Hersteller: Fluke
Environmental Test Equipment KIT WITH FLUKE-62MAX+/T+PRO/1AC / C115 SOFTCASE

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: infrared window; IP55; Ø100mm; -40÷232°C
Type of test accessories: infrared window
IP rating: IP55
Operating temperature: -40...232°C
Dimensions: Ø100mm
Conform to the norm: IEC 60068-2-6

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,75 digit (6000); True RMS AC
Type of meter: digital multimeter
Measurement: AC current; AC voltage; DC current; DC voltage; frequency; resistance
Kind of display used: LCD
Display parameters: 3,75 digit (6000)
DC voltage measuring range: 0.1...600mV; 6V; 60V; 600V
DC voltage measuring accuracy: ±(0.5% + 2 digit)
AC voltage measuring range: 0.1...600mV; 6V; 60V; 600V
AC voltage measuring accuracy: ±(1% + 2 digit)
DC current measuring range: 1mA...6A; 10A; 20A < 30s
DC current measuring accuracy: ±(1% + 3 digit)
AC current measuring range: 1mA...6A; 10A; (20A <30s)
AC current measuring accuracy: ±(1.5% + 3 digit)
True effective value measurement: True RMS AC
Resistance measuring range: 100mΩ...600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 40MΩ
Capacitance measuring range: 1nF...1µF; 10µF; 100µF; 9.999mF
Frequency measuring range: 10mHz...99.99Hz; 999.9Hz; 9.999kHz; 50kHz
Frequency measuring accuracy: ±(0.1%+2 digit)
Resistance measuring accuracy: ±(0.9%+1 digit)
Diode test: 1.2mA @2.7V
Continuity test: acoustic indication; <20Ω
Power supply: battery 6LR61 9V x1
Standard equipment: digital multimeter FLK-115; FLK-TL75 test leads; FLK-TLK225 set
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 84x167x46mm
Measuring instrument features: auto and manual ranging; HOLD function; low battery indicator; MIN/MAX/MEDIUM function; removable holster
Battery/ rechargeable battery: battery 6LR61 9V x1
Optional equipment: FLK-80BK-A drop-like K-type probe; FLK-80PJ-EXT drop-like J-type probe; FLK-C25 soft cover; FLK-C50 soft cover; FLK-TL175 test leads; FLK-TLK289 accessory set; FLK-TOOLPAK strap with magnet for suspending the meter; Set of FLK-MC6 clothes; set of test leads with probes FLK-TL910; test leads FLK-TL71; test leads FLK-TL76; test leads FLK-TL224 SureGrip; test leads FLK-TL-222
Manufacturer series: Fluke 110
Bargraph: 33 segm. 32x/s
Pollution degree: 2
Weight with battery: 550g

Hersteller: FLUKE
Description: FLUKE - FLK-1507/323 KIT - Kit, Isolationswiderstandsmesser & Strommesszange
Hauptprodukt 2: Echteffektiv-Strommesszange Fluke 323
Hauptprodukt 1: Isolationswiderstandsmesser Fluke 1507
Lieferumfang des Kits: Isolationswiderstandsmesser Fluke 1507, Echteffektiv-Strommesszange 323
Produktpalette: -
SVHC: No SVHC (15-Jan-2018)

Hersteller: FLUKE
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; RCD test: general purpose; FLK-1660
Manufacturer series: FLK-1660
Kind of display used: LCD
Illumination: yes
Body dimensions: 100x250x125mm
AC voltage measuring range: 100mV...500V
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Earthing resistance measuring accuracy: ±(2% + 5 digit)
Test voltage: 100V; 250V; 500V; 1kV
Insulation resistance measuring ranges: 10kΩ...100MΩ; 200MΩ; 500MΩ; 1GΩ
Standard equipment: 3 crocodile clips; carrying strap; FLK-C1600 - tool chest; test leads; test mains cable; test probe FLK-TP165X; TL-L1 red test lead; TL-L2 blue test lead; TL-L2 green test lead; user's manual
Measurement: AC voltage; frequency; insulation resistance; RCD tripping current; RCD tripping time
Type of meter: appliance meter
Power supply: battery LR6 AA 1,5V x6
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Measuring instrument features: checks conductors polarization
Connectors for the country: Europe
Related items: FLK-C1600; FLK-TP165X
RCD test: general purpose

Hersteller: FLUKE
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 200÷1000VAC; IP40
Measuring instrument features: AutoTest function; optical (LED) and acoustic indication of detected voltage; set of 5 detectors
Power supply: battery LR03 AAA 1,5V x2
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Conform to the norm: CAT IV 1000V; EN 61010
IP rating: IP40
Type of tester: non-contact voltage detector
Detected voltage range: 200...1000V AC

