Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
DG58C-A-05P-13-00A(H) DG58C-A-05P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 70mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 310 Stücke:
Lieferzeit 14-21 Tag (e)
38+1.89 EUR
55+1.31 EUR
58+1.23 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-06P-13-00A(H) DG58C-A-06P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 80mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 410 Stücke:
Lieferzeit 14-21 Tag (e)
27+2.7 EUR
32+2.3 EUR
52+1.4 EUR
55+1.32 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H) DG58C-A-08P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 0.1m
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 156 Stücke:
Lieferzeit 14-21 Tag (e)
26+2.79 EUR
38+1.9 EUR
40+1.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-02P-13-00A(H) DG58C-B-02P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 23.16mm
Connector pinout layout: 1x2
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 2
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H) DG58C-B-03P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C5D73AD2C1ECAD&compId=DG58C-B.pdf?ci_sign=e93c4722aecaa007c6c8c4a07ca09a941c4c94e0 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Rated voltage: 300V
Colour: black
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 33.16mm
Depth: 15mm
Height: 19.3mm
Number of ways: 3
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x3
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
auf Bestellung 832 Stücke:
Lieferzeit 14-21 Tag (e)
66+1.09 EUR
76+0.95 EUR
89+0.8 EUR
113+0.63 EUR
120+0.6 EUR
Mindestbestellmenge: 66
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-04P-13-00A(H) DG58C-B-04P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 43.16mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 72 Stücke:
Lieferzeit 14-21 Tag (e)
49+1.49 EUR
57+1.26 EUR
72+0.99 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H) DG58C-B-05P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 53.16mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 215 Stücke:
Lieferzeit 14-21 Tag (e)
50+1.46 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-06P-13-00A(H) DG58C-B-06P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 63.16mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 600 Stücke:
Lieferzeit 14-21 Tag (e)
32+2.25 EUR
56+1.28 EUR
59+1.21 EUR
Mindestbestellmenge: 32
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H) DG58C-B-08P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 83.16mm
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-02P-13-00A(H) DG58C-A-02P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Rated voltage: 300V
Colour: black
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 40mm
Depth: 15mm
Height: 19.3mm
Number of ways: 2
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x2
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
Anzahl je Verpackung: 1 Stücke
auf Bestellung 687 Stücke:
Lieferzeit 7-14 Tag (e)
51+1.42 EUR
95+0.76 EUR
100+0.72 EUR
Mindestbestellmenge: 51
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-03P-13-00A(H) DG58C-A-03P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C59CBCC669CCAD&compId=DG58C-A.pdf?ci_sign=a3488900169aca8356f83bdc6195c0f4fb6c057f Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 50mm
Connector pinout layout: 1x3
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 3
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 172 Stücke:
Lieferzeit 7-14 Tag (e)
33+2.22 EUR
38+1.92 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 33
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-03P-13-00A(H) DG58C-A-03P-13-00A(H)
Produktcode: 139824
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-a-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 3, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 3
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-04P-13-00A(H) DG58C-A-04P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 60mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 203 Stücke:
Lieferzeit 7-14 Tag (e)
29+2.53 EUR
34+2.14 EUR
64+1.13 EUR
68+1.06 EUR
Mindestbestellmenge: 29
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-05P-13-00A(H) DG58C-A-05P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 70mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 310 Stücke:
Lieferzeit 7-14 Tag (e)
38+1.89 EUR
55+1.31 EUR
58+1.23 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-05P-13-00A(H)
Produktcode: 139826
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-a-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 5, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 5
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-06P-13-00A(H) DG58C-A-06P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 80mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 410 Stücke:
Lieferzeit 7-14 Tag (e)
27+2.7 EUR
32+2.3 EUR
52+1.4 EUR
55+1.32 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H) DG58C-A-08P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 0.1m
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 156 Stücke:
Lieferzeit 7-14 Tag (e)
26+2.79 EUR
38+1.9 EUR
40+1.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H)
Produktcode: 139828
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-a-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 8, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 8
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-02P-13-00A(H) DG58C-B-02P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 23.16mm
Connector pinout layout: 1x2
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 2
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H) DG58C-B-03P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C5D73AD2C1ECAD&compId=DG58C-B.pdf?ci_sign=e93c4722aecaa007c6c8c4a07ca09a941c4c94e0 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Rated voltage: 300V
