M22-2010546 M22-2010546 Harwin Inc. M22-201.pdf Description: CONN HEADER VERT 5POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole
Number of Positions: 5
Number of Rows: 1
Style: Board to Board
Operating Temperature: -55°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.134" (3.40mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.331" (8.40mm)
Insulation Material: Polyamide (PA6T), Nylon 6T
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 454 Stücke:
Lieferzeit 10-14 Tag (e)
28+0.63 EUR
33+ 0.54 EUR
100+ 0.42 EUR
Mindestbestellmenge: 28
M22-2020205 M22-2020205 Harwin Inc. M22-202.pdf Description: CONN HEADER VERT 4POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole
Number of Positions: 4
Number of Rows: 2
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.134" (3.40mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.331" (8.40mm)
Insulation Material: Polyamide (PA6T), Nylon 6T
Row Spacing - Mating: 0.079" (2.00mm)
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 6691 Stücke:
Lieferzeit 10-14 Tag (e)
28+0.65 EUR
32+ 0.57 EUR
100+ 0.44 EUR
500+ 0.38 EUR
1000+ 0.31 EUR
5000+ 0.27 EUR
Mindestbestellmenge: 28
M80-5101605 M80-5101605 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: DATAMATE J-TEK DIL MALE VERTICAL
Produkt ist nicht verfügbar
G125-MV10605L0R G125-MV10605L0R Harwin Inc. G125-MVXXX05LXR.pdf Description: CONN HEADER VERT 6POS 1.25MM
Features: Board Lock, Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Header
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
Produkt ist nicht verfügbar
G125-MV10605L0R G125-MV10605L0R Harwin Inc. G125-MVXXX05LXR.pdf Description: CONN HEADER VERT 6POS 1.25MM
Features: Board Lock, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 230 Stücke:
Lieferzeit 10-14 Tag (e)
2+9.45 EUR
10+ 8.59 EUR
100+ 7.56 EUR
Mindestbestellmenge: 2
G125-MV10605M1P G125-MV10605M1P Harwin Inc. G125-MV1XX05M1P.pdf Description: CONN HEADER VERT 6POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 47 Stücke:
Lieferzeit 10-14 Tag (e)
1+21.75 EUR
10+ 19.28 EUR
G125-MV12605M3P G125-MV12605M3P Harwin Inc. Harwin_Datasheet-Gecko-Signal.pdf Description: CONN HEADER VERT 26POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 26
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 38 Stücke:
Lieferzeit 10-14 Tag (e)
1+33.84 EUR
10+ 29.34 EUR
G125-MV11005M1P G125-MV11005M1P Harwin Inc. G125-MV1XX05M1P.pdf Description: CONN HEADER VERT 10POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 10
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 32 Stücke:
Lieferzeit 10-14 Tag (e)
1+22.19 EUR
10+ 19.68 EUR
G125-FV11005F2P G125-FV11005F2P Harwin Inc. C125XX_G125_Gecko_Connectors.pdf Description: CONN RCPT 10POS 0.049 GOLD PCB
Features: Pick and Place, Polarizing Key
Packaging: Strip
Connector Type: Receptacle
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 10
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.25mm, 7.33mm
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.207" (5.25mm)
Row Spacing - Mating: 0.049" (1.25mm)
Number of Rows: 2
auf Bestellung 8 Stücke:
Lieferzeit 10-14 Tag (e)
1+42.26 EUR
M80-5125042 M80-5125042 Harwin Inc. M80-512.pdf Description: CONN HEADER SMD 50POS 2MM
Features: Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Packaging: Tube
Connector Type: Header
Voltage Rating: 800V
Current Rating (Amps): 2.2A
Mounting Type: Surface Mount
Number of Positions: 50
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Threaded
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Circular
Insulation Height: 0.234" (5.95mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyphenylene Sulfide (PPS), Glass Filled
Row Spacing - Mating: 0.079" (2.00mm)
auf Bestellung 20 Stücke:
Lieferzeit 10-14 Tag (e)
1+35.01 EUR
12+ 30.65 EUR
G125-FS10605F1P G125-FS10605F1P Harwin Inc. Harwin_Datasheet-Gecko-Signal.pdf Description: CONN RCPT 6POS 0.049 GOLD SMD
Features: Jackscrews, Pick and Place, Polarizing Key
Packaging: Bulk
Connector Type: Receptacle
Current Rating (Amps): 2A
Mounting Type: Surface Mount
