PFE0514B1-000U-A99 SUNON
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 140x140x51mm; 425.25m3/h; 61.4dBA; Len: 310mm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V
Fan dimensions: 140x140x51mm
Power consumption: 22.56W
Current rating: 0.47A
Fan efficiency: 425.25m3/h
Noise level: 61.4dBA
Kind of Bearing: ball bearing
Rotational rate/speed: 5000 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x2
Operating temperature: -10...70°C
Cable length: 0.31m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 36.3mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 140x140x51mm; 425.25m3/h; 61.4dBA; Len: 310mm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V
Fan dimensions: 140x140x51mm
Power consumption: 22.56W
Current rating: 0.47A
Fan efficiency: 425.25m3/h
Noise level: 61.4dBA
Kind of Bearing: ball bearing
Rotational rate/speed: 5000 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x2
Operating temperature: -10...70°C
Cable length: 0.31m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 36.3mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details PFE0514B1-000U-A99 SUNON
Category: DC48V Fans, Description: Fan: DC; axial; 48VDC; 140x140x51mm; 425.25m3/h; 61.4dBA; Len: 310mm, Type of fan: DC, Kind of fan: axial, Supply voltage: 48V DC, Operating voltage: 36...72V, Fan dimensions: 140x140x51mm, Power consumption: 22.56W, Current rating: 0.47A, Fan efficiency: 425.25m3/h, Noise level: 61.4dBA, Kind of Bearing: ball bearing, Rotational rate/speed: 5000 (±10%)rpm, Current and power consumption tolerance: ±15%, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: lead x2, Operating temperature: -10...70°C, Cable length: 0.31m, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Static pressure: 36.3mm H2O, Wire size: 24AWG, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote PFE0514B1-000U-A99
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt |
---|---|---|---|---|---|
PFE0514B1-000U-A99 | Hersteller : Sunon Fans |
Description: FAN AXIAL 140X50.8MM 48VDC WIRE Packaging: Bulk Features: Auto Restart Voltage - Rated: 48VDC Size / Dimension: Square - 140mm L x 140mm H Bearing Type: Ball RPM: 5000 RPM Air Flow: 250.3 CFM (7.01m³/min) Width: 50.80mm Weight: 1.4 lbs (635.0 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Tubeaxial Noise: 61.4dB(A) Static Pressure: 1.430 in H2O (356.2 Pa) Part Status: Active Power (Watts): 22.56 W |
Produkt ist nicht verfügbar |
||
PFE0514B1-000U-A99 | Hersteller : Sunon | DC Fans Axial Fan, 140x140x51mm, 48VDC, 250.3CFM, 1.43"H2O, Auto Restart, High Airflow |
Produkt ist nicht verfügbar |
||
PFE0514B1-000U-A99 | Hersteller : SUNON |
Category: DC48V Fans Description: Fan: DC; axial; 48VDC; 140x140x51mm; 425.25m3/h; 61.4dBA; Len: 310mm Type of fan: DC Kind of fan: axial Supply voltage: 48V DC Operating voltage: 36...72V Fan dimensions: 140x140x51mm Power consumption: 22.56W Current rating: 0.47A Fan efficiency: 425.25m3/h Noise level: 61.4dBA Kind of Bearing: ball bearing Rotational rate/speed: 5000 (±10%)rpm Current and power consumption tolerance: ±15% Min. insulation resistance: 10MΩ Impeller material: thermoplastic Enclosure material: thermoplastic Insulation class: A Leads: lead x2 Operating temperature: -10...70°C Cable length: 0.31m Flammability rating: UL94V-0 Additional functions: autorestart Fan motor: brushless DC Static pressure: 36.3mm H2O Wire size: 24AWG |
Produkt ist nicht verfügbar |