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; Software: Fluke View Forms
Standard equipment: cable for connection with PC; crocodile clips FLK-AC72; digital multimeter FLK-289; FLK-80BK-A drop-like K-type probe; FLK-IR3000FC; FLK-TL175 test leads; holder for probes; magnetic hanging strap FLK-TOOLPAK; soft cover FLK-C280
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5899A; POM-6173A; POM-7519A
Type of meter: digital multimeter
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Software: Fluke View Forms

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; Bluetooth; LCD; VDC: 600mV,6V,60V,600V,1kV
Type of meter: digital multimeter
Kind of display used: LCD
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 50MΩ
Resistance measuring accuracy: ±(0.5%+1 digit)
Measuring instrument features: 20m range; auto and manual ranging; automatic power-off; HOLD function; impact resistant holster; indicates incorrect connection of test leads; MIN/MAX/MEDIUM function
Standard equipment: crocodile clips FLK-AC175; FLK-TL175 test leads
Power supply: battery LR6 AA 1,5V x3
Software: compatible Android; Fluke Connect
IP rating: IP54
True effective value measurement: True RMS
Capacitance measuring range: 1µF; 10µF; 100µF; 9.999mF
DC current measuring range: 60mA; 400mA
AC current measuring range: 60mA; 400mA
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
Frequency measuring range: 9.999Hz; 99.99Hz; 999.9Hz; 99.99kHz
Diode test: 2V
Frequency measuring accuracy: ±(0.1%+1 digit)
DC voltage measuring accuracy: ±(0.09% + 2 digit)
Dimensions (W x H x D): 93x207x48mm
DC current measuring accuracy: ±(0.5% + 3 digit)
AC voltage measuring accuracy: ±(1% + 3 digit)
AC current measuring accuracy: ±(1.5% + 3 digit)
Capacitance measuring accuracy: ±(1.2%+ 2 digit)
Weight with battery: 340g
Related items: FLK-A3001FC-KITCAR; POM-5677B; POM-5899A; POM-7519A
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; frequency; resistance
Continuity test: acoustic indication
Battery/ rechargeable battery: battery LR6 AA 1,5V x3
Interface: Bluetooth
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter
Standard equipment: FLK-3000FC wireless multimeter; FLK-C35 soft cover; manual (CD); test leads FLK-TL-224; test probes FLK-AC280 SureGrip; test probes FLK-TL910
Related items: POM-5677B; POM-5899A; POM-7519A
Type of meter: digital multimeter
Battery/ rechargeable battery: battery LR6 AA 1,5V x3

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: multifunction; VAC accuracy: ±(1%+5digit); VAC: 600V,1kV
Type of meter: multifunction
Kind of display used: LCD
Resistance measuring range: 600Ω; 6kΩ; 60kΩ
Resistance measuring accuracy: ±(1%+5 digit)
Measuring instrument features: AUTO HOLD; automatic power-off; flexible current probe up to 2500A; HOLD function; MIN/MAX/AVG function; polarization indicator
Standard equipment: case; FLK-IRR1-SOL meter; iFlex2500-18 - current clamp; magnetic hanging strap; test leads ( 2pcs.); test leads MC4
Power supply: battery LR6 AA 1,5V x2
Dimensions: 281x84x49mm
Software: Fluke Connect
True effective value measurement: True RMS
Illumination: yes
Capacitance measuring range: 0.1...100µF; 1mF
DC current measuring range: 100mA...999.9A
AC current measuring range: 100mA...999.9A
DC voltage measuring range: 600V; 1.5kV
AC voltage measuring range: 600V; 1kV
Frequency measuring range: 5...500Hz
Frequency measuring accuracy: ±(0.5%+5 digit)
Max. diameter of measured cable: 34mm
DC voltage measuring accuracy: ±(1% + 5 digit)
DC current measuring accuracy: ±(2% + 5 digit)
AC voltage measuring accuracy: ±(1% + 5 digit)
AC current measuring accuracy: ±(2% + 5 digit)
Capacitance measuring accuracy: ±(1%+ 5 digit)
Pollution degree: 2
Weight with battery: 520g
CF crest factor: 1.42k @ 2.5kA; 2.5k @ 600A; 3k @ 1.1kA
Measurement: AC current; AC voltage; capacitance; continuity; current (with current clamps); DC current; DC voltage; frequency; inrush current; peak current; resistance
Kind of meter: AC/DC pincers type; digital
Continuity test: acoustic indication; <30Ω
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Interface: Bluetooth
Conform to the norm: CAT III 1500V; CAT IV 600V; EN 61010

