Produkte > GW INSTEK > Alle Produkte des Herstellers GW INSTEK (486) > Seite 7 nach 9

Hersteller: GW INSTEK
Category: LCR Meter
Description: Test acces: test lead; Structure: tweezers
Related items: LCR-1010; LCR-1100
Type of test accessories: test lead
Test lead configuration: tweezers
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Category: LCR Meter
Description: Test acces: measuring adapter
Related items: LCR-6002; LCR-6020; LCR-6100; LCR-6200; LCR-6300; LCR-8101G; LCR-8110G; LCR-8205; LCR-8210; LCR-8220; LCR-8230
Type of test accessories: measuring adapter
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Category: LCR Meter
Description: LCR meter; LCD 3,5"; 1E-05÷99.999MΩ; 1E-05pF÷9999.99mF; LCR-6000
Type of meter: LCR meter
Kind of display used: LCD 3,5"
Resistance measuring range: 1E-05...99.999MΩ
Capacitance measuring range: 1E-05pF...9999.99mF
Measurement: capacitance; inductance; resistance
Inductance measuring range: 1E-05µH...9999.99H
Dimensions: 265x107x312mm
Standard equipment: four-wire Kelvin clips; mains cable
Measurement frequency: 10Hz...2kHz
Supply voltage: 100...240V AC
Manufacturer series: LCR-6000
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - LCR-6002 (CE) - LCR-Messgerät, Tischgerät, 2 kHz, 9.99999 kH, 10 F, 99.9999 Mohm, LCR-6000 Series
tariffCode: 90303370
Messwert Kapazität, max.: 10F
rohsCompliant: Y-EX
hazardous: false
rohsPhthalatesCompliant: YES
Messwert Induktivität, max.: 9.99999kH
isCanonical: Y
usEccn: 3A992.a
Gerätetyp: Tischgerät
Messwert Widerstand, max.: 99.9999Mohm
euEccn: NLR
Prüffrequenz, max.: 2kHz
Produktpalette: LCR-6000 Series
productTraceability: No
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: LCR Meter
Description: LCR meter; LCD 3,5"; 1E-05÷99.999MΩ; 1E-05pF÷9999.99mF; LCR-6000
Type of meter: LCR meter
Kind of display used: LCD 3,5"
Resistance measuring range: 1E-05...99.999MΩ
Capacitance measuring range: 1E-05pF...9999.99mF
Measurement: capacitance; inductance; resistance
Inductance measuring range: 1E-05µH...9999.99H
Dimensions: 265x107x312mm
Standard equipment: four-wire Kelvin clips; mains cable
Measurement frequency: 10Hz...20kHz
Supply voltage: 100...240V AC
Manufacturer series: LCR-6000
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - LCR-6020 (CE).. - LCR-Messgerät, Tischgerät, 20 kHz, 9.99999 kH, 10 F, 99.9999 Mohm, LCR-6000 Series
tariffCode: 90303370
productTraceability: No
rohsCompliant: Y-EX
Prüffrequenz, max.: 20kHz
euEccn: NLR
Gerätetyp: Tischgerät
hazardous: false
Messwert Induktivität, max.: 9.99999kH
Messwert Widerstand, max.: 99.9999Mohm
rohsPhthalatesCompliant: YES
Messwert Kapazität, max.: 10F
usEccn: 3A992.a
Produktpalette: LCR-6000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: LCR Meter
Description: LCR meter; LCD 3,5"; 1E-05÷99.999MΩ; 1E-05pF÷9999.99mF; LCR-6000
Type of meter: LCR meter
Kind of display used: LCD 3,5"
Resistance measuring range: 1E-05...99.999MΩ
Capacitance measuring range: 1E-05pF...9999.99mF
Measurement: capacitance; inductance; resistance
Inductance measuring range: 1E-05µH...9999.99H
Dimensions: 265x107x312mm
Standard equipment: four-wire Kelvin clips; mains cable
Measurement frequency: 10Hz...100kHz
Supply voltage: 100...240V AC
Manufacturer series: LCR-6000
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - LCR-6100 (CE).. - LCR-Messgerät, Tischgerät, 100 kHz, 9.99999 kH, 10 F, 99.9999 Mohm, LCR-6000 Series
tariffCode: 90303370
Messwert Kapazität, max.: 10F
rohsCompliant: Y-EX
hazardous: false
rohsPhthalatesCompliant: YES
Messwert Induktivität, max.: 9.99999kH
isCanonical: Y
usEccn: 3A992.a
Gerätetyp: Tischgerät
Messwert Widerstand, max.: 99.9999Mohm
euEccn: NLR
Prüffrequenz, max.: 100kHz
Produktpalette: LCR-6000 Series
productTraceability: No
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - LCR-6300 (CE).. - LCR-Messgerät, Tischgerät, 300 kHz, 9.99999 kH, 10 F, 99.9999 Mohm, LCR-6000 Series
tariffCode: 90303370
productTraceability: No
rohsCompliant: Y-EX
Prüffrequenz, max.: 300kHz
euEccn: NLR
Gerätetyp: Tischgerät
isCanonical: Y
hazardous: false
Messwert Induktivität, max.: 9.99999kH
Messwert Widerstand, max.: 99.9999Mohm
rohsPhthalatesCompliant: YES
Messwert Kapazität, max.: 10F
usEccn: 3A992.a
Produktpalette: LCR-6000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - LCR-8205 (CE) - LCR-Messgerät, Tischgerät, 5 MHz, 9999.99 kH, 9999.99 F, 99.9999 Mohm, LCR-8200 Series
tariffCode: 90303380
productTraceability: No
rohsCompliant: Y-EX
Prüffrequenz, max.: 5MHz
euEccn: NLR
Gerätetyp: Tischgerät
isCanonical: Y
hazardous: false
Messwert Induktivität, max.: 9999.99kH
Messwert Widerstand, max.: 99.9999Mohm
rohsPhthalatesCompliant: YES
Messwert Kapazität, max.: 9999.99F
usEccn: 3A992.a
Produktpalette: LCR-8200 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: LCR Meter
Description: Test acces: test lead
Related items: LCR-914; LCR-915; LCR-916
Type of test accessories: test lead
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 70MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel)
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 70MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 70MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 70MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 70MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel)
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 70MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 70MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 70MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 100MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 100MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 100MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 100MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 100MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel)
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 100MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 100MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 100MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 100MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel)
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 100MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 100MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 100MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 200MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 200MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 200MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 200MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 200MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 200MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 200MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel)
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 200MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 4; 200MHz; 1Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000E
Time base: 1n...100s/div
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 4
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 10Mpts/ch
Band: 200MHz
Sampling: 1Gsps (in real time)
Measuring instrument features: 20 sets memory; banana socket x2; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; laboratory power supply function; multimeter; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 300MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 300MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 300MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 300MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: arbitrary waveform generator; spectrum analyzer