Colour: black
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 33.16mm
Depth: 15mm
Height: 19.3mm
Number of ways: 3
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x3
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
Anzahl je Verpackung: 1 Stücke
auf Bestellung 832 Stücke:
Lieferzeit 7-14 Tag (e)
66+1.09 EUR
76+0.95 EUR
89+0.8 EUR
113+0.63 EUR
120+0.6 EUR
Mindestbestellmenge: 66
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H)
Produktcode: 139830
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-b-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Klemmenblock
Beschreibung: Бар'єрний клемник з кришкою, без фланців, крок 10 mm, кількість контактів: 3, луджені. Напруга/струм: 300В/20А. Для кабелю: 22-12AWG. Колір чорний
Anzahl Kontakte: 3
Затискач гвинтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-04P-13-00A(H) DG58C-B-04P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 43.16mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 72 Stücke:
Lieferzeit 7-14 Tag (e)
49+1.49 EUR
57+1.26 EUR
72+0.99 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H) DG58C-B-05P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 53.16mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 215 Stücke:
Lieferzeit 7-14 Tag (e)
50+1.46 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H)
Produktcode: 139832
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-b-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, без фланцев, шаг 10 мм, количество контактов: 5, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 5
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-06P-13-00A(H) DG58C-B-06P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 63.16mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 600 Stücke:
Lieferzeit 7-14 Tag (e)
32+2.25 EUR
56+1.28 EUR
59+1.21 EUR
Mindestbestellmenge: 32
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H) DG58C-B-08P-13-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 83.16mm
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H)
Produktcode: 139834
zu Favoriten hinzufügen Lieblingsprodukt

Degson Electronics dg58c-b-datasheet.pdf Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, без фланцев, шаг 10 мм, количество контактов: 8, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 8
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00A(H) DG636-6.35-02P-14-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB82531ED99DC2DB890C917820&compId=DG636-6.35-03P-14-00A(H).pdf?ci_sign=bdc376318d6eaf0c42a5623996c8a9d4e9e1335e pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B32056660DECAD&compId=DG636.pdf?ci_sign=3ae2b60a4f2218cc8af63c50c92f59d0652a20c8 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Mechanical mounting: on PCBs
Body material: polyamide 66
Type of connector: PCB terminal block
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 12.7mm
Depth: 12.5mm
Height: 21.5mm
Number of ways: 2
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 1x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Colour: green
Contact material: brass
Electrical mounting: cage clamp; screw terminal; THT
Conform to the norm: CE; UL; VDE
auf Bestellung 6926 Stücke:
Lieferzeit 14-21 Tag (e)
65+1.12 EUR
206+0.35 EUR
219+0.33 EUR
Mindestbestellmenge: 65
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00AH Degson Electronics DG636-6.35-02P-14-00AH
auf Bestellung 321 Stücke:
Lieferzeit 14-21 Tag (e)
81+1.78 EUR
100+1.64 EUR
250+1.52 EUR
Mindestbestellmenge: 81
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00A(H) DG636-6.35-02P-14-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB82531ED99DC2DB890C917820&compId=DG636-6.35-03P-14-00A(H).pdf?ci_sign=bdc376318d6eaf0c42a5623996c8a9d4e9e1335e pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B32056660DECAD&compId=DG636.pdf?ci_sign=3ae2b60a4f2218cc8af63c50c92f59d0652a20c8 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Mechanical mounting: on PCBs
Body material: polyamide 66
Type of connector: PCB terminal block
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 12.7mm
Depth: 12.5mm
Height: 21.5mm
Number of ways: 2
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 1x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Colour: green
Contact material: brass
Electrical mounting: cage clamp; screw terminal; THT
Conform to the norm: CE; UL; VDE
Anzahl je Verpackung: 1 Stücke
auf Bestellung 6926 Stücke:
Lieferzeit 7-14 Tag (e)
65+1.12 EUR
206+0.35 EUR
219+0.33 EUR
Mindestbestellmenge: 65
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-03P-14-00AH Degson Electronics DG636-6.35-03P-14-00AH
auf Bestellung 200 Stücke:
Lieferzeit 14-21 Tag (e)
69+2.07 EUR
100+1.91 EUR
Mindestbestellmenge: 69
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-03P-14-00A(H) DEGSON ELECTRONICS DG636-6.35-03P-14 PCB terminal blocks
auf Bestellung 1736 Stücke:
Lieferzeit 7-14 Tag (e)
49+1.47 EUR
115+0.62 EUR
122+0.59 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-06P-14-00AH Degson Electronics DG636-6.35-06P-14-00AH
auf Bestellung 375 Stücke:
Lieferzeit 14-21 Tag (e)
70+2.05 EUR
100+1.89 EUR
250+1.75 EUR
Mindestbestellmenge: 70
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-04P-14-00AH DG636A-6.35-04P-14-00AH DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1ED6B08D4CFA1766BE27&compId=DG636A-6.35.pdf?ci_sign=264825c80739fd4cfcede3ac0d071b04669716b7 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Contact material: copper
Connector variant: double deck
Colour: green
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Electrical mounting: screw terminal; THT
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Conform to the norm: UL
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 15.88mm
Depth: 28mm
Height: 38.9mm
Number of ways: 4