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: multifunction; VAC accuracy: ±(1%+5digit); VAC: 600V,1kV
Type of meter: multifunction
Kind of display used: LCD
Resistance measuring range: 600Ω; 6kΩ; 60kΩ
Resistance measuring accuracy: ±(1%+5 digit)
Measuring instrument features: AUTO HOLD; automatic power-off; flexible current probe up to 2500A; HOLD function; MIN/MAX/AVG function; polarization indicator
Standard equipment: case; iFlex2500-18 - current clamp; magnetic hanging strap; test leads ( 2pcs.); test leads MC4
Power supply: battery LR6 AA 1,5V x2
Dimensions: 281x84x49mm
Software: Fluke Connect
True effective value measurement: True RMS
Illumination: yes
Capacitance measuring range: 0.1...100µF; 1mF
DC current measuring range: 100mA...999.9A
AC current measuring range: 100mA...999.9A
DC voltage measuring range: 600V; 1.5kV
AC voltage measuring range: 600V; 1kV
Frequency measuring range: 5...500Hz
Frequency measuring accuracy: ±(0.5%+5 digit)
Max. diameter of measured cable: 34mm
DC voltage measuring accuracy: ±(1% + 5 digit)
DC current measuring accuracy: ±(2% + 5 digit)
AC voltage measuring accuracy: ±(1% + 5 digit)
AC current measuring accuracy: ±(2% + 5 digit)
Capacitance measuring accuracy: ±(1%+ 5 digit)
Pollution degree: 2
Weight with battery: 520g
CF crest factor: 1.42k @ 2.5kA; 2.5k @ 600A; 3k @ 1.1kA
Measurement: AC current; AC voltage; capacitance; continuity; current (with current clamps); DC current; DC voltage; frequency; inrush current; peak current; resistance
Kind of meter: AC/DC pincers type; digital
Continuity test: acoustic indication; <30Ω
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Interface: Bluetooth
Conform to the norm: CAT III 1500V; CAT IV 600V; EN 61010

Hersteller: FLUKE
Category: Calibrators
Description: Meter: calibrator; pressure; VDC: 0÷30V; I DC: 0÷24mA; -0.9÷40bar
Type of meter: calibrator
Software: DPCTrack2
Related items: FLK-PMM-200K; FLK-PMM-200KA; FLK-PMM-2000K; FLK-PMM-4000K
Kind of calibrator: pressure
Battery/ rechargeable battery: rechargeable battery Li-Ion 14,4V x1
Power supply: rechargeable battery Li-Ion x1
Temperature measuring range: -50...150°C
Pressure measuring range: -0.9...40bar
DC current measuring range: 0...24mA
DC voltage measuring range: 0...30V
Current measuring resolution: 1µA
Voltage measuring resolution: 1mV DC
Temperature measurement resolution: 0.01°C
Dimensions: 290x215x100mm
Producer guarantee (months): 36
Standard equipment: 2 crocodile clips; adapter AC-DC; carrying strap; connection hose; coupler set; mains cable; manufacturer's calibration certificate; pressure measurement module; test leads; test probes FLK-AC280 SureGrip; test probes FLK-TP220; USB A / USB B-mini cable
Measurement: 4-20mA current loop; DC current; DC voltage; pressure; temperature
Measuring instrument features: 24V loop supply voltage; datalogging; HART communication; measure, source and simulate current in mA; modular construction

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: digital multimeter; VAC accuracy: ±(0.7%+4digit); IP67
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-4408; POM-5519A; POM-5673B
Type of meter: digital multimeter
Measuring instrument features: auto and manual ranging; automatic power-off; built-in thermometer; filter ensuring voltage and frequency measuring accuracy; HOLD function; impact resistant holster; indicates incorrect connection of test leads; MIN/MAX/MEDIUM function; PEAK HOLD function; test leads resistance compensation
Battery/ rechargeable battery: battery LR6 AA 1,5V x3
Power supply: battery LR6 AA 1,5V x3
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
IP rating: IP67
Kind of display used: LCD
True effective value measurement: True RMS AC
Illumination: yes
Temperature measuring range: -200...1090°C
AC current measuring range: 0.1...600µA; 6mA; 60mA; 400mA; 6A; 10A; (20A <30s)
AC voltage measuring range: 0.1...600mV; 6V; 60V; 600V; 1kV
DC voltage measuring range: 0.1...600mV; 6V; 60V; 600V; 1kV
Capacitance measuring range: 10pF...10nF; 100nF; 1µF; 10µF; 100µF; 9.999mF
Conductance measurement: 0.01...60nS
DC current measuring range: 0.1...600µA; 6mA; 60mA; 400mA; 6A; 10A; 20A < 30s
Diode test: 1mA @3V
Frequency measuring accuracy: ±(0.005%+1 digit)
Frequency measuring range: 10mHz...199.99Hz; 1999.9Hz; 19.999kHz; 199.99kHz
DC voltage measuring accuracy: ±(0.05% + 1 digit)
Dimensions (W x H x D): 63x198x100mm
Temperature measurement resolution: 0.1°C
Resistance measuring range: 100mΩ...600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 50MΩ
Resistance measuring accuracy: ±(0.2%+1 digit)
DC current measuring accuracy: ±(0.2% + 4 digit)
AC voltage measuring accuracy: ±(0.7% + 4 digit)
AC current measuring accuracy: ±(1% + 2 digit)
Capacitance measuring accuracy: ±(1%+ 2 digit)
Temperature measurement accuracy: ±(1% + 10 digit)
Conductance measuring accuracy: ±(1% + 10digit)
Bargraph: 33 segm. 40x/s
Weight with battery: 700g
Standard equipment: crocodile clip FLK-AC175 x2; FLK-80BK-A drop-like K-type probe; FLK-TL175 test leads; test leads MC4
Optional equipment: 400A AC/DC FLK-I410 current clamp probe; FLK-C25 soft cover; FLK-TL238 set; FLK-TOOLPAK strap with magnet for suspending the meter
Display parameters: (6000/20000)
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication