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; MDO; Ch: 2; 100MHz; 2Gsps (in real time)
Interface: Go/NoGo BNC; LAN; USB 2.0 host; USB device
Trigger modes: automatic; normal; single
Standard equipment: cable BNC-BNC x2; mains cable; oscilloscope probe (1 per channel); test leads; test leads with crocodile clips
Type of oscilloscope: digital
Kind of display used: LCD TFT 8"
Kind of oscilloscope: MDO
Manufacturer series: MDO-2000A
Time base: 1n...100s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 384x208x127.3mm
Supply voltage: 100...240V AC
Number of channels: 2
Vertical resolution: 8bit
Measurement memory: 24
Max. input voltage: 300V
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Memory record length: 20Mpts/ch
Band: 100MHz
Sampling: 2Gsps (in real time)
Measuring instrument features: 20 sets memory; EF function - electrical field detecion; mask testing; mathematical functions: addition, subtraction, division, multiplication and FFT; segmented memory function; support I2C, SPI, UART, CAN, LIN BUS trigger and decoding functions; Y-T, X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC, GND
Trigger: alternative; bus; falling-edge; glitch; rising-edge; runt; video signal; with delay
Additional functions: spectrum analyzer
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - MDO-2102EX - Oszilloskop, MSO / MDO, MDO-2000E, 2 Kanäle, 100 MHz, 1 GSPS, 10Mpts, 3.5 ns
tariffCode: 90302000
productTraceability: No
Oszilloskopkanäle: 2 Kanäle
rohsCompliant: YES
Lieferumfang des Kits: Digitales Speicheroszilloskop, Kurzanleitung, Handbuch auf CD, Netzkabel, 2 BNC-BNC-Kabel, Messleitung mit Krokodilklemme, Messleitung mit Bananenstecker, umschaltbarer passiver Tastkopf.
euEccn: NLR
hazardous: false
rohsPhthalatesCompliant: TBA
Oszilloskopanzeige: WVGA-TFT-Farbanzeige
usEccn: 3A992.a
Herstellergewährleistung: 3 Jahre
Produktpalette: MDO-2000E
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MDO-2204EG - Oszilloskop, MSO / MDO, MDO-2000E Series, 4 Kanäle, 200 MHz, 1 GSPS, 10Mpts, 1.75 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: Digitales Speicheroszilloskop, Kurzanleitung, Handbuch auf CD, Netzkabel.
Berechnete Anstiegszeit: 1.75ns
hazardous: false
rohsPhthalatesCompliant: YES
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): 10Mpts
usEccn: 3A992.a
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: MDO-2000E Series
Bandbreite: 200MHz
productTraceability: No
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: WVGA-TFT-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Generators and Frequency Meters
Description: Laboratory generator: arbitrary, function; 200MHz; Ch: 2; 16kpts
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 200MHz
Waveform frequency range: 1µHz...5MHz (triangle waveform); 1µHz...60MHz (rectangular waveform); 1µHz...200MHz (arbitrary waveform); 1µHz...200MHz (sinus waveform)
Kind of display used: colour; LCD 4,3"
Number of channels: 2
Memory record length: 16kpts
Vertical resolution: 14bit
Dimensions: 266x107x293mm
Interface: LAN; USB
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM; SUM
Waveforms: arbitrary; burst; impulse; ramp; rectangular; sinus; sweep; triangle
Sampling: 250Msps
Standard equipment: BNC-BNC cable; mains cable; test leads ( 2pcs.); user's manual
Software: included
Manufacturer series: MFG-2000
Supply voltage: 100...240V AC
Output parameters: impedance: 50Ω

