FLKN2-14X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-W FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-24X-L FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-25X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-28X-P FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6 Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM12-FW-1-XX000-N10M2 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7024343BC0E1&compId=FLM12-FW-1-XX000.pdf?ci_sign=84ee5db9d4941adfbfe4c314a9f0d5a5a2c531bb Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST; 1A/250VAC; 2A/36VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 1A / 250V AC
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Leads dimensions: 150mm
Electrical life: 100000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø12mm
Body material: nickel plated brass
Min. insulation resistance: 1GΩ
Body dimensions: Ø14x24.5mm
Operating temperature: -25...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-A11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: OFF-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-A11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-N11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-N11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-S11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-S11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-A11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-A11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-N11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-S11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-S11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FW-1-XX000-A10M2 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C9BA4F01240E1&compId=FLM19-FW-1-XX000.pdf?ci_sign=33a6701ec75b99a59bca8fdb98fc346ff5501e14 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST; 5A/250VAC; 5A/36VDC; IP67
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Leads dimensions: 150mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body material: aluminum alloy
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x25mm
Operating temperature: -25...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM22-FJ-1-XX000-S11M3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949CAB79C01020E1&compId=FLM22-FJ-1-XX000.pdf?ci_sign=fa878592d27c20792141ae92015bab8d6d406f54 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø25x26.2mm
IP rating: IP65
Mounting hole diameter: Ø22mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM22-FJ-1-XX000-S11Z3 FILN pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949CAB79C01020E1&compId=FLM22-FJ-1-XX000.pdf?ci_sign=fa878592d27c20792141ae92015bab8d6d406f54 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø25x26.2mm
IP rating: IP65
Mounting hole diameter: Ø22mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-101EN-8 Green 230V FILN 2 stable positions; ON-OFF; rocker green; LED; 230V; illumination; SPST; 3P; 10A 125VAC; 6A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS101-11g; illuminated; rocker switch; PRZ Mirs101-11g
Anzahl je Verpackung: 10 Stücke
auf Bestellung 200 Stücke:
Lieferzeit 7-14 Tag (e)
20+1.43 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-101EN-8 Red 230V FILN 2 stable positions; ON-OFF; rocker red; LED; 230V; illumination; SPST; 3P; 10A 125VAC; 6A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS101-11r; illuminated; rocker switch; PRZ Mirs101-11r
Anzahl je Verpackung: 10 Stücke
auf Bestellung 187 Stücke:
Lieferzeit 7-14 Tag (e)
20+1.43 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-103-5 FILN 3 stable positions; ON-OFF-ON; cap colour: black; SPDT; 3P; 10A 125VAC or 6A 250VAC; endurance: 10000 cycles; ambient temperature: -25°C+85°C MRS103-9C6b; rocker switch; PRZ MRS1039c6b II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 250 Stücke:
Lieferzeit 7-14 Tag (e)
40+0.83 EUR
Mindestbestellmenge: 40
Im Einkaufswagen  Stück im Wert von  UAH
KCD2-10A FILN 2 stable positions; ON-OFF; cap colour: red; double cap; DPST; 4P; circuit breaker 10A 10A 125VAC / 250VAC; endurance 6000 cycles; ambient temperature: -10°C+85°C RS2R-10A; rocker switch PRZ Rs2r-10A
Anzahl je Verpackung: 10 Stücke
auf Bestellung 100 Stücke:
Lieferzeit 7-14 Tag (e)
10+3.03 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201N-4 Green 230V FILN 2 stable positions; ON-OFF; rocker green illumination; DPST; 4P; 16A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS4201N-4g; illuminated; rocker switch; PRZ MIRS4201N-4g
Anzahl je Verpackung: 10 Stücke
auf Bestellung 145 Stücke:
Lieferzeit 7-14 Tag (e)
10+4.47 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201N-4 White 230V FILN 2 stable positions; ON-OFF; rocker white illumination; DPST; 4P; 16A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS4201N-4w; illuminated; rocker switch; PRZ MIRS4201N-4w
Anzahl je Verpackung: 10 Stücke
auf Bestellung 150 Stücke:
Lieferzeit 7-14 Tag (e)
10+4.47 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201New-4 230V FILN 2 stable positions; ON-OFF; cap colour: silver; DPST; 4P; 20A 125VAC or 16A 250VAC;endurance: 20000 cycles; ambient temperature: -25°C+85°C MRS4201-4s; rocker switch; PRZ MRS4201-4s
Anzahl je Verpackung: 10 Stücke
auf Bestellung 133 Stücke:
Lieferzeit 7-14 Tag (e)
10+2.82 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KW10-FZ4F FILN 5A; 250VAC; OFF-(ON); SPDT; 3P; endurance: 10000 cycles; ambient temperature: -25°C+85°C MSW-15; micro switch; PRZ MSW15
Anzahl je Verpackung: 10 Stücke
auf Bestellung 50 Stücke:
Lieferzeit 7-14 Tag (e)
20+1.42 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KW1-103-3 Black micro switch FILN 16A; 250VAC; OFF-(ON); SPDT; 3P; L=28mm; endurance: 10000 cycles; ambient temperature: -25°C+85°C MSW-02C-28; micro switch; PRZ MSW02c-28
Anzahl je Verpackung: 20 Stücke
auf Bestellung 25 Stücke:
Lieferzeit 7-14 Tag (e)