Hersteller: FLUKE
Category: Meters and AC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Features: 20m range
Max. diameter of measured cable: 34mm
AC current measuring range: 400A
Measurement: AC current
Power supply: battery LR6 AA 1,5V x2
Interface: Bluetooth
Conform to the norm: CAT III 600V; EN 61010
Software: Fluke Connect
Kind of meter: digital; pincers type
IP rating: IP30
Kind of display used: LCD
True effective value measurement: True RMS AC
Body dimensions: 75x36x203mm
AC current measuring accuracy: ±(2% + 5 digit)
Weight with battery: 220g
Measurement memory: 65000
Display parameters: 3,5 digit
Measuring instrument features: 20m range
Type of meter: multifunction
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: FLUKE
Category: Multimeters - Sets
Description: Measuring kit: multimeters
Standard equipment: case; crocodile clip FLK-AC175 x2; FLK-TL175 test leads; user's manual
Kit contents: FLK-3000FC wireless multimeter; FLK-A3000FC clamp meter
Type of measuring kit: multimeters
Battery/ rechargeable battery: battery LR6 AA 1,5V x5

Hersteller: FLUKE
Category: Multimeters - Sets
Description: Measuring kit: multimeters
Standard equipment: case; clamp meter FLK-A3001FC; crocodile clip FLK-AC175 x2; FLK-3000FC wireless multimeter; FLK-I2500-10 flexible current probe; FLK-TL175 test leads; user's manual
Related items: FLK-A3001FC-KITCAR
Type of measuring kit: multimeters
Battery/ rechargeable battery: battery LR6 AA 1,5V x5

Hersteller: FLUKE
Category: Meters and AC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Features: 20m range
Type of meter: multifunction
Related items: FLK-A3001FC-KITCAR
Software: Fluke Connect
IP rating: IP42
True effective value measurement: True RMS AC
AC current measuring range: 500mA...2.5kA
Dimensions: 165x64x14mm
Current measuring resolution: 0.1A
Max. diameter of measured cable: 254mm
AC current measuring accuracy: ±(3% + 5 digit)
Measurement memory: 65000
Display parameters: 3,5 digit
Measuring instrument features: 20m range
Interface: Bluetooth
Measurement: AC current
Power supply: battery LR6 AA 1,5V x2
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Kind of display used: LCD
Kind of meter: digital; pincers type

Hersteller: FLUKE
Category: Meters and AC/DC Clamp Probes
Description: Meter: AC/DC current module; LCD; 3,5 digit; I DC: 400A,1kA; IP42
DC current measuring range: 400A; 1kA
AC current measuring range: 400A; 600A
Measurement: AC current; DC current
Related items: FLK-I410; FLK-I1010
Power supply: battery LR6 AA 1,5V x2
Interface: Bluetooth
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Connect
IP rating: IP42
Kind of display used: LCD
Dimensions: 160x66x38mm
Measurement memory: 65000
Display parameters: 3,5 digit
Measuring instrument features: 20m range
Type of meter: AC/DC current module

