TMV 2405DHI Traco Power
Hersteller: Traco Power
Description: DC DC CONVERTER +/-5V 1W
Packaging: Tube
Features: SCP
Package / Case: 7-SIP Module, 5 Leads
Size / Dimension: 0.77" L x 0.30" W x 0.40" H (19.5mm x 7.5mm x 10.2mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 95°C (With Derating)
Applications: ITE (Commercial)
Voltage - Input (Max): 26.4V
Efficiency: 71%
Current - Output (Max): 100mA, 100mA
Voltage - Input (Min): 21.6V
Voltage - Output 1: 5V
Voltage - Output 2: -5V
Part Status: Active
Power (Watts): 1 W
Number of Outputs: 2
Voltage - Isolation: 5.2 kV
Description: DC DC CONVERTER +/-5V 1W
Packaging: Tube
Features: SCP
Package / Case: 7-SIP Module, 5 Leads
Size / Dimension: 0.77" L x 0.30" W x 0.40" H (19.5mm x 7.5mm x 10.2mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 95°C (With Derating)
Applications: ITE (Commercial)
Voltage - Input (Max): 26.4V
Efficiency: 71%
Current - Output (Max): 100mA, 100mA
Voltage - Input (Min): 21.6V
Voltage - Output 1: 5V
Voltage - Output 2: -5V
Part Status: Active
Power (Watts): 1 W
Number of Outputs: 2
Voltage - Isolation: 5.2 kV
auf Bestellung 10 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
2+ | 16.81 EUR |
10+ | 16.23 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details TMV 2405DHI Traco Power
Description: DC DC CONVERTER +/-5V 1W, Packaging: Tube, Features: SCP, Package / Case: 7-SIP Module, 5 Leads, Size / Dimension: 0.77" L x 0.30" W x 0.40" H (19.5mm x 7.5mm x 10.2mm), Mounting Type: Through Hole, Type: Isolated Module, Operating Temperature: -40°C ~ 95°C (With Derating), Applications: ITE (Commercial), Voltage - Input (Max): 26.4V, Efficiency: 71%, Current - Output (Max): 100mA, 100mA, Voltage - Input (Min): 21.6V, Voltage - Output 1: 5V, Voltage - Output 2: -5V, Part Status: Active, Power (Watts): 1 W, Number of Outputs: 2, Voltage - Isolation: 5.2 kV.
Weitere Produktangebote TMV 2405DHI nach Preis ab 13.92 EUR bis 17.69 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TMV 2405DHI | Hersteller : TRACO Power | Isolated DC/DC Converters - Through Hole Product Type: DC/DC; Package Style: SIP-7; Output Power (W): 1; Input Voltage: 24 VDC +/-10%; Output 1 (Vdc): 5; Output 2 (Vdc): -5; Output 3 (Vdc): N/A |
auf Bestellung 27 Stücke: Lieferzeit 10-14 Tag (e) |
|
|||||||||||||||||
TMV 2405DHI | Hersteller : TRACO POWER |
Category: DC/DC Converters Description: Converter: DC/DC; 1W; Uin: 21.6÷26.4V; Uout: 5VDC; Uout2: -5VDC; SIP7 Type of converter: DC/DC Power: 1W Input voltage: 21.6...26.4V Output voltage: 5V DC Output voltage 2: -5V DC Output current: 0.1A Output current 2: 0.1A Case: SIP7 Body dimensions: 19.5x10.2x7.1mm Efficiency: 71% Operating temperature: -40...85°C Switching frequency: 100kHz Protection: short circuit protection SCP Insulation voltage: 5.2kV Manufacturer series: TMV-HI Number of outputs: 2 Anzahl je Verpackung: 1 Stücke |
Produkt ist nicht verfügbar |
||||||||||||||||||
TMV 2405DHI | Hersteller : TRACO POWER |
Category: DC/DC Converters Description: Converter: DC/DC; 1W; Uin: 21.6÷26.4V; Uout: 5VDC; Uout2: -5VDC; SIP7 Type of converter: DC/DC Power: 1W Input voltage: 21.6...26.4V Output voltage: 5V DC Output voltage 2: -5V DC Output current: 0.1A Output current 2: 0.1A Case: SIP7 Body dimensions: 19.5x10.2x7.1mm Efficiency: 71% Operating temperature: -40...85°C Switching frequency: 100kHz Protection: short circuit protection SCP Insulation voltage: 5.2kV Manufacturer series: TMV-HI Number of outputs: 2 |
Produkt ist nicht verfügbar |