20+2.64 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdbl 220V FILN 10A; 220VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdbl 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 290 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdbl II FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdbl II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 290 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdg 220V FILN 10A; 220VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdg 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdg II FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdg II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 300 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.13 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdr 220V FILN 10A; 220VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdr 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdr II FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdr II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5bl 12V FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5bl 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 280 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5bl 220V FILN 10A; 220VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5bl 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 270 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5g 12V FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5g 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5g 220V FILN 10A; 220VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5g 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5r 12V FILN 10A; 12VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5r 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 200 Stücke:
Lieferzeit 7-14 Tag (e)
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-14X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-15X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-16X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-17X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 2
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-18X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: SP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x15x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-21X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-22X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 16A/250VAC; 20A/24VDC; on panel
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-23X-W pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 3
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: cables
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-24X-L pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: OFF-(ON)
Illumination: none
Leads: screw terminals
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-25X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPST; (OFF)-ON; 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPST
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (OFF)-ON
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLKN2-28X-P pVersion=0046&contRep=ZT&docId=005056AB281E1FD091A4DCD438C8E0DF&compId=FLKN2%20Toggle%20switch%20Datasheet.pdf?ci_sign=0102bed5c2fe0d7eab85539d96ea5eafc7b16195 pVersion=0046&contRep=ZT&docId=005056AB281E1FD092D47E78124F60E1&compId=Toggle%20Switch%20Selection%20Guide.pdf?ci_sign=b2c8e9a42e7e86e7232ab7194b4455ef05dd69c6
Hersteller: FILN
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; (ON)-OFF-(ON); 16A/250VAC; 20A/24VDC
Type of switch: toggle
Number of positions: 3
Stable positions number: 1
Contacts configuration: DP3T
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 20A / 24V DC
Switching method: (ON)-OFF-(ON)
Illumination: none
Leads: for soldering
Max. contact resistance:: 50mΩ
Mounting hole diameter: Ø12.4mm
Min. insulation resistance: 0.1GΩ
Body dimensions: 29.4x23.5x23.2mm
Mounting: on panel
Contact material: silver alloy
Lever length: 17mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM12-FW-1-XX000-N10M2 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7024343BC0E1&compId=FLM12-FW-1-XX000.pdf?ci_sign=84ee5db9d4941adfbfe4c314a9f0d5a5a2c531bb
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST; 1A/250VAC; 2A/36VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 1A / 250V AC
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Leads dimensions: 150mm
Electrical life: 100000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø12mm
Body material: nickel plated brass
Min. insulation resistance: 1GΩ
Body dimensions: Ø14x24.5mm
Operating temperature: -25...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-A11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: OFF-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-A11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-N11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-N11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-S11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM16-FJ-1-XX000-S11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C7904EE4640E1&compId=FLM16-FJ-1-XX000.pdf?ci_sign=72c9e89e27242ac9f85b58babb5cc2ebda3dab42
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø18x28.1mm
IP rating: IP65
Mounting hole diameter: Ø16mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-A11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-A11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: aluminum alloy
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-N11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: nickel plated brass
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-S11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FJ-1-XX000-S11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C80F0DECD40E1&compId=FLM19-FJ-1-XX000.pdf?ci_sign=1029dd1d1385c8f10d8b2c1a81c502d962607f88
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x26.5mm
IP rating: IP65
Mounting hole diameter: Ø19mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM19-FW-1-XX000-A10M2 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949C9BA4F01240E1&compId=FLM19-FW-1-XX000.pdf?ci_sign=33a6701ec75b99a59bca8fdb98fc346ff5501e14
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST; 5A/250VAC; 5A/36VDC; IP67
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: none
Leads: cables
Leads dimensions: 150mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body material: aluminum alloy
Min. insulation resistance: 1GΩ
Body dimensions: Ø22x25mm
Operating temperature: -25...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM22-FJ-1-XX000-S11M3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949CAB79C01020E1&compId=FLM22-FJ-1-XX000.pdf?ci_sign=fa878592d27c20792141ae92015bab8d6d406f54
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-(ON)
Stable positions number: 1
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø25x26.2mm
IP rating: IP65
Mounting hole diameter: Ø22mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