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 2x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Body material: polyamide 66
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-04P-14-00AH DG636A-6.35-04P-14-00AH DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1ED6B08D4CFA1766BE27&compId=DG636A-6.35.pdf?ci_sign=264825c80739fd4cfcede3ac0d071b04669716b7 Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Contact material: copper
Connector variant: double deck
Colour: green
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Electrical mounting: screw terminal; THT
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Conform to the norm: UL
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 15.88mm
Depth: 28mm
Height: 38.9mm
Number of ways: 4
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 2x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Body material: polyamide 66
Anzahl je Verpackung: 200 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-06P-14-00AH DEGSON ELECTRONICS DG636A-6.35-06P PCB terminal blocks
auf Bestellung 20 Stücke:
Lieferzeit 7-14 Tag (e)
20+3.58 EUR
33+2.17 EUR
600+1.37 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
DG636S-9.52-02P-14-00AH DEGSON ELECTRONICS DG636S-9.52-02P PCB terminal blocks
auf Bestellung 462 Stücke:
Lieferzeit 7-14 Tag (e)
64+1.13 EUR
130+0.55 EUR
137+0.52 EUR
Mindestbestellmenge: 64
Im Einkaufswagen  Stück im Wert von  UAH
DG636S-9.52-03P-14-00AH DEGSON ELECTRONICS DG636S-9.52-03P PCB terminal blocks
auf Bestellung 1761 Stücke:
Lieferzeit 7-14 Tag (e)
55+1.32 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 55
Im Einkaufswagen  Stück im Wert von  UAH
DG638-9.52-02P-14-00AH DEGSON ELECTRONICS DG638-9.52-02P PCB terminal blocks
auf Bestellung 769 Stücke:
Lieferzeit 7-14 Tag (e)
58+1.24 EUR
131+0.55 EUR
138+0.52 EUR
Mindestbestellmenge: 58
Im Einkaufswagen  Stück im Wert von  UAH
DG638-9.52-03P-14-00AH DEGSON ELECTRONICS DG638-9.52-03P PCB terminal blocks
auf Bestellung 860 Stücke:
Lieferzeit 7-14 Tag (e)
60+1.2 EUR
91+0.79 EUR
99+0.73 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-02P-13-00AH DEGSON ELECTRONICS DG66RT-02P PCB terminal blocks
auf Bestellung 34 Stücke:
Lieferzeit 7-14 Tag (e)
34+2.1 EUR
50+1.43 EUR
500+0.84 EUR
Mindestbestellmenge: 34
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-03P-13-00AH DEGSON ELECTRONICS DG66RT-03P PCB terminal blocks
auf Bestellung 68 Stücke:
Lieferzeit 7-14 Tag (e)
38+1.89 EUR
52+1.39 EUR
55+1.3 EUR
500+1.27 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-04P-13-00AH DEGSON ELECTRONICS DG66RT-04P PCB terminal blocks
auf Bestellung 69 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.97 EUR
37+1.94 EUR
40+1.83 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-05P-13-00AH DEGSON ELECTRONICS DG66RT-05P PCB terminal blocks
auf Bestellung 45 Stücke:
Lieferzeit 7-14 Tag (e)
23+3.15 EUR
32+2.3 EUR
33+2.17 EUR
600+2.12 EUR
Mindestbestellmenge: 23
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-02P-13-00A(H) DEGSON ELECTRONICS DG78H-A-02P-13 Terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-03P-13-00A(H) DEGSON ELECTRONICS DG78H-A-03P-13 Terminal blocks
auf Bestellung 129 Stücke:
Lieferzeit 7-14 Tag (e)
30+2.39 EUR
48+1.52 EUR
50+1.43 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-04P-13-00A(H) DEGSON ELECTRONICS DG78H-A-04P-13 Terminal blocks
auf Bestellung 259 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.86 EUR
39+1.84 EUR
41+1.74 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-05P-13-00A(H) DEGSON ELECTRONICS DG78H-A-05P-13 Terminal blocks
auf Bestellung 24 Stücke:
Lieferzeit 7-14 Tag (e)
24+2.97 EUR
500+2.2 EUR
Mindestbestellmenge: 24
Im Einkaufswagen  Stück im Wert von  UAH
DG801-01P-11-00A(H)
+1
 		DG801-01P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Current rating: 6.3A
Rated voltage: 250V
Electrical mounting: screw terminal
Flammability rating: UL94V-0
Body material: polyamide
Wire cross-section: 0.5...2.5mm2
Number of terminals: 2
Operating temperature: -40...105°C
Contact plating: tinned
Type of connector: terminal block
Design: fuse x1
Caution!: fuses not included
Mounting hole diameter: 2.2...3.2mm
Fuse size: 5x20mm
Mechanical mounting: for cable; for panel mounting; mounting holes
Number of ways: 1
Conform to the norm: CE; UL; VDE
Contact material: brass
Wire size: 22AWG...14AWG
Colour: grey
auf Bestellung 995 Stücke:
Lieferzeit 14-21 Tag (e)
71+1.02 EUR
81+0.89 EUR
94+0.76 EUR
162+0.44 EUR
172+0.42 EUR
Mindestbestellmenge: 71
Im Einkaufswagen  Stück im Wert von  UAH
DG801-02P-11-00A(H) DG801-02P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 2
Number of terminals: 4
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
auf Bestellung 6851 Stücke:
Lieferzeit 14-21 Tag (e)
60+1.2 EUR
69+1.05 EUR
80+0.9 EUR
138+0.52 EUR
146+0.49 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG801-03P-11-00A(H)
+1
 		DG801-03P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 3
Number of terminals: 6
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
auf Bestellung 1269 Stücke:
Lieferzeit 14-21 Tag (e)
46+1.57 EUR
53+1.37 EUR
61+1.19 EUR
105+0.69 EUR
109+0.66 EUR
Mindestbestellmenge: 46
Im Einkaufswagen  Stück im Wert von  UAH
DG801-01P-11-00A(H)
+1
 		DG801-01P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Current rating: 6.3A
Rated voltage: 250V
Electrical mounting: screw terminal
Flammability rating: UL94V-0
Body material: polyamide
Wire cross-section: 0.5...2.5mm2
Number of terminals: 2
Operating temperature: -40...105°C
Contact plating: tinned
Type of connector: terminal block
Design: fuse x1
Caution!: fuses not included
Mounting hole diameter: 2.2...3.2mm
Fuse size: 5x20mm
Mechanical mounting: for cable; for panel mounting; mounting holes
Number of ways: 1
Conform to the norm: CE; UL; VDE
Contact material: brass
Wire size: 22AWG...14AWG
Colour: grey
Anzahl je Verpackung: 1 Stücke
