Hersteller: ELECTRO-PJP
Category: 4mm Crocodile Clips
Description: Crocodile clip; 20A; 1.5kV; red; Grip capac: max.25mm
Conform to the norm: CAT III 1500V; CAT IV 1000V
Type of test accessories: crocodile clip
Contact plating: nickel plated
Measuring instruments application: photovoltaics
Socket size: 4mm
Overall length: 91.1mm
Grip capacity: max. 25mm
Current rating: 20A
Rated voltage: 1.5kV
Colour: red

Hersteller: ELECTRO-PJP
Category: 4mm Crocodile Clips
Description: Crocodile clip; 20A; 1.5kV; green; Grip capac: max.25mm
Conform to the norm: CAT III 1500V; CAT IV 1000V
Type of test accessories: crocodile clip
Contact plating: nickel plated
Measuring instruments application: photovoltaics
Socket size: 4mm
Overall length: 91.1mm
Grip capacity: max. 25mm
Current rating: 20A
Rated voltage: 1.5kV
Colour: green

Hersteller: ELECTRO-PJP
Category: 4mm Banana Sockets
Description: Laboratory connector: 4mm banana; socket; 10A; black; insulated
Connector variant: insulated
Current rating: 10A
Type of lab connector: 4mm banana
Colour: black
Conform to the norm: CAT 0 5000V
Connector: socket
Mounting: faston terminal

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; hook type; 20A; black; Grip capac: max.12.3mm; 1kV
Colour: black
Contact material: brass
Conform to the norm: CAT IV 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: hook type
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 12.3mm
Overall length: 137mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; hook type; 20A; red; Grip capac: max.12.3mm; 1kV
Colour: red
Contact material: brass
Conform to the norm: CAT IV 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: hook type
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 12.3mm
Overall length: 137mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; pincers type; 6A; black; Grip capac: max.4.5mm
Colour: black
Conform to the norm: CAT II 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: pincers type
Socket size: 4mm
Grip capacity: max. 4.5mm
Overall length: 162mm
Current rating: 6A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; pincers type; 6A; red; Grip capac: max.4.5mm; 1000V
Colour: red
Conform to the norm: CAT II 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: pincers type
Socket size: 4mm
Grip capacity: max. 4.5mm
Overall length: 162mm
Current rating: 6A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; pincers type; 6A; black; Grip capac: max.4.5mm
Colour: black
Conform to the norm: CAT II 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: pincers type
Socket size: 4mm
Grip capacity: max. 4.5mm
Overall length: 159mm
Current rating: 6A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 6A; black; Grip capac: max.20mm; 4mm
Colour: black
Contact material: brass
Conform to the norm: CAT III 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: crocodile
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 20mm
Overall length: 176mm
Current rating: 6A
Rated voltage: 1kV AC

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 6A; red; Grip capac: max.20mm; 4mm; 1kVAC
Colour: red
Contact material: brass
Conform to the norm: CAT III 1000V; EN 61010
Type of test accessories: clip-on probe
Kind of clip-on probe: crocodile
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 20mm
Overall length: 176mm
Current rating: 6A
Rated voltage: 1kV AC

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; hook type; 6A; black; 4mm
Colour: black
Type of test accessories: clip-on probe
Kind of clip-on probe: hook type
Socket size: 4mm
Current rating: 6A

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; hook type; 6A; red; 4mm
Colour: red
Type of test accessories: clip-on probe
Kind of clip-on probe: hook type
Socket size: 4mm
Current rating: 6A

