SY-5-K FUJITSU
Hersteller: FUJITSU
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; 2A; 0.5A/120VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 120V AC
DC contacts rating @R: 1A / 24V DC
Switched voltage: max. 60V DC; max. 120V AC
Relay variant: signal; subminiature
Mounting: PCB
Coil resistance: 167Ω
Coil voltage min.: 3.5V DC
Operate time: 5ms
Body dimensions: 12.5x7.4x9.4mm
Coil power consumption: 150mW
Mechanical durability: 5000000 cycles
Operating temperature: -30...90°C
Relay series: SY
Contact resistance: 100mΩ
Electrical life: 100000 cycles
Switching capacity: 24W; 60VA
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; 2A; 0.5A/120VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 120V AC
DC contacts rating @R: 1A / 24V DC
Switched voltage: max. 60V DC; max. 120V AC
Relay variant: signal; subminiature
Mounting: PCB
Coil resistance: 167Ω
Coil voltage min.: 3.5V DC
Operate time: 5ms
Body dimensions: 12.5x7.4x9.4mm
Coil power consumption: 150mW
Mechanical durability: 5000000 cycles
Operating temperature: -30...90°C
Relay series: SY
Contact resistance: 100mΩ
Electrical life: 100000 cycles
Switching capacity: 24W; 60VA
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 883 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
40+ | 1.79 EUR |
44+ | 1.63 EUR |
58+ | 1.24 EUR |
61+ | 1.17 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details SY-5-K FUJITSU
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; 2A; 0.5A/120VAC; PCB, Type of relay: electromagnetic, Contacts configuration: SPDT, Rated coil voltage: 5V DC, Contact current max.: 2A, AC contacts rating @R: 0.5A / 120V AC, DC contacts rating @R: 1A / 24V DC, Switched voltage: max. 60V DC; max. 120V AC, Relay variant: signal; subminiature, Mounting: PCB, Coil resistance: 167Ω, Coil voltage min.: 3.5V DC, Operate time: 5ms, Body dimensions: 12.5x7.4x9.4mm, Coil power consumption: 150mW, Mechanical durability: 5000000 cycles, Operating temperature: -30...90°C, Relay series: SY, Contact resistance: 100mΩ, Electrical life: 100000 cycles, Switching capacity: 24W; 60VA, Contact material: AgPd/Au 0,2μm, Terminal pitch: 2.54mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote SY-5-K nach Preis ab 1.17 EUR bis 8.11 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SY-5-K | Hersteller : FUJITSU |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; 2A; 0.5A/120VAC; PCB Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 5V DC Contact current max.: 2A AC contacts rating @R: 0.5A / 120V AC DC contacts rating @R: 1A / 24V DC Switched voltage: max. 60V DC; max. 120V AC Relay variant: signal; subminiature Mounting: PCB Coil resistance: 167Ω Coil voltage min.: 3.5V DC Operate time: 5ms Body dimensions: 12.5x7.4x9.4mm Coil power consumption: 150mW Mechanical durability: 5000000 cycles Operating temperature: -30...90°C Relay series: SY Contact resistance: 100mΩ Electrical life: 100000 cycles Switching capacity: 24W; 60VA Contact material: AgPd/Au 0,2μm Terminal pitch: 2.54mm |
auf Bestellung 883 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
SY-5-K | Hersteller : Fujitsu | Low Signal Relays - PCB SIGNAL |
auf Bestellung 10 Stücke: Lieferzeit 10-14 Tag (e) |
|
|||||||||||||||||
SY-5-K | Hersteller : FCL Components | Low Signal Relays - PCB SIGNAL |
auf Bestellung 797 Stücke: Lieferzeit 10-14 Tag (e) |
|
|||||||||||||||||
SY-5-K | Hersteller : Fujitsu | Signal Relay 5VDC 1A SPDT(12.5x7.4x9.5)mm THT |
auf Bestellung 7052 Stücke: Lieferzeit 14-21 Tag (e) |
||||||||||||||||||
SY5K |
auf Bestellung 85 Stücke: Lieferzeit 21-28 Tag (e) |