auf Bestellung 995 Stücke:
Lieferzeit 7-14 Tag (e)
71+1.02 EUR
81+0.89 EUR
94+0.76 EUR
162+0.44 EUR
172+0.42 EUR
Mindestbestellmenge: 71
Im Einkaufswagen  Stück im Wert von  UAH
DG801-02P-11-00A(H) DG801-02P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 2
Number of terminals: 4
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 6851 Stücke:
Lieferzeit 7-14 Tag (e)
60+1.2 EUR
69+1.05 EUR
80+0.9 EUR
138+0.52 EUR
146+0.49 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG801-03P-11-00A(H)
+1
 		DG801-03P-11-00A(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 3
Number of terminals: 6
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1269 Stücke:
Lieferzeit 7-14 Tag (e)
46+1.57 EUR
53+1.37 EUR
61+1.19 EUR
105+0.69 EUR
109+0.66 EUR
Mindestbestellmenge: 46
Im Einkaufswagen  Stück im Wert von  UAH
DG801-04P-11-00A(H) DEGSON ELECTRONICS DG801-4P11 Terminal blocks
auf Bestellung 178 Stücke:
Lieferzeit 7-14 Tag (e)
27+2.72 EUR
65+1.12 EUR
68+1.06 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG88-02P-13-10AH DEGSON ELECTRONICS DG88-02P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG88-03P-13-10AH DEGSON ELECTRONICS DG88-03P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG88-04P-13-10AH DEGSON ELECTRONICS DG88-04P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG8HSWP-1.2-12P-17-100Z(H) DG8HSWP-1.2-12P-17-100Z(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B37DE60841ACAD&compId=DG10HSWP-1.2.pdf?ci_sign=847d24f548d2e237833c102d9f15198ac71ee15e Category: Terminal blocks
Description: Connector: terminal block; 24A; 450V; with wire protector
Colour: transparent
Conform to the norm: CE; UL; VDE
Mechanical mounting: for cable; for panel mounting; mounting holes
Connectors features: may be easily broken into smaller fragments
Contact material: phosphor bronze
Body material: polyamide 66
Electrical mounting: screw terminal
Type of connector: terminal block
Flammability rating: UL94V-2
Connector variant: with wire protector
Operating temperature: -40...110°C
Wire cross-section: 0.5...2.5mm2
Mounting hole diameter: 3mm
Height: 15.5mm
Width: 17.8mm
Length: 96.05mm
Number of ways: 12
Number of terminals: 24
Wire size: 20AWG...14AWG
Current rating: 24A
Rated voltage: 450V
auf Bestellung 4905 Stücke:
Lieferzeit 14-21 Tag (e)
50+1.43 EUR
61+1.19 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG8HSWP-1.2-12P-17-100Z(H) DG8HSWP-1.2-12P-17-100Z(H) DEGSON ELECTRONICS pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B37DE60841ACAD&compId=DG10HSWP-1.2.pdf?ci_sign=847d24f548d2e237833c102d9f15198ac71ee15e Category: Terminal blocks
Description: Connector: terminal block; 24A; 450V; with wire protector
Colour: transparent
Conform to the norm: CE; UL; VDE
Mechanical mounting: for cable; for panel mounting; mounting holes
Connectors features: may be easily broken into smaller fragments
Contact material: phosphor bronze
Body material: polyamide 66
Electrical mounting: screw terminal
Type of connector: terminal block
Flammability rating: UL94V-2
Connector variant: with wire protector
Operating temperature: -40...110°C
Wire cross-section: 0.5...2.5mm2
Mounting hole diameter: 3mm
Height: 15.5mm
Width: 17.8mm
Length: 96.05mm
Number of ways: 12
Number of terminals: 24
Wire size: 20AWG...14AWG
Current rating: 24A
Rated voltage: 450V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 4905 Stücke:
Lieferzeit 7-14 Tag (e)
50+1.43 EUR
61+1.19 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-05P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-05P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 70mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 310 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
38+1.89 EUR
55+1.31 EUR
58+1.23 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-06P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-06P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 80mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 410 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
27+2.7 EUR
32+2.3 EUR
52+1.4 EUR
55+1.32 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-08P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 0.1m
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 156 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
26+2.79 EUR
38+1.9 EUR
40+1.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-02P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-02P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 23.16mm
Connector pinout layout: 1x2
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 2
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H) pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C5D73AD2C1ECAD&compId=DG58C-B.pdf?ci_sign=e93c4722aecaa007c6c8c4a07ca09a941c4c94e0
DG58C-B-03P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Rated voltage: 300V
Colour: black
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 33.16mm
Depth: 15mm
Height: 19.3mm
Number of ways: 3
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x3
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
auf Bestellung 832 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
66+1.09 EUR
76+0.95 EUR
89+0.8 EUR
113+0.63 EUR
120+0.6 EUR
Mindestbestellmenge: 66
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-04P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-04P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 43.16mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 72 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
49+1.49 EUR
57+1.26 EUR
72+0.99 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-05P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 53.16mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 215 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