Hersteller: FLUKE
Category: Clamp Meters - Others
Description: Meter: ammeter; digital,pincers type; LCD; 3,5 digit; Øcable: 64mm
Max. diameter of measured cable: 64mm
Measurement: DC current
Power supply: battery LR6 AA 1,5V x2
Interface: Bluetooth
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Connect
Kind of meter: digital; pincers type
IP rating: IP42
Kind of display used: LCD
Body dimensions: 165x14x635mm
Weight with battery: 650g
Display parameters: 3,5 digit
Measuring instrument features: transfer measurement data wireless
Type of meter: ammeter
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: FLUKE
Category: Clamp Meters - Others
Description: Meter: current loop; pincers type; LCD; 3,5 digit; IP42; 4.5mm
Measurement: 4-20mA current loop
Power supply: battery LR6 AA 1,5V x2
Software: Fluke Connect
Kind of meter: pincers type
IP rating: IP42
Kind of display used: LCD
Operating temperature: -10...50°C
Jaw capacity: 4.5mm
Dimensions: 165x635x356mm
Signal measurements: 0-20,99mA (0,01mA resolution, accuracy: 0,2% + 5 digits); 21-99,9mA (0,1mA resolution, accuracy: 1% + 5 digits)
Measurement memory: 65000
Display parameters: 3,5 digit
Measuring instrument features: datalogging; transfer measurement data wireless
Type of meter: current loop

Hersteller: FLUKE
Category: Bags & Soft Cases
Description: Cover
Type of test accessories: cover
Related items: FLK-A3001FC; FLK-A3002FC; FLK-A3003FC; FLK-A3004FC; FLK-V3000FC; FLK-V3001FC

Hersteller: FLUKE
Description: FLUKE - FLK-DS701 - Videoskop, 800 x 600 Pixel, 1X-8X, 8.5mm
Auflösung: 800 x 600 Pixel
Vergrößerung: 1x bis 8x
Ausgangsanschluss: USB
Kamerakopf-Durchmesser: 8.5
Produktpalette: -
SVHC: No SVHC (15-Jan-2018)

Hersteller: FLUKE
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; 68°; Cam.res: 1200x720; 6GB
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 1200x720
IP rating: IP54; IP68 (probe)
Power supply: rechargeable battery Li-Ion 3,7V x1
Measuring instrument features: automatic image orientation; digital zoom x8; dual view camera, from forward and side of the probe; LED for measurement spot illumination
Standard equipment: battery charger/power supply; hand strap; HDMI cable; magnetic hanging strap; neckstrap; soft case; USB cable
Interface: WiFi
Resistance to: fall from 2m height
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Supported formats: AVI; JPEG
Connection: HDMI; USB
Touchpad: yes
Probe diameter: 8.5mm
Dimensions: 173.3x224.8mm
Cable length: 1.2m
Viewing angle: 68°
Weight with battery: 880g
Memory capacity: 6GB
Software: Fluke Connect

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Test acces: test cable; 250/430V
Measuring instruments application: for electric vehicle charging station type 2
Max. input voltage: 250/430V
Type of test accessories: test cable

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Measuring kit: set of testers for network installation; 10A
Standard equipment: 3 crocodile clips; appliance meter FLK-1664FC-SCH; carrying strap; case; test cable FLK-FEV300-CON-TY2; test leads; test mains cable; test probe FLK-TP165X; TL-L1 red test lead; TL-L2 blue test lead; TL-L2 green test lead
Conform to the norm: CAT II 300V; EN 61010
Measuring instruments application: for electric vehicle charging station type 3
Colour: yellow-black
Max. input voltage: 250/430V
Maximum current: 10A
Dimensions (W x H x D): 110x45x220mm
Operating temperature: 0...40°C
Test: CP: simulating various charging states; PP cable; protective conductor PE
Measuring instrument features: measuring terminals L1, L2, L3, N and PE; separate phase indication by 3 LED; simulation of CP error "E"; simulation of PE error "Earth fault"
Type of measuring kit: set of testers for network installation

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: test adapter kit; yellow-black; 250/430V; 10A; 0÷40°C
Operating temperature: 0...40°C
Max. input voltage: 250/430V
Standard equipment: case; test cable FLK-FEV300-CON-TY1; test cable FLK-FEV300-CON-TY2
Conform to the norm: CAT II 300V; EN 61010
Test: CP: simulating various charging states; PP cable; protective conductor PE
Type of meter: test adapter kit
Measuring instruments application: for electric vehicle charging station type 3
Measuring instrument features: measuring terminals L1, L2, L3, N and PE; separate phase indication by 3 LED; simulation of CP error "E"; simulation of PE error "Earth fault"
Colour: yellow-black
Dimensions (W x H x D): 110x45x220mm
Maximum current: 10A

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: test adapter kit; yellow-black; 250/430V; 10A; 0÷40°C
Type of meter: test adapter kit
Standard equipment: case; test cable FLK-FEV300-CON-TY2
Conform to the norm: CAT II 300V; EN 61010
Measuring instruments application: for electric vehicle charging station type 3
Colour: yellow-black
Max. input voltage: 250/430V
Maximum current: 10A
Dimensions (W x H x D): 110x45x220mm
Operating temperature: 0...40°C
Test: CP: simulating various charging states; PP cable; protective conductor PE
Measuring instrument features: measuring terminals L1, L2, L3, N and PE; separate phase indication by 3 LED; simulation of CP error "E"; simulation of PE error "Earth fault"