Hersteller: GW INSTEK
Category: Generators and Frequency Meters
Description: Laboratory generator: arbitrary, function; 30MHz; Ch: 2; 16kpts
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 30MHz
Waveform frequency range: 1µHz...1MHz (triangle waveform); 1µHz...25MHz (rectangular waveform); 1µHz...30MHz (arbitrary waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: colour; LCD 4,3"
Number of channels: 2
Vertical resolution: 14bit
Output parameters: impedance: 50Ω
Dimensions: 266x107x293mm
Interface: LAN; USB
Kind of modulation: AM; FM; FSK; PM; PWM; SUM
Waveforms: arbitrary; burst; impulse; ramp; rectangular; sinus; sweep; triangle
Sampling: 200Msps
Standard equipment: test leads ( 2pcs.)
Supply voltage: 100...240V AC
Memory record length: 16kpts
Manufacturer series: MFG-2000
Software: included

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2110 - Funktionsgenerator, Arbiträr, Impuls, 1 Kanal, 10MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: -
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 10MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2120 - Funktionsgenerator, Arbiträr, Impuls, 1 Kanal, 20MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: -
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 20MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2120MA - Funktionsgenerator, Arbiträr, Impuls, 1 Kanal, 20MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 20MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2130M - Funktionsgenerator, Arbiträr, Impuls, 1 Kanal, 30MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 30MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2160MF - Funktionsgenerator, Arbiträr, Impuls, HF, 1 Kanal, 60MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträrgenerator, Funktionsgenerator, Impulsgenerator, HF-Generator
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: YES
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: TBA
usEccn: 3A992.a
Bandbreite: 60MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2160MR - Funktionsgenerator, Arbiträr, Impuls, HF, 1 Kanal, 60MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträrgenerator, Funktionsgenerator, Impulsgenerator, HF-Generator
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 1 Kanal
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 60MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2220HM - FUNKTIONSGENERATOR, 2 KANÄLE, 200MHZ
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM, SUM
productTraceability: No
Anzahl der Kanäle: 2 Kanäle
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 200MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Generators and Frequency Meters
Description: Laboratory generator: arbitrary, function; 200MHz; Ch: 2; 16kpts
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 200MHz
Waveform frequency range: 1µHz...5MHz (triangle waveform); 1µHz...60MHz (rectangular waveform); 1µHz...200MHz (arbitrary waveform); 1µHz...200MHz (sinus waveform)
Kind of display used: colour; LCD 4,3"
Number of channels: 2
Memory record length: 16kpts
Vertical resolution: 14bit
Dimensions: 266x107x293mm
Interface: LAN; USB
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM; SUM
Waveforms: arbitrary; burst; impulse; ramp; rectangular; sinus; sweep; triangle
Sampling: 250Msps
Standard equipment: BNC-BNC cable; mains cable; test leads ( 2pcs.); user's manual
Software: included
Manufacturer series: MFG-2000
Supply voltage: 100...240V AC
Output parameters: impedance: 50Ω
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2230M - Funktionsgenerator, Arbiträr, Impuls, 2 Kanäle, 30MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 2 Kanäle
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 30MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Generators and Frequency Meters
Description: Laboratory generator: arbitrary, function; 30MHz; Ch: 2; 16kpts
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 30MHz
Waveform frequency range: 1µHz...1MHz (triangle waveform); 1µHz...25MHz (rectangular waveform); 1µHz...30MHz (arbitrary waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: colour; LCD 4,3"
Number of channels: 2
Vertical resolution: 14bit
Output parameters: impedance: 50Ω
Dimensions: 266x107x293mm
Interface: LAN; USB
Kind of modulation: AM; FM; FSK; PM; PWM; SUM
Waveforms: arbitrary; burst; impulse; ramp; rectangular; sinus; sweep; triangle
Sampling: 200Msps
Standard equipment: test leads ( 2pcs.)
Supply voltage: 100...240V AC
Memory record length: 16kpts
Manufacturer series: MFG-2000
Software: included
Anzahl je Verpackung: 1 Stücke