50+1.46 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-06P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-06P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 63.16mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
auf Bestellung 600 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
32+2.25 EUR
56+1.28 EUR
59+1.21 EUR
Mindestbestellmenge: 32
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-08P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 83.16mm
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-02P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-02P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Rated voltage: 300V
Colour: black
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 40mm
Depth: 15mm
Height: 19.3mm
Number of ways: 2
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x2
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
Anzahl je Verpackung: 1 Stücke
auf Bestellung 687 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
51+1.42 EUR
95+0.76 EUR
100+0.72 EUR
Mindestbestellmenge: 51
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-03P-13-00A(H) pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C59CBCC669CCAD&compId=DG58C-A.pdf?ci_sign=a3488900169aca8356f83bdc6195c0f4fb6c057f
DG58C-A-03P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 50mm
Connector pinout layout: 1x3
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 3
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 172 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
33+2.22 EUR
38+1.92 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 33
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-03P-13-00A(H)
Produktcode: 139824
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-a-datasheet.pdf
DG58C-A-03P-13-00A(H)
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 3, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 3
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-04P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-04P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 60mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 203 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
29+2.53 EUR
34+2.14 EUR
64+1.13 EUR
68+1.06 EUR
Mindestbestellmenge: 29
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-05P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-05P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 70mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 310 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
38+1.89 EUR
55+1.31 EUR
58+1.23 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-05P-13-00A(H)
Produktcode: 139826
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-a-datasheet.pdf
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 5, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 5
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-06P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-06P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 80mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 410 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
27+2.7 EUR
32+2.3 EUR
52+1.4 EUR
55+1.32 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BD5F1A6F5005056AB5A8F&compId=dg58c-a.pdf?ci_sign=b31db92d477b287c2310df5ca266a24573966fd5
DG58C-A-08P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: for panel mounting; mounting holes; on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 0.1m
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 156 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
26+2.79 EUR
38+1.9 EUR
40+1.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-A-08P-13-00A(H)
Produktcode: 139828
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-a-datasheet.pdf
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, с фланцами, шаг 10 мм, количество контактов: 8, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 8
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-02P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-02P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x2
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 23.16mm
Connector pinout layout: 1x2
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 2
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H) pVersion=0046&contRep=ZT&docId=005056AB752F1EE382C5D73AD2C1ECAD&compId=DG58C-B.pdf?ci_sign=e93c4722aecaa007c6c8c4a07ca09a941c4c94e0
DG58C-B-03P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x3
Rated voltage: 300V
Colour: black
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Body material: polyamide 66
Contact plating: tinned
Flammability rating: UL94V-0
Operating temperature: -40...105°C
Wire cross-section: 4mm2
Contacts pitch: 10mm
Length: 33.16mm
Depth: 15mm
Height: 19.3mm
Number of ways: 3
Current rating: 20A
Wire size: 22AWG...12AWG
Connector pinout layout: 1x3
Spatial orientation: straight
Contact material: brass
Electrical mounting: screw terminal; THT
Conform to the norm: CE; UL
Connector: terminal
Connector variant: with protection
Anzahl je Verpackung: 1 Stücke
auf Bestellung 832 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
66+1.09 EUR
76+0.95 EUR
89+0.8 EUR
113+0.63 EUR
120+0.6 EUR
Mindestbestellmenge: 66
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-03P-13-00A(H)
Produktcode: 139830
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-b-datasheet.pdf
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Klemmenblock
Beschreibung: Бар'єрний клемник з кришкою, без фланців, крок 10 mm, кількість контактів: 3, луджені. Напруга/струм: 300В/20А. Для кабелю: 22-12AWG. Колір чорний
Anzahl Kontakte: 3
Затискач гвинтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-04P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-04P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x4
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 43.16mm
Connector pinout layout: 1x4
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 4