Number of Positions: 6
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Insulation Height: 0.207" (5.25mm)
Row Spacing - Mating: 0.049" (1.25mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M22-2031005 M22-2031005 Harwin Inc. C018XX_M22_Series_Connectors.pdf Description: CONN HEADER R/A 10POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole, Right Angle
Number of Positions: 10
Number of Rows: 1
Style: Board to Board
Operating Temperature: -55°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.079" (2.00mm)
Shrouding: Unshrouded
Insulation Material: Polyamide (PA6T), Nylon 6T
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 1084 Stücke:
Lieferzeit 10-14 Tag (e)
13+1.37 EUR
16+ 1.16 EUR
100+ 1.04 EUR
500+ 0.85 EUR
1000+ 0.76 EUR
Mindestbestellmenge: 13
M80-8430745 M80-8430745 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: CONN HEADER R/A 7POS 2MM
Produkt ist nicht verfügbar
M80-7930745 Harwin Inc. M80-793_Dwg.pdf Description: CONN HEADER R/A 7POS 2MM
Produkt ist nicht verfügbar
M80-8230745 Harwin Inc. M80-823_Dwg.pdf Description: CONN HEADER VERT 7POS 2MM
Produkt ist nicht verfügbar
M55-7012042R M55-7012042R Harwin Inc. C047XX_M55_Archer_Kontrol.pdf Description: CONN HEADER SMD 20POS 1.27MM
Features: Board Guide, Pick and Place, Solder Retention
Packaging: Tape & Reel (TR)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.325" (8.25mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 1350 Stücke:
Lieferzeit 10-14 Tag (e)
450+2 EUR
900+ 1.94 EUR
1350+ 1.71 EUR
Mindestbestellmenge: 450
M55-7012042R M55-7012042R Harwin Inc. C047XX_M55_Archer_Kontrol.pdf Description: CONN HEADER SMD 20POS 1.27MM
Features: Board Guide, Pick and Place, Solder Retention
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.325" (8.25mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 1948 Stücke:
Lieferzeit 10-14 Tag (e)
6+3.08 EUR
10+ 2.69 EUR
100+ 2.4 EUR
Mindestbestellmenge: 6
G125-MH23405L2R G125-MH23405L2R Harwin Inc. C125XX_G125_Gecko_Connectors.pdf Description: CONN HDR R/A 34POS
Produkt ist nicht verfügbar
M80-7931745 Harwin Inc. M80-793_Dwg.pdf Description: CONN HEADER R/A 17POS 2MM
Produkt ist nicht verfügbar
M80-8231745 Harwin Inc. M80-823_Dwg.pdf Description: CONN HEADER VERT 17POS 2MM
Produkt ist nicht verfügbar
M80-8431745 Harwin Inc. Harwin_PC_Datamate.pdf Description: CONN HEADER R/A 17POS 2MM
Produkt ist nicht verfügbar
Z80-044F Z80-044F Harwin Inc. Z80-044F.pdf Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 36 Stücke:
Lieferzeit 10-14 Tag (e)
1+40.69 EUR
5+ 38.42 EUR
10+ 36.16 EUR
25+ 35.03 EUR
Z80-044C Z80-044C Harwin Inc. Z80-044C-044D.pdf Description: TOOL INSERT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Insertion Tool Tip
Part Status: Active
auf Bestellung 451 Stücke:
Lieferzeit 10-14 Tag (e)
1+42.1 EUR
5+ 39.76 EUR
10+ 37.42 EUR
25+ 36.25 EUR
Z80-044D Z80-044D Harwin Inc. Z80-044C-044D.pdf Description: TOOL INSERT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Insertion Tool Tip
Part Status: Active
auf Bestellung 441 Stücke:
Lieferzeit 10-14 Tag (e)
1+33.3 EUR
5+ 31.45 EUR
10+ 29.6 EUR
25+ 28.68 EUR
Z80-044G Z80-044G Harwin Inc. Z80-044G.pdf Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 447 Stücke:
Lieferzeit 10-14 Tag (e)
1+41.82 EUR
5+ 39.48 EUR
10+ 37.16 EUR
25+ 36 EUR
Z80-044E Z80-044E Harwin Inc. Z80-044E.pdf Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 423 Stücke:
Lieferzeit 10-14 Tag (e)
1+37.89 EUR
5+ 35.79 EUR
10+ 33.69 EUR
25+ 32.64 EUR
M50-3140845R M50-3140845R Harwin Inc. M50-314.pdf Description: CONN RCPT 8POS 0.05 GOLD SMD
Features: Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Receptacle
Voltage Rating: 500VAC
Current Rating (Amps): 1A
Mounting Type: Surface Mount
Number of Positions: 8
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.134" (3.40mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M50-3140845R M50-3140845R Harwin Inc. M50-314.pdf Description: CONN RCPT 8POS 0.05 GOLD SMD
Features: Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Receptacle
Voltage Rating: 500VAC