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2260M - Funktionsgenerator, Arbiträr, Impuls, 2 Kanäle, 60MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträr, Funktion, Impuls
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 2 Kanäle
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 60MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2260MFA - Funktionsgenerator, Arbiträr, Impuls, HF, 2 Kanäle, 60MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträrgenerator, Funktionsgenerator, Impulsgenerator, HF-Generator
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 2 Kanäle
rohsCompliant: YES
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: TBA
usEccn: 3A992.a
Bandbreite: 60MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MFG-2260MRA - Funktionsgenerator, Arbiträr, Impuls, HF, 2 Kanäle, 60MHz, Produktreihe MFG2000
tariffCode: 90308900
Signalgeber: Arbiträrgenerator, Funktionsgenerator, Impulsgenerator, HF-Generator
Modulation Signalgenerator: AM, ASK, FM, FSK, PM, PSK, PWM
productTraceability: No
Anzahl der Kanäle: 2 Kanäle
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
usEccn: 3A992.a
Bandbreite: 60MHz
Herstellergewährleistung: 1 Jahr
Produktpalette: MFG-2000 Series
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MPO-2102B - Digitales Oszilloskop, MPO-2000 Series, 2 Kanäle, 100 MHz, 1 GSPS, 3.5 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: MPO-2102B, Tastkopf GTP-100B-4, 2x Kabel GTL-110, Messleitung GTL-105A/GTL-207, Netzkabel, Kalibrierzertifikat
Berechnete Anstiegszeit: 3.5ns
hazardous: false
rohsPhthalatesCompliant: YES
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): -
usEccn: 3A992.g
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: MPO-2000 Series
Bandbreite: 100MHz
productTraceability: No
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MPO-2104B - Digitales Oszilloskop, MPO-2000 Series, 4 Kanäle, 100 MHz, 1 GSPS, 3.5 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: MPO-2104B, Tastkopf GTP-100B-4, 2x Kabel GTL-110, Messleitung GTL-105A/GTL-207, Netzkabel, Kalibrierzertifikat
Berechnete Anstiegszeit: 3.5ns
hazardous: false
rohsPhthalatesCompliant: YES
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): -
usEccn: 3A992.g
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: MPO-2000 Series
Bandbreite: 100MHz
productTraceability: No
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: WVGA-TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MPO-2202P - Digitales Oszilloskop, MPO-2000 Series, 2 Kanäle, 200 MHz, 1 GSPS, 1.75 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: MPO-2202P, 2x Kabel GTL-110, Messleitung GTL-105A/GTL-207, passiver Tastkopf, Netzkabel, Kalibrierzertifikat
Berechnete Anstiegszeit: 1.75ns
hazardous: false
rohsPhthalatesCompliant: TBA
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): -
usEccn: 3A992.g
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: MPO-2000 Series
Bandbreite: 200MHz
productTraceability: No
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - MPO-2204P - Digitales Oszilloskop, MPO-2000 Series, 4 Kanäle, 200 MHz, 1 GSPS, 1.75 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: MPO-2204P, 2x Kabel GTL-110, Messleitung GTL-105A/GTL-207, passiver Tastkopf, Netzkabel, Kalibrierzertifikat
Berechnete Anstiegszeit: 1.75ns
hazardous: false
rohsPhthalatesCompliant: TBA
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): -
usEccn: 3A992.g
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: MPO-2000 Series
Bandbreite: 200MHz
productTraceability: No
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: WVGA-TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Accessories - Others
Description: Rackmount
Related items: PEL-2002A; PEL-2004A; PEL-2020A; PEL-2030A; PEL-2040A; PEL-2041A
Type of test accessories: rackmount

