: 18...75V DC
Output voltage: 5V DC
Output current: 1A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 82%
Operating temperature: -40...85°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
Output voltage 2: -5V DC
Output current 2: 1A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4811E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-4811E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+71.5 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423WI pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe
TEN 40-2423WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; PCB
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.35A
Output current 2: 1.35A
Case: 2"x2"
Mounting: PCB
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 86%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 2
auf Bestellung 17 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+126.08 EUR
5+120.86 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-2422WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 12VDC; Uout2: -12VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 5 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+72.13 EUR
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-2422E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 6 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+58.32 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2410E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-2410E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 3.3VDC; Iout: 12200mA
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 3.3V DC
Output current: 12.2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+58.32 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4810E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-4810E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 3.3VDC; Iout: 12200mA
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 3.3V DC
Output current: 12.2A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+59.1 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4822E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-4822E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.666A
Output current 2: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+59.86 EUR
10+57.94 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4813WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-4813WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 2666mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 2666mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+69.58 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-4812E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 38÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 38...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812N pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5254F3E6100C4&compId=ten40n-datasheet.pdf?ci_sign=ba8086412386ce3d50f7900fa678d7c58c3ad2d8
TEN 40-4812N
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 36÷75VDC; Uout: 12VDC; Iout: 3330mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 36...75V DC
Output voltage: 12V DC
Output current: 3.33A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40N
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...80°C
Switching frequency: 320kHz
Protection: anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-4812WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2425WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-2425WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Uout2: -24VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output voltage 2: -24V DC
Output current: 0.833A
Output current 2: 833mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2413WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-2413WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Iout: 2666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output current: 2666mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 93%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2413WI pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe
TEN 40-2413WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Iout: 2650mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output current: 2.65A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-2415E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 24VDC; Iout: 1666mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-2411WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4815WIR pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849
TEN 40-4815WIR
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 24VDC; Iout: 1666mA; PCB
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: PCB
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415WIE pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5F81E0ACE2C40C7&compId=ten40wie_datasheet.pdf?ci_sign=da902ee8141d1fce7c5824aca9fa0270ccf7c66a
TEN 40-2415WIE
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Iout: 1666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIE
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423E pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB5DDCEC0746EC0C7&compId=ten40e_datasheet.pdf?ci_sign=2c010efe533fbef1a61c3632fef4a4becc1dbfe1
TEN 40-2423E
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 15VDC; Uout2: -15VDC
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.333A
Output current 2: 1333mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40E
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2422WI pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 12VDC; Uout2: -12VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 1.65A
Output current 2: 1.65A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 86%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2415WIR pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 24VDC; Iout: 1666mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 24V DC
Output current: 1.666A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIR pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3333mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.333A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 92%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-4812WIN pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE53A737676E0C4&compId=ten40win-datasheet.pdf?ci_sign=a33d0a97c57333d3ac16eed0e368bef829ae73a1
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 3330mA; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 3.33A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIN
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...75°C
Switching frequency: 320kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2423WIR pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; THT
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 1.333A
Output current 2: 1333mA
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 90%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE44AD29DFC40C4&compId=ten40-datasheet.pdf?ci_sign=4bb8a68f35643f244a6beb5b0e45055b02e986a2
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 18÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 18...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 89%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 1.5kV
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WIR pVersion=0046&contRep=ZT&docId=005056AB752F1EE88DFB50B0E07953D1&compId=ten40wir.pdf?ci_sign=a4aaef555d52c7620b78182c14a27ca0ce36c849
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x1"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x1"