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: EV Charging Station Analyzer; IP40; Display: LCD; 1A
Type of meter: EV Charging Station Analyzer
Kind of display used: LCD
Standard equipment: adapter FLK-ZEROADAPTER/T2; carrying case; magnetic strap; test cable FLK-FEV300-CON-TY2
Measuring instruments application: for electric vehicle charging station type 3
IP rating: IP40
Colour: yellow-black
Operating temperature: -10...40°C
Dimensions (W x H x D): 263x123x63mm
Maximum current: 1A
Max. input voltage: 230/400V; 250V
Test: 30 mA RCD + 6 mA RDC-DD trip test; CP: simulating various charging states; PP cable; protective conductor PE
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Power supply: battery LR6 AA 1,5V x4
Conform to the norm: CAT II 300V; EN 61010
Related items: FLK-ZEROADAPTER/T2

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: EV Charging Station Analyzer; IP40; Display: LCD; 1A
Type of meter: EV Charging Station Analyzer
Standard equipment: adapter FLK-ZEROADAPTER/T2; carrying case; magnetic strap; test cable FLK-FEV300-CON-TY2
Conform to the norm: CAT II 300V; EN 61010
IP rating: IP40
Related items: FLK-ZEROADAPTER/T2
Kind of display used: LCD
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Measuring instruments application: for electric vehicle charging station type 3
Power supply: battery LR6 AA 1,5V x4
Colour: yellow-black
Max. input voltage: 230/400V; 250V
Maximum current: 1A
Dimensions (W x H x D): 263x123x63mm
Software: Trutest
Operating temperature: -10...40°C

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: EV Charging Station Analyzer; IP40; Display: LCD; 1A
IP rating: IP40
Operating temperature: -10...40°C
Max. input voltage: 230/400V; 250V
Standard equipment: adapter FLK-ZEROADAPTER/T1; adapter FLK-ZEROADAPTER/T2; carrying case; magnetic strap; test adapter FLK-FEV300/TY1; test adapter FLK-FEV300/TY2
Power supply: battery LR6 AA 1,5V x4
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Conform to the norm: CAT II 300V; EN 61010
Type of meter: EV Charging Station Analyzer
Related items: FLK-ZEROADAPTER/T1; FLK-ZEROADAPTER/T2
Measuring instruments application: for electric vehicle charging station type 3
Kind of display used: LCD
Colour: yellow-black
Dimensions (W x H x D): 263x123x63mm
Maximum current: 1A

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: EV Charging Station Analyzer; IP40; Interface: USB C,WiFi
Type of meter: EV Charging Station Analyzer
Standard equipment: Fluke Premium Care- 1 year; test probe FLK-TP165X; USB cable
Conform to the norm: IEC 61557-8; IEC 61557-18
Measuring instrument features: autotest with PASS/FAIL results; safe simulation of a 2 kW load
IP rating: IP40
Kind of display used: LCD TFT 7"; touch screen
Measuring instruments application: for testing fast charging stations for electric vehicles with direct current
Interface: USB C; WiFi
Power supply: rechargeable battery Li-Ion 10,8V 6800mAh x1
Maximum current: 10A
Dimensions (W x H x D): 650x508x300mm
Operating temperature: -20...50°C

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: solar power; Meas.accur: ±(5% + 5 digits); Temp: -30÷100°C
Power supply: battery LR61 AA 1,5V x4
Battery/ rechargeable battery: battery LR61 AA 1,5V x4
Measuring instruments application: for solar panels; photovoltaics
Additional functions: inclination sensor; integrated compass; temperature sensor
IP rating: IP40
Kind of display used: LCD
Type of meter: solar power
Temperature measuring range: -30...100°C
Temperature measurement resolution: 0.1°C
Body dimensions: 150x80x35mm
Temperature measurement accuracy: ±1°C
Weight with battery: 231g
Measuring range: 0...1400W/m2
Measuring resolution: 1W/m2
Measurement accuracy: ±(5% + 5 digits)
Standard equipment: shoulder strap; soft case FLK-C250; temperature probe FLK-80PR-IRR

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: solar power; Meas.accur: ±(5% + 5 digits); Temp: -30÷100°C
Interface: Bluetooth
Power supply: battery LR61 AA 1,5V x4
Battery/ rechargeable battery: battery LR61 AA 1,5V x4
Measuring instruments application: for solar panels; photovoltaics
Additional functions: inclination sensor; integrated compass; temperature sensor
IP rating: IP40
Kind of display used: LCD
Type of meter: solar power
Temperature measuring range: -30...100°C
Temperature measurement resolution: 0.1°C
Body dimensions: 150x80x35mm
Temperature measurement accuracy: ±1°C
Weight with battery: 231g
Measuring range: 0...1400W/m2
Measuring resolution: 1W/m2
Measurement accuracy: ±(5% + 5 digits)
Standard equipment: shoulder strap; soft case FLK-C250; temperature probe FLK-80PR-IRR