Current Rating (Amps): 1A
Mounting Type: Surface Mount
Number of Positions: 8
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.134" (3.40mm)
Number of Rows: 1
auf Bestellung 739 Stücke:
Lieferzeit 10-14 Tag (e)
7+2.52 EUR
10+ 2.2 EUR
100+ 1.96 EUR
500+ 1.64 EUR
Mindestbestellmenge: 7
M50-3602742 Harwin Inc. Description: CONN HEADER SMD 54POS 1.27MM
Produkt ist nicht verfügbar
M50-3602742P Harwin Inc. Description: CONN HEADER SMD 54POS 1.27MM
Produkt ist nicht verfügbar
M80-7534445 M80-7534445 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: CONN HEADER VERT 44POS 2MM
Produkt ist nicht verfügbar
M55-8001242-0300A M55-8001242-0300A Harwin Inc. M55-800.pdf Description: CBL ASSEM 1.27MM 12POS F-F 300MM
Features: Latch Lock, Polarizing Key
Packaging: Bulk
Connector Type: Socket to Socket
Contact Finish: Gold
Color: Gray, Ribbon
Length: 0.984' (300.00mm, 11.81")
Shielding: Unshielded
Number of Positions: 12
Number of Rows: 2
Cable Termination: IDC
Pitch - Cable: 0.025" (0.64mm)
Pitch - Connector: 0.050" (1.27mm)
auf Bestellung 33 Stücke:
Lieferzeit 10-14 Tag (e)
1+33.99 EUR
10+ 29.76 EUR
25+ 28.48 EUR
M80-4000000FC-03-PF2-00-000 Harwin Inc. Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M55-7102042R M55-7102042R Harwin Inc. M55-710.pdf Description: CONN HEADER SMD R/A 20POS 1.27MM
Packaging: Tape & Reel (TR)
Features: Board Guide, Solder Retention
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount, Right Angle
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.165" (4.20mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
600+2.06 EUR
1200+ 1.76 EUR
1800+ 1.7 EUR
3000+ 1.65 EUR
Mindestbestellmenge: 600
M55-7102042R M55-7102042R Harwin Inc. M55-710.pdf Description: CONN HEADER SMD R/A 20POS 1.27MM
Features: Board Guide, Solder Retention
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount, Right Angle
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.165" (4.20mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 3921 Stücke:
Lieferzeit 10-14 Tag (e)
6+3.19 EUR
10+ 2.76 EUR
100+ 2.47 EUR
Mindestbestellmenge: 6
M80-8391822 Harwin Inc. M80-839_obsolete.pdf Description: CONN HEADER R/A 18POS 2MM
Produkt ist nicht verfügbar
G125-MV13405M2P G125-MV13405M2P Harwin Inc. G125-MV1XX05M2P.pdf Description: CONN HEADER VERT 34POS 1.25MM
Packaging: Bulk
Features: Mating Flange, Mounting Flange, Pick and Place
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 34
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Threaded
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 14 Stücke:
Lieferzeit 10-14 Tag (e)
1+22.04 EUR
10+ 19.53 EUR
M80-8182022R Harwin Inc. Description: CONNECTOR
Produkt ist nicht verfügbar
M80-8182022P Harwin Inc. Description: CONNECTOR
Produkt ist nicht verfügbar
M20-7863646P Harwin Inc. M20_Series_Spec.pdf Description: CONN RCPT 36POS 0.1 TIN SMD
Packaging: Tube
Features: Pick and Place
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863642 Harwin Inc. M20_Series_Spec.pdf Description: CONN RCPT 36POS 0.1 GOLD SMD
Packaging: Tube
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863642P Harwin Inc. M20_Series_Spec.pdf Description: CONN RCPT 36POS 0.1 GOLD SMD
Packaging: Tube
Features: Pick and Place
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863646 Harwin Inc. M20_Series_Spec.pdf Description: CONN RCPT 36POS 0.1 TIN SMD
Packaging: Tube
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M80-8242645 Harwin Inc. M80-824_Dwg.pdf Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M80-7542645 M80-7542645 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M50-3152742P Harwin Inc. Description: CONN RCPT 54POS 0.05 GOLD SMD
Produkt ist nicht verfügbar
M50-3152742 Harwin Inc. Description: CONN RCPT 54POS 0.05 GOLD SMD
Produkt ist nicht verfügbar
M22-6340442R Harwin Inc. Description: CONN RCPT 8POS 0.079 GOLD SMD
Produkt ist nicht verfügbar
M80-6811042 M80-6811042 Harwin Inc. M80-681.pdf Description: CONN RCPT 10POS 0.079 GOLD SMD
Packaging: Tube
Connector Type: Receptacle
Voltage Rating: 120V
Mounting Type: Surface Mount