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 20A; black; Grip capac: max.18mm; 1000V
Type of test accessories: clip-on probe
Colour: black
Conform to the norm: CAT II 1000V; CAT III 1000V; EN 61010
Kind of clip-on probe: crocodile
Socket size: 4mm
Grip capacity: max. 18mm
Overall length: 155mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 20A; red; Grip capac: max.18mm; 1000V
Type of test accessories: clip-on probe
Colour: red
Conform to the norm: CAT II 1000V; CAT III 1000V; EN 61010
Kind of clip-on probe: crocodile
Socket size: 4mm
Grip capacity: max. 18mm
Overall length: 155mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 20A; black; Grip capac: max.15mm; 1kV
Type of test accessories: clip-on probe
Colour: black
Contact material: brass
Kind of clip-on probe: crocodile
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 15mm
Overall length: 156mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Test hooks
Description: Clip-on probe; crocodile; 20A; red; Grip capac: max.15mm; 1kV; 4mm
Type of test accessories: clip-on probe
Colour: red
Contact material: brass
Kind of clip-on probe: crocodile
Contact plating: nickel plated
Socket size: 4mm
Grip capacity: max. 15mm
Overall length: 156mm
Current rating: 20A
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 3A; BNC plug,both sides; Urated: 1kV; Len: 1m; black
Type of test accessories: test lead
Current rating: 3A
Test lead configuration: BNC plug; both sides
Rated voltage: 1kV
Cable length: 1m
Colour: black
Conform to the norm: CAT II 1000V; CAT III 600V; CAT IV 300V; EN 61010
Operating temperature: -20...80°C
Impedance: 50Ω
Wire insulation material: PVC

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 60VDC; 30VAC; 3A; BNC plug,clip-on hook probe x2
Cable length: 2m
Current rating: 3A
Rated voltage: 30V AC; 60V DC
Impedance: 50Ω
Colour: black
Test lead configuration: BNC plug; clip-on hook probe x2
Wire insulation material: PA; PP
Type of test accessories: test lead

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 60VDC; 30VAC; 3A; BNC plug,clip-on hook probe x2; red
Cable length: 2m
Current rating: 3A
Rated voltage: 30V AC; 60V DC
Impedance: 50Ω
Colour: red
Test lead configuration: BNC plug; clip-on hook probe x2
Wire insulation material: PA; PP
Type of test accessories: test lead

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 3A; BNC plug,both sides; Urated: 1kV; Len: 1m; black
Type of test accessories: test lead
Current rating: 3A
Test lead configuration: BNC plug; both sides
Rated voltage: 1kV
Cable length: 1m
Colour: black
Conform to the norm: CAT II 1000V; EN 61010
Kind of wire: RG58

Hersteller: ELECTRO-PJP
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 0.4mm2; PVC; double; white; 1000V; 100m; Class: 6
Type of wire: assembly
Kind of core: Cu
Type of insulation: double
CPR standard: no classification
Wire insulation material: PVC
Shield structure: unshielded
Core structure: stranded
Insulation colour: white
Operating temperature: -20...80°C
Core section: 0.4mm²
Cable external diameter: 2mm
Number of cores: 1
Cable structure: 1x0.4mm²
Flexibility class: 6
Package contents: 100m
Rated voltage: 1kV

Hersteller: ELECTRO-PJP
Category: 4mm Banana Plugs
Description: Laboratory connector: 4mm banana; adapter; 10A; 70VDC; black; 52mm
Operating temperature: -25...80°C
Contact plating: nickel plated
Max. contact resistance:: 1mΩ
Overall length: 52mm
Current rating: 10A
Rated voltage: 70V DC
Type of lab connector: 4mm banana
Connector: adapter
Contact material: brass
Cable/adapter structure: banana 2mm socket; banana 4mm plug
Colour: black

Hersteller: ELECTRO-PJP
Category: 4mm Banana Plugs
Description: Laboratory connector: 4mm banana; adapter; 10A; 70VDC; red; 52mm
Operating temperature: -25...80°C
Contact plating: nickel plated
Max. contact resistance:: 1mΩ
Overall length: 52mm
Current rating: 10A
Rated voltage: 70V DC
Type of lab connector: 4mm banana
Connector: adapter
Contact material: brass
Cable/adapter structure: banana 2mm socket; banana 4mm plug
Colour: red

Hersteller: ELECTRO-PJP
Category: Fork plugs
Description: Laboratory connector: fork terminals; 60VDC; 36A; blue; 1mΩ
Max. contact resistance:: 1mΩ
Stud terminal maximal diameter: 6.3mm
Overall length: 49mm
Current rating: 36A
Rated voltage: 60V DC
Type of lab connector: fork terminals
Cable/adapter structure: banana 4mm socket; fork terminal
Colour: blue