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: wide-angle lens
Related items: FLK-TI200/9HZ; FLK-TI300/9HZ; FLK-TI400/9HZ
Type of test accessories: wide-angle lens
Field of observation: 46° horizontal x 34° vertical

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 120x90; -20÷150°C; Focus: focus free
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 120x90
Temperature measuring range: -20...150°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 50° horizontal x 38° vertical
IP rating: IP54
Body dimensions: 89x127x25mm
Power supply: rechargeable battery Li-Ion 3,7V x1
Measuring instrument features: AutoBlend function; compact design; IR-Fusion function to combine thermal and real images; multilanguage menu; picture-in-picture (PIP) function; radiometric measurements for detailed temperature analysis; transfer measurement data wireless
Standard equipment: case; hand strap; USB cable
Interface: WiFi
Resistance to: fall from 1m height
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 320x240
Supported formats: IS2; JPG
Touchpad: yes
Three-dimensional resolution: 7.6mrad
Optical resolution: 130:1
Weight with battery: 233g
Focusing: focus free
Software: Fluke Connect

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Measuring kit: photovoltaic system analyzer; photovoltaics
Measuring instrument features: multifunction
Measurement: AC current; AC voltage; DC current; DC voltage; insulation resistance; open-circuit voltage; protective conductor resistance; short-circuit current
Related items: FLK-TRUTEST-ADV; FLK-TRUTEST-LITE
Power supply: battery LR6 AA 1,5V x6
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Application: photovoltaics
Type of measuring kit: photovoltaic system analyzer
Storage temperature: -30...60°C
Operating temperature: 0...50°C
Dimensions: 100x250x125mm
Standard equipment: adapter; analyzer; backpack; carrying case; carrying strap; coupler set; FLK-I100 - current clamp; fuses; magnetic catch; mounting holder; remotely controlled probe TP1000; solar irradiance meter FLK-IRR2-BT; temperature probe FLK-80PR-IRR; test lead on reel TL1000/30M; test leads TL1000; test leads TL1000-MC4; test probe x1; USB cable

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Measuring kit: photovoltaic system analyzer; photovoltaics
Measuring instrument features: multifunction
Measurement: AC current; AC voltage; DC current; DC voltage; insulation resistance; open-circuit voltage; protective conductor resistance; short-circuit current
Related items: FLK-TRUTEST-ADV; FLK-TRUTEST-LITE
Power supply: battery LR6 AA 1,5V x6
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Application: photovoltaics
Type of measuring kit: photovoltaic system analyzer
Storage temperature: -30...60°C
Operating temperature: 0...50°C
Dimensions: 100x250x125mm
Standard equipment: adapter; analyzer; backpack; carrying case; carrying strap; coupler set; FLK-I100 - current clamp; fuses; magnetic catch; mounting holder; PVLEAD3 Solar PV Clamp Test Lead Set; remotely controlled probe TP1000; solar irradiance meter FLK-IRR2-BT; temperature probe FLK-80PR-IRR; test lead on reel TL1000/30M; test leads TL1000; test leads TL1000-MC4; test probe x1; USB cable
Software: Trutest

Hersteller: FLUKE
Category: Temperature Meters
Description: Meter: temperature; digital; LCD; 3,5 digit; -200÷1372°C; IP42
Temperature measurement accuracy: ±(0.5% + 0.3°C)
Display parameters: 3,5 digit
Measurement memory: 65000
Measuring instrument features: 20m range
Power supply: battery LR6 AA 1,5V x2
Interface: Bluetooth
Kind of meter: digital
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA
Software: Fluke Connect
IP rating: IP42
Standard equipment: K-type temperature probe; magnetic hanging strap
Kind of display used: LCD
Type of meter: temperature
Measurement: temperature
Temperature measuring range: -200...1372°C
Dimensions: 165x64x36mm

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: accu pack; 2.5h; 7.4V
Type of test accessories: accu pack
Related items: FLK-TI32; FLK-TIR32
Body dimensions: 124x58.4x42.4mm
Charge time: 2.5h
Rated voltage: 7.4V

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: stand mount
Type of test accessories: stand mount
Related items: FLK-TI100; FLK-TI110; FLK-TI125; FLK-TIR110; FLK-TIR125