Number of Positions: 10
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Locking Ramp
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.85mm, 8.45mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.220" (5.60mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
auf Bestellung 195 Stücke:
Lieferzeit 10-14 Tag (e)
1+18.94 EUR
18+ 16.79 EUR
108+ 14.64 EUR
M80-6811442 M80-6811442 Harwin Inc. Harwin_Datasheet-Datamate-Signal.pdf Description: CONN RCPT 14POS 0.079 GOLD SMD
Packaging: Tube
Connector Type: Receptacle
Voltage Rating: 120V
Mounting Type: Surface Mount
Number of Positions: 14
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Locking Ramp
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.85mm, 8.45mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.220" (5.60mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M80-4201842 M80-4201842 Harwin Inc. M80-420.pdf Description: 2X9POS DIL FEMALE VERTICAL CONN
Packaging: Bulk
Features: Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Connector Type: Receptacle
Voltage Rating: 120VAC/DC
Current Rating (Amps): 2.2A
Mounting Type: Through Hole
Number of Positions: 18
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.3mm, 7.55mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.205" (5.20mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M80-4T11842FC Harwin Inc. Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M80-4T11842FD M80-4T11842FD Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M80-4850605 M80-4850605 Harwin Inc. M80-485.pdf Description: CONN RCPT 6POS CRIMP 22AWG GOLD
Features: Jackscrews, Polarizing Key, Potting Wall
Packaging: Bag
Connector Type: Receptacle
Contact Finish: Galvanized
Color: Black
Mounting Type: Free Hanging (In-Line)
Wire Gauge: 22 AWG
Number of Positions: 6
Pitch: 0.079" (2.00mm)
Contact Type: Female Socket
Fastening Type: Screw Lock
Row Spacing: 0.079" (2.00mm)
Contact Finish Thickness: 11.8µin (0.30µm)
Wire Type: Discrete
Cable Termination: Crimp
Part Status: Active
Number of Rows: 2
auf Bestellung 193 Stücke:
Lieferzeit 10-14 Tag (e)
1+21.1 EUR
10+ 18.7 EUR
25+ 17.98 EUR
50+ 17.26 EUR
100+ 16.3 EUR
M80-8241842 Harwin Inc. M80-824_Dwg.pdf Description: CONN HEADER VERT 18POS 2MM
Packaging: Tube
Connector Type: Header
Voltage Rating: 800V
Current Rating (Amps): 2.2A
Mounting Type: Through Hole
Number of Positions: 18
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Contact Shape: Circular
Contact Length - Post: 0.370" (9.40mm)
Insulation Height: 0.213" (5.40mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA46), Nylon 4/6
Row Spacing - Mating: 0.079" (2.00mm)
Produkt ist nicht verfügbar
M80-7711045 M80-7711045 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: CONN HEADER R/A 10POS 2MM
Produkt ist nicht verfügbar
M80-7711022 M80-7711022 Harwin Inc. C005XX_M80_and_M83_Datamate_Series_Connectors.pdf Description: DATAMATE L-TEK DIL MALE HORIZONT
Produkt ist nicht verfügbar
M7686-46 M7686-46 Harwin Inc. Harwin_Datasheet-INDESS.pdf Description: 10MM JUMPER SKT W/HNDL BLACK
Packaging: Bulk
Gender: Female Sockets
Contact Finish: Tin
Color: Black
Voltage Rating: 250V
Current Rating (Amps): 3A
Pitch: 0.100" (2.54mm)
Type: Closed Top, Grip
Height: 0.394" (10.00mm)
Number of Positions or Pins (Grid): 2 (1 x 2)
Contact Finish Thickness: 118.1µin (3.00µm)
Material Flammability Rating: UL94 V-0
Housing Material: Polyester
Part Status: Active
auf Bestellung 4377 Stücke:
Lieferzeit 10-14 Tag (e)
26+0.69 EUR
30+ 0.6 EUR
33+ 0.55 EUR
50+ 0.51 EUR
100+ 0.49 EUR
250+ 0.45 EUR
500+ 0.43 EUR
1000+ 0.35 EUR
2500+ 0.32 EUR
Mindestbestellmenge: 26
M80-8562605 Harwin Inc. M80-856_Dwg.pdf Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M22-2741505 Harwin Inc. Description: CONN HDR 2MM 30POS
Produkt ist nicht verfügbar
M22-2010546 M22-201.pdf
M22-2010546
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 5POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole
Number of Positions: 5
Number of Rows: 1
Style: Board to Board