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 72 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
49+1.49 EUR
57+1.26 EUR
72+0.99 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-05P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x5
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 53.16mm
Connector pinout layout: 1x5
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 5
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 215 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
50+1.46 EUR
71+1.02 EUR
74+0.97 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-05P-13-00A(H)
Produktcode: 139832
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-b-datasheet.pdf
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, без фланцев, шаг 10 мм, количество контактов: 5, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 5
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-06P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-06P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x6
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 63.16mm
Connector pinout layout: 1x6
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 6
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 600 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
32+2.25 EUR
56+1.28 EUR
59+1.21 EUR
Mindestbestellmenge: 32
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472BF1F1A6F5005056AB5A8F&compId=dg58c-b.pdf?ci_sign=371f869a8d37021f50edfe3f17b6e8c6fd827463
DG58C-B-08P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 20A; 300V; straight; 1x8
Type of connector: PCB terminal block
Connector: terminal
Current rating: 20A
Rated voltage: 300V
Spatial orientation: straight
Connector variant: with protection
Mechanical mounting: on PCBs
Electrical mounting: screw terminal; THT
Contact material: brass
Contact plating: tinned
Colour: black
Flammability rating: UL94V-0
Body material: polyamide 66
Wire size: 22AWG...12AWG
Depth: 15mm
Length: 83.16mm
Connector pinout layout: 1x8
Wire cross-section: 4mm2
Contacts pitch: 10mm
Number of ways: 8
Height: 19.3mm
Conform to the norm: CE; UL
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG58C-B-08P-13-00A(H)
Produktcode: 139834
zu Favoriten hinzufügen Lieblingsprodukt

dg58c-b-datasheet.pdf
Hersteller: Degson Electronics
Steckverbinder, Reihenklemmen > Steckverbindungen Schaltsteckverbindungen DIN
Beschreibung: Барьерный клеммник с крышкой, без фланцев, шаг 10 мм, количество контактов: 8, луженые. Напряжение/ток: 300В/20А. Для кабеля: 22-12AWG. Цвет:черный
Anzahl Kontakte: 8
Струм: 20А/300V
Провід: AWG:22-12
Монтаж провода: Зажим винтом
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00A(H) pVersion=0046&contRep=ZT&docId=005056AB82531ED99DC2DB890C917820&compId=DG636-6.35-03P-14-00A(H).pdf?ci_sign=bdc376318d6eaf0c42a5623996c8a9d4e9e1335e pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B32056660DECAD&compId=DG636.pdf?ci_sign=3ae2b60a4f2218cc8af63c50c92f59d0652a20c8
DG636-6.35-02P-14-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Mechanical mounting: on PCBs
Body material: polyamide 66
Type of connector: PCB terminal block
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 12.7mm
Depth: 12.5mm
Height: 21.5mm
Number of ways: 2
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 1x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Colour: green
Contact material: brass
Electrical mounting: cage clamp; screw terminal; THT
Conform to the norm: CE; UL; VDE
auf Bestellung 6926 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
65+1.12 EUR
206+0.35 EUR
219+0.33 EUR
Mindestbestellmenge: 65
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00AH
Hersteller: Degson Electronics
DG636-6.35-02P-14-00AH
auf Bestellung 321 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
81+1.78 EUR
100+1.64 EUR
250+1.52 EUR
Mindestbestellmenge: 81
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-02P-14-00A(H) pVersion=0046&contRep=ZT&docId=005056AB82531ED99DC2DB890C917820&compId=DG636-6.35-03P-14-00A(H).pdf?ci_sign=bdc376318d6eaf0c42a5623996c8a9d4e9e1335e pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B32056660DECAD&compId=DG636.pdf?ci_sign=3ae2b60a4f2218cc8af63c50c92f59d0652a20c8
DG636-6.35-02P-14-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Mechanical mounting: on PCBs
Body material: polyamide 66
Type of connector: PCB terminal block
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 12.7mm
Depth: 12.5mm
Height: 21.5mm
Number of ways: 2
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 1x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Colour: green
Contact material: brass
Electrical mounting: cage clamp; screw terminal; THT
Conform to the norm: CE; UL; VDE
Anzahl je Verpackung: 1 Stücke
auf Bestellung 6926 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
65+1.12 EUR
206+0.35 EUR
219+0.33 EUR
Mindestbestellmenge: 65
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-03P-14-00AH
Hersteller: Degson Electronics
DG636-6.35-03P-14-00AH
auf Bestellung 200 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
69+2.07 EUR
100+1.91 EUR
Mindestbestellmenge: 69
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-03P-14-00A(H)
Hersteller: DEGSON ELECTRONICS
DG636-6.35-03P-14 PCB terminal blocks
auf Bestellung 1736 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
49+1.47 EUR
115+0.62 EUR
122+0.59 EUR
Mindestbestellmenge: 49
Im Einkaufswagen  Stück im Wert von  UAH
DG636-6.35-06P-14-00AH
Hersteller: Degson Electronics
DG636-6.35-06P-14-00AH
auf Bestellung 375 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
70+2.05 EUR
100+1.89 EUR
250+1.75 EUR
Mindestbestellmenge: 70
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-04P-14-00AH pVersion=0046&contRep=ZT&docId=005056AB752F1ED6B08D4CFA1766BE27&compId=DG636A-6.35.pdf?ci_sign=264825c80739fd4cfcede3ac0d071b04669716b7
DG636A-6.35-04P-14-00AH