Hersteller: FLUKE
Description: FLUKE - FLK-TI401 PRO 9HZ - Wärmebildkamera, -20 °C, 650 °C, 640 x 480, 0.075 °C, 34° x 24°, 150 mm
Temperaturempfindlichkeit (NETD): 0.075
Sichtfeld (H x V): 34° x 24°
IR-Fokusabstand, min.: 150
IR-Auflösung: 640 x 480
Temperatur, max.: 650
Bildaufnahmefrequenz: 9
Temperatur, min.: -20
Herstellergewährleistung: 2 Jahre
Produktpalette: -
SVHC: No SVHC (15-Jan-2019)

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 120x90; -20÷400°C; Focus: FocusFree
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 120x90
Temperature measuring range: -20...400°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 50° horizontal x 38° vertical
IP rating: IP54
Power supply: rechargeable battery Li-Ion x1
Measuring instrument features: adjustable emissivity; AutoBlend function; IR-Fusion function to combine thermal and real images; wireless communication with PC
Standard equipment: battery charger; case; power supply; USB cable
Thermal sensitivity (NETD): 60mK
Interface: USB; WiFi
Resistance to: fall from 2m height
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
Display resolution: 320x240
Measurement: temperature
Three-dimensional resolution: 7.6mrad
Dimensions: 26.7x10.1x14.5mm
Focusing: FocusFree
Measuring unit: °C; °F

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 256x192; -20÷550°C; Focus: manual; IP54
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 256x192
Temperature measuring range: -20...550°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 28° horizontal x 20° vertical
IP rating: IP54
Power supply: rechargeable battery Li-Ion x1
Measuring instrument features: adjustable emissivity; AutoBlend function; colour alarms; IR-Fusion function to combine thermal and real images; radiometric measurements for detailed temperature analysis; voice and text message recorder; wide palette of colours; wireless communication with PC
Standard equipment: 4GB SD memory card; carrying strap; case; hard case; power supply; USB cable
Thermal sensitivity (NETD): 40mK
Interface: LAN; USB; WiFi
Resistance to: fall from 2m height
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
Display resolution: 320x240
Supported formats: BMP; GIF; IS2; JPEG; PNG; TIFF
Measurement: temperature
Touchpad: yes
Operating temperature: -10...50°C
Three-dimensional resolution: 1.91mrad
Dimensions: 267x101x145mm
Focusing: manual
Measuring unit: °C; °F
Software: download from manufacturers website; Fluke Connect

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 384x288; -20÷550°C; Focus: manual; IP54
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 384x288
Temperature measuring range: -20...550°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 42° horizontal x 30° vertical
IP rating: IP54
Power supply: rechargeable battery Li-Ion x1
Measuring instrument features: adjustable emissivity; AutoBlend function; colour alarms; IR-Fusion function to combine thermal and real images; radiometric measurements for detailed temperature analysis; voice and text message recorder; wide palette of colours; wireless communication with PC
Standard equipment: battery charger; carrying strap; case; hard case; microSD 4GB memory card; power supply; USB cable
Thermal sensitivity (NETD): 40mK
Interface: LAN; USB; WiFi
Resistance to: fall from 2m height
Related items: FLK-TI-SBP3
Display resolution: 320x240
Supported formats: BMP; GIF; IS2; IS3; JPEG; PNG; TIFF
Measurement: temperature
Touchpad: yes
Operating temperature: -10...50°C
Three-dimensional resolution: 1.91mrad
Dimensions: 267x101x145mm
Focusing: manual
Measuring unit: °C; °F
Software: download from manufacturers website; Fluke Connect

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Adapter USB; Interface: WiFi
Interface: WiFi
Type of test accessories: adapter USB
Related items: FLK-1738FTP-KIT

Hersteller: Fluke
Thermal Imaging Cameras INFRARED WIDE ANGLE LENS

Hersteller: Fluke
Thermal Imaging Cameras 3 IN (75MM) C-RANGE IR WINDOW, KWIK TWIST

Hersteller: Fluke
Thermal Imagers IR WINDOW 3INCH 75MM INDOOR MEDIUMVOLTAGE

Hersteller: Fluke
Thermal Imaging Cameras IR WINDOW 3INCH 75MM INDOOR LOW VOLTAGE

Hersteller: Fluke
Thermal Imaging Cameras 4 IN (100MM) C-RANGE IR WINDOW, KWIK TWIST

Hersteller: Fluke
FLK-100-CLKT-DEMO

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY FROM 3 TO 5 YEARS

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY 3-5 W / ANNUAL TRACE CAL

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY FROM 3 TO 5 YEARS

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY 3-5 W / ANNUAL TRACE CAL

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY FROM 3 TO 5 YEARS

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY 3-5 W / ANNUAL TRACE CAL

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY FROM 3 TO 5 YEARS

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY 3-5 W / ANNUAL TRACE CAL

Hersteller: Fluke
Calibration, Warranties, & Service Plans EXTENDS WARRANTY FROM 3 TO 5 YEARS