Operating Temperature: -55°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.134" (3.40mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.331" (8.40mm)
Insulation Material: Polyamide (PA6T), Nylon 6T
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 454 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
28+0.63 EUR
33+ 0.54 EUR
100+ 0.42 EUR
Mindestbestellmenge: 28
M22-2020205 M22-202.pdf
M22-2020205
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 4POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole
Number of Positions: 4
Number of Rows: 2
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.134" (3.40mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.331" (8.40mm)
Insulation Material: Polyamide (PA6T), Nylon 6T
Row Spacing - Mating: 0.079" (2.00mm)
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 6691 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
28+0.65 EUR
32+ 0.57 EUR
100+ 0.44 EUR
500+ 0.38 EUR
1000+ 0.31 EUR
5000+ 0.27 EUR
Mindestbestellmenge: 28
M80-5101605 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-5101605
Hersteller: Harwin Inc.
Description: DATAMATE J-TEK DIL MALE VERTICAL
Produkt ist nicht verfügbar
G125-MV10605L0R G125-MVXXX05LXR.pdf
G125-MV10605L0R
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 6POS 1.25MM
Features: Board Lock, Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Header
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
Produkt ist nicht verfügbar
G125-MV10605L0R G125-MVXXX05LXR.pdf
G125-MV10605L0R
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 6POS 1.25MM
Features: Board Lock, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 230 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
2+9.45 EUR
10+ 8.59 EUR
100+ 7.56 EUR
Mindestbestellmenge: 2
G125-MV10605M1P G125-MV1XX05M1P.pdf
G125-MV10605M1P
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 6POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 6
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 47 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+21.75 EUR
10+ 19.28 EUR
G125-MV12605M3P Harwin_Datasheet-Gecko-Signal.pdf
G125-MV12605M3P
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 26POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 26
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 38 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+33.84 EUR
10+ 29.34 EUR
G125-MV11005M1P G125-MV1XX05M1P.pdf
G125-MV11005M1P
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 10POS 1.25MM
Features: Mating Flange, Mounting Flange, Pick and Place
Packaging: Strip
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 10
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 32 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+22.19 EUR
10+ 19.68 EUR
G125-FV11005F2P C125XX_G125_Gecko_Connectors.pdf
G125-FV11005F2P
Hersteller: Harwin Inc.
Description: CONN RCPT 10POS 0.049 GOLD PCB
Features: Pick and Place, Polarizing Key
Packaging: Strip
Connector Type: Receptacle
Voltage Rating: 450V
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 10
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.25mm, 7.33mm
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.207" (5.25mm)
Row Spacing - Mating: 0.049" (1.25mm)
Number of Rows: 2
auf Bestellung 8 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+42.26 EUR
M80-5125042 M80-512.pdf
M80-5125042
Hersteller: Harwin Inc.
Description: CONN HEADER SMD 50POS 2MM
Features: Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Packaging: Tube
Connector Type: Header
Voltage Rating: 800V
Current Rating (Amps): 2.2A
Mounting Type: Surface Mount
Number of Positions: 50
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Threaded
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Circular
Insulation Height: 0.234" (5.95mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyphenylene Sulfide (PPS), Glass Filled
Row Spacing - Mating: 0.079" (2.00mm)
auf Bestellung 20 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+35.01 EUR
12+ 30.65 EUR
G125-FS10605F1P Harwin_Datasheet-Gecko-Signal.pdf
G125-FS10605F1P
Hersteller: Harwin Inc.