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Contact material: copper
Connector variant: double deck
Colour: green
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Electrical mounting: screw terminal; THT
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Conform to the norm: UL
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 15.88mm
Depth: 28mm
Height: 38.9mm
Number of ways: 4
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 2x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Body material: polyamide 66
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-04P-14-00AH pVersion=0046&contRep=ZT&docId=005056AB752F1ED6B08D4CFA1766BE27&compId=DG636A-6.35.pdf?ci_sign=264825c80739fd4cfcede3ac0d071b04669716b7
DG636A-6.35-04P-14-00AH
Hersteller: DEGSON ELECTRONICS
Category: PCB terminal blocks
Description: Connector: PCB terminal block; terminal; 24A; 450V; angled 90°
Operating temperature: -40...105°C
Contact material: copper
Connector variant: double deck
Colour: green
Mechanical mounting: on PCBs
Type of connector: PCB terminal block
Electrical mounting: screw terminal; THT
Connector: terminal
Contact plating: tinned
Flammability rating: UL94V-0
Conform to the norm: UL
Wire cross-section: 4mm2
Contacts pitch: 6.35mm
Length: 15.88mm
Depth: 28mm
Height: 38.9mm
Number of ways: 4
Current rating: 24A
Wire size: 26AWG...10AWG
Rated voltage: 450V
Connector pinout layout: 2x2
Spatial orientation: angled 90°
Connectors features: assembling possibility
Body material: polyamide 66
Anzahl je Verpackung: 200 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG636A-6.35-06P-14-00AH
Hersteller: DEGSON ELECTRONICS
DG636A-6.35-06P PCB terminal blocks
auf Bestellung 20 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+3.58 EUR
33+2.17 EUR
600+1.37 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
DG636S-9.52-02P-14-00AH
Hersteller: DEGSON ELECTRONICS
DG636S-9.52-02P PCB terminal blocks
auf Bestellung 462 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
64+1.13 EUR
130+0.55 EUR
137+0.52 EUR
Mindestbestellmenge: 64
Im Einkaufswagen  Stück im Wert von  UAH
DG636S-9.52-03P-14-00AH
Hersteller: DEGSON ELECTRONICS
DG636S-9.52-03P PCB terminal blocks
auf Bestellung 1761 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
55+1.32 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 55
Im Einkaufswagen  Stück im Wert von  UAH
DG638-9.52-02P-14-00AH
Hersteller: DEGSON ELECTRONICS
DG638-9.52-02P PCB terminal blocks
auf Bestellung 769 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
58+1.24 EUR
131+0.55 EUR
138+0.52 EUR
Mindestbestellmenge: 58
Im Einkaufswagen  Stück im Wert von  UAH
DG638-9.52-03P-14-00AH
Hersteller: DEGSON ELECTRONICS
DG638-9.52-03P PCB terminal blocks
auf Bestellung 860 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
60+1.2 EUR
91+0.79 EUR
99+0.73 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-02P-13-00AH
Hersteller: DEGSON ELECTRONICS
DG66RT-02P PCB terminal blocks
auf Bestellung 34 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
34+2.1 EUR
50+1.43 EUR
500+0.84 EUR
Mindestbestellmenge: 34
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-03P-13-00AH
Hersteller: DEGSON ELECTRONICS
DG66RT-03P PCB terminal blocks
auf Bestellung 68 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
38+1.89 EUR
52+1.39 EUR
55+1.3 EUR
500+1.27 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-04P-13-00AH
Hersteller: DEGSON ELECTRONICS
DG66RT-04P PCB terminal blocks
auf Bestellung 69 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.97 EUR
37+1.94 EUR
40+1.83 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
DG66RT-05P-13-00AH
Hersteller: DEGSON ELECTRONICS
DG66RT-05P PCB terminal blocks
auf Bestellung 45 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
23+3.15 EUR
32+2.3 EUR
33+2.17 EUR
600+2.12 EUR
Mindestbestellmenge: 23
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-02P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
DG78H-A-02P-13 Terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-03P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
DG78H-A-03P-13 Terminal blocks
auf Bestellung 129 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+2.39 EUR
48+1.52 EUR
50+1.43 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-04P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
DG78H-A-04P-13 Terminal blocks
auf Bestellung 259 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.86 EUR
39+1.84 EUR
41+1.74 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
DG78H-A-05P-13-00A(H)
Hersteller: DEGSON ELECTRONICS
DG78H-A-05P-13 Terminal blocks
auf Bestellung 24 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
24+2.97 EUR
500+2.2 EUR
Mindestbestellmenge: 24
Im Einkaufswagen  Stück im Wert von  UAH
DG801-01P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-01P-11-00A(H)
+1
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Current rating: 6.3A
Rated voltage: 250V
Electrical mounting: screw terminal
Flammability rating: UL94V-0
Body material: polyamide
Wire cross-section: 0.5...2.5mm2
Number of terminals: 2
Operating temperature: -40...105°C
Contact plating: tinned
Type of connector: terminal block
Design: fuse x1
Caution!: fuses not included
Mounting hole diameter: 2.2...3.2mm
Fuse size: 5x20mm
Mechanical mounting: for cable; for panel mounting; mounting holes
Number of ways: 1
Conform to the norm: CE; UL; VDE
Contact material: brass
Wire size: 22AWG...14AWG
Colour: grey
auf Bestellung 995 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
71+1.02 EUR
81+0.89 EUR
94+0.76 EUR
162+0.44 EUR
172+0.42 EUR
Mindestbestellmenge: 71
Im Einkaufswagen  Stück im Wert von  UAH
DG801-02P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-02P-11-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 2
Number of terminals: 4
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