Hersteller: GW INSTEK
Category: Electronic Loads
Description: Electronic load; PEL-2000B; 435x20x581mm; Display: LCD TFT
Dimensions: 435x20x581mm
Manufacturer series: PEL-2000B
Interface: GPIB; LAN; RS232; RS485; USB B
Kind of display used: LCD TFT
Type of meter: electronic load
Operating modes: constant current; constant power; constant resistance; constant voltage
Display resolution: 320x240
Related items: GTL-120; GTL-121; GTL-232; GTL-246; GTL-248; GTL-249; PEL-002

Hersteller: GW INSTEK
Category: Electronic Loads
Description: Electronic load; 0÷80V; 40A; 250W; PEL-2000A; dual channels
Manufacturer series: PEL-2000A
Supply voltage: 100...240V AC
Interface: GPIB (option); RS232; USB
Optional equipment: PEL-002
Operating voltage: 0...80V
Operating current: 40A
Maximum power: 250W
Kind of module: dual channels
Type of meter: electronic load

Hersteller: GW INSTEK
Description: GW INSTEK - PEL-3031E - Elektronische DC-Last, PEL-3000E, 300 W, Programmierbar, 1 V, 150 V, 60 A
DC-Last: Programmierbar
Produktpalette: PEL-3000E
SVHC: No SVHC (17-Jan-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - PEL-3032E - Elektronische DC-Last, PEL-3000E, 300 W, Programmierbar, 2.5 V, 500 V, 15 A
DC-Last: Programmierbar
Produktpalette: PEL-3000E
SVHC: No SVHC (17-Jan-2022)

Hersteller: GW INSTEK
Category: Electronic Loads
Description: Electronic load; 0÷150V; 0÷600A; 9kW; PEL-5000G; 177x440x745mm
Interface: GPIB (option); LAN (option); RS232 (option); USB (option)
Kind of display used: LCD
Measuring instrument features: Turbo Mode Function
Operating voltage: 0...150V
Operating current: 0...600A
Dimensions: 177x440x745mm
Supply voltage: 100...240V AC
Maximum power: 9kW
Operating modes: constant current; constant power; constant resistance; constant voltage
Type of meter: electronic load
Manufacturer series: PEL-5000G

Hersteller: GW INSTEK
Description: GW INSTEK - PFR-100L - Labornetzteil, USB, RS232/RS485, Programmierbar, 1 Ausgang, 0 V, 50 V, 0 A, 10 A
Anzahl der Ausgänge: 1 Ausgang
Stromversorgungsausgang: Programmierbar
Produktpalette: PFR-100
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - PFR-100M - Labornetzteil, USB, RS232/RS485, Programmierbar, 1 Ausgang, 0 V, 250 V, 0 A, 2 A
tariffCode: 85044095
rohsCompliant: Y-EX
Ausgangsspannung, min.: 0V
Ausgangsspannung, max.: 250V
hazardous: false
rohsPhthalatesCompliant: YES
Anzahl der Ausgänge: 1 Ausgang
Nennleistung: 100W
isCanonical: Y
usEccn: EAR99
Netzsteckertyp: -
Versorgungsspannung, min.: 85V
Herstellergewährleistung: -
euEccn: NLR
Ausgangsstrom, max.: 2A
Stromversorgungsausgang: Programmierbar
Produktpalette: PFR-100 Series
productTraceability: No
Ausgangsstrom, min.: 0A
Versorgungsspannung, max.: 265V
SVHC: No SVHC (10-Jun-2022)