Description: CONN RCPT 6POS 0.049 GOLD SMD
Features: Jackscrews, Pick and Place, Polarizing Key
Packaging: Bulk
Connector Type: Receptacle
Current Rating (Amps): 2A
Mounting Type: Surface Mount
Number of Positions: 6
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Contact Finish - Post: Gold
Insulation Height: 0.207" (5.25mm)
Row Spacing - Mating: 0.049" (1.25mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M22-2031005 C018XX_M22_Series_Connectors.pdf
M22-2031005
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 10POS 2MM
Packaging: Bulk
Connector Type: Header, Cuttable
Current Rating (Amps): 1A per Contact
Mounting Type: Through Hole, Right Angle
Number of Positions: 10
Number of Rows: 1
Style: Board to Board
Operating Temperature: -55°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.079" (2.00mm)
Shrouding: Unshrouded
Insulation Material: Polyamide (PA6T), Nylon 6T
Contact Length - Mating: 0.138" (3.50mm)
auf Bestellung 1084 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
13+1.37 EUR
16+ 1.16 EUR
100+ 1.04 EUR
500+ 0.85 EUR
1000+ 0.76 EUR
Mindestbestellmenge: 13
M80-8430745 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-8430745
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 7POS 2MM
Produkt ist nicht verfügbar
M80-7930745 M80-793_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 7POS 2MM
Produkt ist nicht verfügbar
M80-8230745 M80-823_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 7POS 2MM
Produkt ist nicht verfügbar
M55-7012042R C047XX_M55_Archer_Kontrol.pdf
M55-7012042R
Hersteller: Harwin Inc.
Description: CONN HEADER SMD 20POS 1.27MM
Features: Board Guide, Pick and Place, Solder Retention
Packaging: Tape & Reel (TR)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.325" (8.25mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 1350 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
450+2 EUR
900+ 1.94 EUR
1350+ 1.71 EUR
Mindestbestellmenge: 450
M55-7012042R C047XX_M55_Archer_Kontrol.pdf
M55-7012042R
Hersteller: Harwin Inc.
Description: CONN HEADER SMD 20POS 1.27MM
Features: Board Guide, Pick and Place, Solder Retention
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.325" (8.25mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 1948 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
6+3.08 EUR
10+ 2.69 EUR
100+ 2.4 EUR
Mindestbestellmenge: 6
G125-MH23405L2R C125XX_G125_Gecko_Connectors.pdf
G125-MH23405L2R
Hersteller: Harwin Inc.
Description: CONN HDR R/A 34POS
Produkt ist nicht verfügbar
M80-7931745 M80-793_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 17POS 2MM
Produkt ist nicht verfügbar
M80-8231745 M80-823_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 17POS 2MM
Produkt ist nicht verfügbar
M80-8431745 Harwin_PC_Datamate.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 17POS 2MM
Produkt ist nicht verfügbar
Z80-044F Z80-044F.pdf
Z80-044F
Hersteller: Harwin Inc.
Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 36 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+40.69 EUR
5+ 38.42 EUR
10+ 36.16 EUR
25+ 35.03 EUR
Z80-044C Z80-044C-044D.pdf
Z80-044C
Hersteller: Harwin Inc.
Description: TOOL INSERT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Insertion Tool Tip
Part Status: Active
auf Bestellung 451 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+42.1 EUR
5+ 39.76 EUR
10+ 37.42 EUR
25+ 36.25 EUR
Z80-044D Z80-044C-044D.pdf
Z80-044D
Hersteller: Harwin Inc.
Description: TOOL INSERT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Insertion Tool Tip
Part Status: Active
auf Bestellung 441 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+33.3 EUR
5+ 31.45 EUR
10+ 29.6 EUR
25+ 28.68 EUR
Z80-044G Z80-044G.pdf
Z80-044G
Hersteller: Harwin Inc.
Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 447 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+41.82 EUR
5+ 39.48 EUR
10+ 37.16 EUR
25+ 36 EUR
Z80-044E Z80-044E.pdf
Z80-044E
Hersteller: Harwin Inc.
Description: TOOL EXTRACT TIP FOR Z80-280
Packaging: Bulk
For Use With/Related Products: Rectangular Contacts
Tool Type: Extraction Tool Tip
Part Status: Active
auf Bestellung 423 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+37.89 EUR
5+ 35.79 EUR
10+ 33.69 EUR
25+ 32.64 EUR
M50-3140845R M50-314.pdf
M50-3140845R
Hersteller: Harwin Inc.