FLM22-FJ-1-XX000-S11Z3 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0949CAB79C01020E1&compId=FLM22-FJ-1-XX000.pdf?ci_sign=fa878592d27c20792141ae92015bab8d6d406f54
Hersteller: FILN
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 5A/250VAC; 5A/36VDC; IP65
Contacts configuration: SPDT
Operating temperature: -25...85°C
Leads: for soldering
Electrical life: 50000 cycles
Body material: stainless steel
Type of switch: vandal resistant
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 36V DC
Switching method: ON-ON
Stable positions number: 2
Illumination: none
Button shape: flat; round
Number of positions: 2
Mechanical durability: 500000 cycles
Max. contact resistance:: 50mΩ
Min. insulation resistance: 1GΩ
Body dimensions: Ø25x26.2mm
IP rating: IP65
Mounting hole diameter: Ø22mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-101EN-8 Green 230V
Hersteller: FILN
2 stable positions; ON-OFF; rocker green; LED; 230V; illumination; SPST; 3P; 10A 125VAC; 6A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS101-11g; illuminated; rocker switch; PRZ Mirs101-11g
Anzahl je Verpackung: 10 Stücke
auf Bestellung 200 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+1.43 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-101EN-8 Red 230V
Hersteller: FILN
2 stable positions; ON-OFF; rocker red; LED; 230V; illumination; SPST; 3P; 10A 125VAC; 6A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS101-11r; illuminated; rocker switch; PRZ Mirs101-11r
Anzahl je Verpackung: 10 Stücke
auf Bestellung 187 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+1.43 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KCD1-103-5
Hersteller: FILN
3 stable positions; ON-OFF-ON; cap colour: black; SPDT; 3P; 10A 125VAC or 6A 250VAC; endurance: 10000 cycles; ambient temperature: -25°C+85°C MRS103-9C6b; rocker switch; PRZ MRS1039c6b II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 250 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
40+0.83 EUR
Mindestbestellmenge: 40
Im Einkaufswagen  Stück im Wert von  UAH
KCD2-10A
Hersteller: FILN
2 stable positions; ON-OFF; cap colour: red; double cap; DPST; 4P; circuit breaker 10A 10A 125VAC / 250VAC; endurance 6000 cycles; ambient temperature: -10°C+85°C RS2R-10A; rocker switch PRZ Rs2r-10A
Anzahl je Verpackung: 10 Stücke
auf Bestellung 100 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+3.03 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201N-4 Green 230V
Hersteller: FILN
2 stable positions; ON-OFF; rocker green illumination; DPST; 4P; 16A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS4201N-4g; illuminated; rocker switch; PRZ MIRS4201N-4g
Anzahl je Verpackung: 10 Stücke
auf Bestellung 145 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+4.47 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201N-4 White 230V
Hersteller: FILN
2 stable positions; ON-OFF; rocker white illumination; DPST; 4P; 16A 250VAC; endurance: 10000 cycles; operating temperature: -25°C+85°C MIRS4201N-4w; illuminated; rocker switch; PRZ MIRS4201N-4w
Anzahl je Verpackung: 10 Stücke
auf Bestellung 150 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+4.47 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KCD4-201New-4 230V
Hersteller: FILN
2 stable positions; ON-OFF; cap colour: silver; DPST; 4P; 20A 125VAC or 16A 250VAC;endurance: 20000 cycles; ambient temperature: -25°C+85°C MRS4201-4s; rocker switch; PRZ MRS4201-4s
Anzahl je Verpackung: 10 Stücke
auf Bestellung 133 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+2.82 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
KW10-FZ4F
Hersteller: FILN
5A; 250VAC; OFF-(ON); SPDT; 3P; endurance: 10000 cycles; ambient temperature: -25°C+85°C MSW-15; micro switch; PRZ MSW15
Anzahl je Verpackung: 10 Stücke
auf Bestellung 50 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+1.42 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
KW1-103-3 Black micro switch
Hersteller: FILN
16A; 250VAC; OFF-(ON); SPDT; 3P; L=28mm; endurance: 10000 cycles; ambient temperature: -25°C+85°C MSW-02C-28; micro switch; PRZ MSW02c-28
Anzahl je Verpackung: 20 Stücke
auf Bestellung 25 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+2.64 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdbl 220V
Hersteller: FILN
10A; 220VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdbl 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 290 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdbl II
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdbl II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 290 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdg 220V
Hersteller: FILN
10A; 220VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdg 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdg II
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdg II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 300 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.13 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdr 220V
Hersteller: FILN
10A; 220VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdr 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101E8cdr II
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS-101E-8C/D automotive switch PRZ Mirs101E8cdr II
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5bl 12V
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5bl 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 280 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5bl 220V
Hersteller: FILN
10A; 220VDC; ON-OFF; single pole; SPST; 3P; blue lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5bl 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 270 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5g 12V
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5g 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 230 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5g 220V
Hersteller: FILN
10A; 220VDC; ON-OFF; single pole; SPST; 3P; green lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5g 220V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
PRZ Mirs101n-5r 12V
Hersteller: FILN
10A; 12VDC; ON-OFF; single pole; SPST; 3P; red lamp; endurance: 10000 cycles; ambient temperature: -25°C+85°C MIRS101n-5 automotive switch PRZ Mirs101n-5r 12V
Anzahl je Verpackung: 10 Stücke
auf Bestellung 200 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
30+1.18 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 2 3 4  [ Nächste Seite >> ]