auf Bestellung 6851 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
60+1.2 EUR
69+1.05 EUR
80+0.9 EUR
138+0.52 EUR
146+0.49 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG801-03P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-03P-11-00A(H)
+1
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 3
Number of terminals: 6
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
auf Bestellung 1269 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
46+1.57 EUR
53+1.37 EUR
61+1.19 EUR
105+0.69 EUR
109+0.66 EUR
Mindestbestellmenge: 46
Im Einkaufswagen  Stück im Wert von  UAH
DG801-01P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-01P-11-00A(H)
+1
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Current rating: 6.3A
Rated voltage: 250V
Electrical mounting: screw terminal
Flammability rating: UL94V-0
Body material: polyamide
Wire cross-section: 0.5...2.5mm2
Number of terminals: 2
Operating temperature: -40...105°C
Contact plating: tinned
Type of connector: terminal block
Design: fuse x1
Caution!: fuses not included
Mounting hole diameter: 2.2...3.2mm
Fuse size: 5x20mm
Mechanical mounting: for cable; for panel mounting; mounting holes
Number of ways: 1
Conform to the norm: CE; UL; VDE
Contact material: brass
Wire size: 22AWG...14AWG
Colour: grey
Anzahl je Verpackung: 1 Stücke
auf Bestellung 995 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
71+1.02 EUR
81+0.89 EUR
94+0.76 EUR
162+0.44 EUR
172+0.42 EUR
Mindestbestellmenge: 71
Im Einkaufswagen  Stück im Wert von  UAH
DG801-02P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-02P-11-00A(H)
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 2
Number of terminals: 4
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 6851 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
60+1.2 EUR
69+1.05 EUR
80+0.9 EUR
138+0.52 EUR
146+0.49 EUR
Mindestbestellmenge: 60
Im Einkaufswagen  Stück im Wert von  UAH
DG801-03P-11-00A(H) pVersion=0046&contRep=ZT&docId=E1C049FE472C0DF1A6F5005056AB5A8F&compId=DG801.pdf?ci_sign=af856c00f4cf93819072a73ed2131f5573e67c7d
DG801-03P-11-00A(H)
+1
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 6.3A; 250V; screw terminal; tinned
Type of connector: terminal block
Current rating: 6.3A
Rated voltage: 250V
Mechanical mounting: for cable; for panel mounting; mounting holes
Electrical mounting: screw terminal
Contact material: brass
Contact plating: tinned
Colour: grey
Flammability rating: UL94V-0
Body material: polyamide
Wire size: 22AWG...14AWG
Mounting hole diameter: 2.2...3.2mm
Wire cross-section: 0.5...2.5mm2
Design: fuse x1
Number of ways: 3
Number of terminals: 6
Conform to the norm: CE; UL; VDE
Fuse size: 5x20mm
Caution!: fuses not included
Operating temperature: -40...105°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1269 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
46+1.57 EUR
53+1.37 EUR
61+1.19 EUR
105+0.69 EUR
109+0.66 EUR
Mindestbestellmenge: 46
Im Einkaufswagen  Stück im Wert von  UAH
DG801-04P-11-00A(H)
Hersteller: DEGSON ELECTRONICS
DG801-4P11 Terminal blocks
auf Bestellung 178 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
27+2.72 EUR
65+1.12 EUR
68+1.06 EUR
Mindestbestellmenge: 27
Im Einkaufswagen  Stück im Wert von  UAH
DG88-02P-13-10AH
Hersteller: DEGSON ELECTRONICS
DG88-02P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG88-03P-13-10AH
Hersteller: DEGSON ELECTRONICS
DG88-03P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG88-04P-13-10AH
Hersteller: DEGSON ELECTRONICS
DG88-04P PCB terminal blocks
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DG8HSWP-1.2-12P-17-100Z(H) pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B37DE60841ACAD&compId=DG10HSWP-1.2.pdf?ci_sign=847d24f548d2e237833c102d9f15198ac71ee15e
DG8HSWP-1.2-12P-17-100Z(H)
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 24A; 450V; with wire protector
Colour: transparent
Conform to the norm: CE; UL; VDE
Mechanical mounting: for cable; for panel mounting; mounting holes
Connectors features: may be easily broken into smaller fragments
Contact material: phosphor bronze
Body material: polyamide 66
Electrical mounting: screw terminal
Type of connector: terminal block
Flammability rating: UL94V-2
Connector variant: with wire protector
Operating temperature: -40...110°C
Wire cross-section: 0.5...2.5mm2
Mounting hole diameter: 3mm
Height: 15.5mm
Width: 17.8mm
Length: 96.05mm
Number of ways: 12
Number of terminals: 24
Wire size: 20AWG...14AWG
Current rating: 24A
Rated voltage: 450V
auf Bestellung 4905 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
50+1.43 EUR
61+1.19 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
DG8HSWP-1.2-12P-17-100Z(H) pVersion=0046&contRep=ZT&docId=005056AB752F1EE382B37DE60841ACAD&compId=DG10HSWP-1.2.pdf?ci_sign=847d24f548d2e237833c102d9f15198ac71ee15e
DG8HSWP-1.2-12P-17-100Z(H)
Hersteller: DEGSON ELECTRONICS
Category: Terminal blocks
Description: Connector: terminal block; 24A; 450V; with wire protector
Colour: transparent
Conform to the norm: CE; UL; VDE
Mechanical mounting: for cable; for panel mounting; mounting holes
Connectors features: may be easily broken into smaller fragments
Contact material: phosphor bronze
Body material: polyamide 66
Electrical mounting: screw terminal
Type of connector: terminal block
Flammability rating: UL94V-2
Connector variant: with wire protector
Operating temperature: -40...110°C
Wire cross-section: 0.5...2.5mm2
Mounting hole diameter: 3mm
Height: 15.5mm
Width: 17.8mm
Length: 96.05mm
Number of ways: 12
Number of terminals: 24
Wire size: 20AWG...14AWG
Current rating: 24A
Rated voltage: 450V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 4905 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
50+1.43 EUR
61+1.19 EUR
85+0.84 EUR
90+0.8 EUR
Mindestbestellmenge: 50
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 6 12 18 24 30 36 38 39 40 41 42 43 44 45 46 47 48 54 60 61  [ Nächste Seite >> ]