Description: CONN RCPT 8POS 0.05 GOLD SMD
Features: Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Receptacle
Voltage Rating: 500VAC
Current Rating (Amps): 1A
Mounting Type: Surface Mount
Number of Positions: 8
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.134" (3.40mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M50-3140845R M50-314.pdf
M50-3140845R
Hersteller: Harwin Inc.
Description: CONN RCPT 8POS 0.05 GOLD SMD
Features: Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Receptacle
Voltage Rating: 500VAC
Current Rating (Amps): 1A
Mounting Type: Surface Mount
Number of Positions: 8
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.134" (3.40mm)
Number of Rows: 1
auf Bestellung 739 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
7+2.52 EUR
10+ 2.2 EUR
100+ 1.96 EUR
500+ 1.64 EUR
Mindestbestellmenge: 7
M50-3602742
Hersteller: Harwin Inc.
Description: CONN HEADER SMD 54POS 1.27MM
Produkt ist nicht verfügbar
M50-3602742P
Hersteller: Harwin Inc.
Description: CONN HEADER SMD 54POS 1.27MM
Produkt ist nicht verfügbar
M80-7534445 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-7534445
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 44POS 2MM
Produkt ist nicht verfügbar
M55-8001242-0300A M55-800.pdf
M55-8001242-0300A
Hersteller: Harwin Inc.
Description: CBL ASSEM 1.27MM 12POS F-F 300MM
Features: Latch Lock, Polarizing Key
Packaging: Bulk
Connector Type: Socket to Socket
Contact Finish: Gold
Color: Gray, Ribbon
Length: 0.984' (300.00mm, 11.81")
Shielding: Unshielded
Number of Positions: 12
Number of Rows: 2
Cable Termination: IDC
Pitch - Cable: 0.025" (0.64mm)
Pitch - Connector: 0.050" (1.27mm)
auf Bestellung 33 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+33.99 EUR
10+ 29.76 EUR
25+ 28.48 EUR
M80-4000000FC-03-PF2-00-000
Hersteller: Harwin Inc.
Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M55-7102042R M55-710.pdf
M55-7102042R
Hersteller: Harwin Inc.
Description: CONN HEADER SMD R/A 20POS 1.27MM
Packaging: Tape & Reel (TR)
Features: Board Guide, Solder Retention
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount, Right Angle
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.165" (4.20mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
600+2.06 EUR
1200+ 1.76 EUR
1800+ 1.7 EUR
3000+ 1.65 EUR
Mindestbestellmenge: 600
M55-7102042R M55-710.pdf
M55-7102042R
Hersteller: Harwin Inc.
Description: CONN HEADER SMD R/A 20POS 1.27MM
Features: Board Guide, Solder Retention
Packaging: Cut Tape (CT)
Connector Type: Header
Current Rating (Amps): 1.2A
Mounting Type: Surface Mount, Right Angle
Number of Positions: 20
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 1.00µin (0.025µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Rectangular
Insulation Height: 0.165" (4.20mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 3921 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
6+3.19 EUR
10+ 2.76 EUR
100+ 2.47 EUR
Mindestbestellmenge: 6
M80-8391822 M80-839_obsolete.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 18POS 2MM
Produkt ist nicht verfügbar
G125-MV13405M2P G125-MV1XX05M2P.pdf
G125-MV13405M2P
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 34POS 1.25MM
Packaging: Bulk
Features: Mating Flange, Mounting Flange, Pick and Place
Connector Type: Header
Voltage Rating: 450V
Current Rating (Amps): 2A per Contact
Mounting Type: Through Hole
Number of Positions: 34
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 150°C
Contact Type: Male Pin
Fastening Type: Threaded
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Green
Pitch - Mating: 0.049" (1.25mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Circular
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.193" (4.90mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Row Spacing - Mating: 0.049" (1.25mm)
auf Bestellung 14 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+22.04 EUR
10+ 19.53 EUR
M80-8182022R
Hersteller: Harwin Inc.
Description: CONNECTOR
Produkt ist nicht verfügbar
M80-8182022P
Hersteller: Harwin Inc.
Description: CONNECTOR
Produkt ist nicht verfügbar
M20-7863646P M20_Series_Spec.pdf
Hersteller: Harwin Inc.