Mounting: THT
Manufacturer series: TEN 40WIR
Body dimensions: 50.8x25.4x10.2mm
Efficiency: 91%
Operating temperature: -40...85°C
Switching frequency: 250kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
Conform to the norm: EN 50155
Application: railway industry
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEN 40-2411WI pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BA95631DC4418143&compId=ten40wi-datasheet.pdf?ci_sign=8f524efadf3a86142280a42f9e74d7153a00debe
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 40W; Uin: 9÷36VDC; Uout: 5VDC; Iout: 8000mA; 2"x2"
Type of converter: DC/DC
Power: 40W
Input voltage: 9...36V DC
Output voltage: 5V DC
Output current: 8A
Case: 2"x2"
Mounting: THT
Manufacturer series: TEN 40WI
Body dimensions: 50.8x50.8x10.2mm
Efficiency: 87%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMPS 10-109 pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BDF9825D160EE143&compId=tmps10-datasheet.pdf?ci_sign=57deaef7954706e311943bddeab2088825111ef8
TMPS 10-109
Hersteller: TRACO POWER
Category: PCB AC/DC converters
Description: Converter: AC/DC; 10W; Uin: 85÷264VAC,120÷370VDC; Uout: 9VDC; 83%
Type of converter: AC/DC
Power: 10W
Input voltage: 85...264V AC; 120...370V DC
Output voltage: 9V DC
Output current: 1.1A
Efficiency: 83%
Manufacturer series: TMPS
Body dimensions: 38.1x25.4x15.74mm
Mounting: PCB
Insulation voltage: 4kV
Operating temperature: -25...70°C
Protection: anti-overvoltage OVP; short circuit protection SCP
auf Bestellung 9 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+31.99 EUR
5+30.24 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
TMPS 03-109 pVersion=0046&contRep=ZT&docId=005056AB752F1EE78ACE2C40C0470745&compId=tmps03-datasheet.pdf?ci_sign=37b86bd010ab5cb435bd0674a856f0ad3e18627f
TMPS 03-109
Hersteller: TRACO POWER
Category: PCB AC/DC converters
Description: Converter: AC/DC; 3W; Uin: 85÷264VAC,120÷370VDC; Uout: 9VDC; 77%
Type of converter: AC/DC
Power: 3W
Input voltage: 85...264V AC; 120...370V DC
Output voltage: 9V DC
Output current: 0.333A
Efficiency: 77%
Manufacturer series: TMPS
Body dimensions: 25.4x25.4x16.3mm
Mounting: PCB
Insulation voltage: 4.2kV
Operating temperature: -25...70°C
Protection: anti-overload OPP; short circuit protection SCP
auf Bestellung 16 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
4+20.78 EUR
5+19.63 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15215C tmp.pdf
TMP 15215C
Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 15VDC; 500mA; 79%
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: -15V DC
Output current: 0.5A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.5A
Output voltage: 15V DC
Efficiency: 79%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+50.58 EUR
10+50.45 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15212C tmp.pdf
Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 12VDC; 650mA; 79%
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: -12V DC
Output current: 0.65A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.65A
Output voltage: 12V DC
Efficiency: 79%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15212 tmp.pdf
Hersteller: TRACO POWER
Category: PCB AC/DC converters
Description: Converter: AC/DC; 15W; Uin: 85÷264VAC,120÷370VDC; Uout: 12VDC; 79%
Mounting: PCB
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Output voltage 2: -12V DC
Output current: 0.65A
Body dimensions: 74x54x19.5mm
Power: 15W
Output current 2: 0.65A
Output voltage: 12V DC
Input voltage: 85...264V AC; 120...370V DC
Efficiency: 79%
Insulation voltage: 3kV
Type of converter: AC/DC
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15215 tmp.pdf
Hersteller: TRACO POWER
Category: PCB AC/DC converters
Description: Converter: AC/DC; 15W; Uin: 85÷264VAC,120÷370VDC; Uout: 15VDC; 79%
Mounting: PCB
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Output voltage 2: -15V DC
Output current: 0.5A
Body dimensions: 74x54x19.5mm
Power: 15W
Output current 2: 0.5A
Output voltage: 15V DC
Input voltage: 85...264V AC; 120...370V DC
Efficiency: 79%
Insulation voltage: 3kV
Type of converter: AC/DC
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TMP 15252C tmp.pdf
Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 15W; 5VDC; 1.5A; TMP 15
Mounting: on panel
Operating temperature: -25...70°C
Manufacturer series: TMP 15
Type of power supply: switching
Output voltage 2: 12V DC
Output current: 1.5A
Body dimensions: 96x54x23.3mm
Power: 15W
Output current 2: 0.625A
Output voltage: 5V DC
Efficiency: 72%
Supply voltage: 85...264V AC; 120...370V DC
Insulation voltage: 3kV
Kind of power supply: for building in
Protection: anti-overload OPP; anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TDN 5-4813WI pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CCD4FBB5E5100C4&compId=tdn5wi-datasheet.pdf?ci_sign=5c68ce749642182b287fe987125b4b334d8a10cb
TDN 5-4813WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷75VDC; Uout: 15VDC; Iout: 333mA; DIP
Type of converter: DC/DC
Power: 5W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output current: 0.333A
Case: DIP
Mounting: THT
Manufacturer series: TDN5
Body dimensions: 13.2x9.1x10.2mm
Efficiency: 83%
Operating temperature: -40...75°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 1
auf Bestellung 9 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+32.78 EUR
5+31.17 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
TES5-4823WI
TES5-4823WI
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷75VDC; Uout: 15VDC; Uout2: -15VDC; SMT
Type of converter: DC/DC
Power: 5W
Input voltage: 18...75V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 165mA
Output current 2: 165mA
Mounting: SMT
Efficiency: 83%
Operating temperature: -40...71°C
Switching frequency: 340kHz
Insulation voltage: 1.5kV
Number of outputs: 2
auf Bestellung 8 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
8+28.81 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
TCK-092 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9FF80C21A6BB40C4&compId=tck-092.pdf?ci_sign=3a371ea330bfb947ce166570239de708c7a4678b
TCK-092
Hersteller: TRACO POWER
Category: Inductors
Description: Inductor: wire; THT; 45uH; 1.4mΩ; ±35%; 16x16.2x12.5mm; 31.4A
Type of inductor: wire
Mounting: THT
Inductance: 45µH
Resistance: 1.4mΩ
Tolerance: ±35%
Dimensions: 16x16.2x12.5mm
Max. operating current: 31.4A
Max. voltage: 500V DC
Operating temperature: -40...105°C
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
7+10.21 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211-CM pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; on panel
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14
TEP 100-1211
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; PCB
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: PCB
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TEP 100-1211-CMF pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9CE5F503F975A0C4&compId=tep100-datasheet.pdf?ci_sign=1c841d0ab14e19ecc2177809518742393c79fc14
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 100W; Uin: 9÷18VDC; Uout: 5VDC; Iout: 20A; on panel
Type of converter: DC/DC
Power: 0.1kW
Input voltage: 9...18V DC
Output voltage: 5V DC
Output current: 20A
Case: Half Brick
Mounting: on panel
Manufacturer series: TEP 100
Body dimensions: 61x57.9x12.7mm
Efficiency: 87...92%
Operating temperature: -40...75°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1591V
Number of outputs: 1
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 41 82 123 164 205 246 287 328 369 410 411 412 413 414 415 416 417 418  [ Nächste Seite >> ]