Hersteller: ELECTRO-PJP
Category: Fork plugs
Description: Laboratory connector: fork terminals; 60VDC; 36A; yellow; 1mΩ
Max. contact resistance:: 1mΩ
Stud terminal maximal diameter: 6.3mm
Overall length: 49mm
Current rating: 36A
Rated voltage: 60V DC
Type of lab connector: fork terminals
Cable/adapter structure: banana 4mm socket; fork terminal
Colour: yellow

Hersteller: ELECTRO-PJP
Category: Fork plugs
Description: Laboratory connector: fork terminals; 60VDC; 36A; black; 1mΩ
Max. contact resistance:: 1mΩ
Stud terminal maximal diameter: 6.3mm
Overall length: 49mm
Current rating: 36A
Rated voltage: 60V DC
Type of lab connector: fork terminals
Cable/adapter structure: banana 4mm socket; fork terminal
Colour: black

Hersteller: ELECTRO-PJP
Category: Fork plugs
Description: Laboratory connector: fork terminals; 60VDC; 36A; red; Ømax: 6.3mm
Max. contact resistance:: 1mΩ
Stud terminal maximal diameter: 6.3mm
Overall length: 49mm
Current rating: 36A
Rated voltage: 60V DC
Type of lab connector: fork terminals
Cable/adapter structure: banana 4mm socket; fork terminal
Colour: red

Hersteller: ELECTRO-PJP
Category: Fork plugs
Description: Laboratory connector: fork terminals; 60VDC; 36A; green; 1mΩ
Max. contact resistance:: 1mΩ
Stud terminal maximal diameter: 6.3mm
Overall length: 49mm
Current rating: 36A
Rated voltage: 60V DC
Type of lab connector: fork terminals
Cable/adapter structure: banana 4mm socket; fork terminal
Colour: green

Hersteller: ELECTRO-PJP
Category: Probes - Test Plugs
Description: Measuring tip; 1A; 60VDC; 30VAC; black; Tip diameter: 0.6mm
Type of test accessories: measuring tip
Current rating: 1A
Rated voltage: 30V AC; 60V DC
Colour: black
Tip diameter: 0.6mm
Socket size: 4mm
Overall length: 54mm
Blade length: 19mm
Operating temperature: -25...80°C

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 2A; banana socket 4mm,banana plug 4mm; insulated
Contact plating: nickel plated
Conform to the norm: CAT II 1000V; CAT III 1000V; CAT IV 600V; EN 61010
Connector variant: insulated
Wire insulation material: PVC
Type of test accessories: test lead
Operating temperature: -20...80°C
Wire cross-section: 0.75mm²
Cable length: 30m
Current rating: 2A
Rated voltage: 1kV
Test lead configuration: banana plug 4mm; banana socket 4mm
Colour: green
Contact material: brass
Standard equipment: cable reel

Hersteller: ELECTRO-PJP
Category: Single Test Leads
Description: Test lead; 2A; banana socket 4mm,banana plug 4mm; insulated
Contact plating: nickel plated
Conform to the norm: CAT II 1000V; CAT III 1000V; CAT IV 600V; EN 61010
Connector variant: insulated
Wire insulation material: PVC
Type of test accessories: test lead
Operating temperature: -20...80°C
Wire cross-section: 0.75mm²
Cable length: 50m
Current rating: 2A
Rated voltage: 1kV
Test lead configuration: banana plug 4mm; banana socket 4mm
Colour: black
Contact material: brass
Standard equipment: cable reel

Hersteller: ELECTRO-PJP
Steckverbinder, Reihenklemmen > Steckverbindungen Audio, Video (außer HDMI, DVI)
Stecker oder Steckdose: Гніздо
Beschreibung: Гніздо банан червоне на корпус. Гніздо: 4 мм. Довжина: 22мм. Номінальна напруга: 60VDC. Номінальний струм: 36А. Товщина панелі: 4 мм. Розмір монтажного отвору: 8мм.
№ 4: банан
Монтаж: на корпус
Вид роз’ємів: мама

Hersteller: ELECTRO-PJP
Steckverbinder, Reihenklemmen > Steckverbindungen Audio, Video (außer HDMI, DVI)
Stecker oder Steckdose: Штекер
Beschreibung: Штекер банан, чорний 4мм. Довжина загальна: 44,2мм. Напруга/струм 30 VAC/60 VDC
№ 4: банан
Монтаж: на кабель
Вид роз’ємів: тато