Description: CONN RCPT 36POS 0.1 TIN SMD
Packaging: Tube
Features: Pick and Place
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863642 M20_Series_Spec.pdf
Hersteller: Harwin Inc.
Description: CONN RCPT 36POS 0.1 GOLD SMD
Packaging: Tube
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863642P M20_Series_Spec.pdf
Hersteller: Harwin Inc.
Description: CONN RCPT 36POS 0.1 GOLD SMD
Packaging: Tube
Features: Pick and Place
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M20-7863646 M20_Series_Spec.pdf
Hersteller: Harwin Inc.
Description: CONN RCPT 36POS 0.1 TIN SMD
Packaging: Tube
Connector Type: Receptacle, Bottom or Top Entry
Current Rating (Amps): 3A
Mounting Type: Surface Mount
Number of Positions: 36
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 11.63mm
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Tin
Contact Finish - Post: Tin
Insulation Height: 0.295" (7.50mm)
Number of Rows: 1
Produkt ist nicht verfügbar
M80-8242645 M80-824_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M80-7542645 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-7542645
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M50-3152742P
Hersteller: Harwin Inc.
Description: CONN RCPT 54POS 0.05 GOLD SMD
Produkt ist nicht verfügbar
M50-3152742
Hersteller: Harwin Inc.
Description: CONN RCPT 54POS 0.05 GOLD SMD
Produkt ist nicht verfügbar
M22-6340442R
Hersteller: Harwin Inc.
Description: CONN RCPT 8POS 0.079 GOLD SMD
Produkt ist nicht verfügbar
M80-6811042 M80-681.pdf
M80-6811042
Hersteller: Harwin Inc.
Description: CONN RCPT 10POS 0.079 GOLD SMD
Packaging: Tube
Connector Type: Receptacle
Voltage Rating: 120V
Mounting Type: Surface Mount
Number of Positions: 10
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Locking Ramp
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.85mm, 8.45mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.220" (5.60mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
auf Bestellung 195 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+18.94 EUR
18+ 16.79 EUR
108+ 14.64 EUR
M80-6811442 Harwin_Datasheet-Datamate-Signal.pdf
M80-6811442
Hersteller: Harwin Inc.
Description: CONN RCPT 14POS 0.079 GOLD SMD
Packaging: Tube
Connector Type: Receptacle
Voltage Rating: 120V
Mounting Type: Surface Mount
Number of Positions: 14
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Locking Ramp
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.85mm, 8.45mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.220" (5.60mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M80-4201842 M80-420.pdf
M80-4201842
Hersteller: Harwin Inc.
Description: 2X9POS DIL FEMALE VERTICAL CONN
Packaging: Bulk
Features: Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Connector Type: Receptacle
Voltage Rating: 120VAC/DC
Current Rating (Amps): 2.2A
Mounting Type: Through Hole
Number of Positions: 18
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Screw Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 7.3mm, 7.55mm
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 12.0µin (0.30µm)
Contact Finish - Post: Tin
Contact Length - Post: 0.118" (3.00mm)
Insulation Height: 0.205" (5.20mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
Produkt ist nicht verfügbar
M80-4T11842FC
Hersteller: Harwin Inc.
Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M80-4T11842FD C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-4T11842FD
Hersteller: Harwin Inc.
Description: CONN DATAMATE FEMALE
Produkt ist nicht verfügbar
M80-4850605 M80-485.pdf
M80-4850605
Hersteller: Harwin Inc.
Description: CONN RCPT 6POS CRIMP 22AWG GOLD
Features: Jackscrews, Polarizing Key, Potting Wall
Packaging: Bag
Connector Type: Receptacle
Contact Finish: Galvanized
Color: Black
Mounting Type: Free Hanging (In-Line)
Wire Gauge: 22 AWG
Number of Positions: 6
Pitch: 0.079" (2.00mm)
Contact Type: Female Socket
Fastening Type: Screw Lock
Row Spacing: 0.079" (2.00mm)
Contact Finish Thickness: 11.8µin (0.30µm)
Wire Type: Discrete
Cable Termination: Crimp
Part Status: Active
Number of Rows: 2
auf Bestellung 193 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+21.1 EUR
10+ 18.7 EUR
25+ 17.98 EUR
50+ 17.26 EUR
100+ 16.3 EUR
M80-8241842 M80-824_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 18POS 2MM
Packaging: Tube
Connector Type: Header
Voltage Rating: 800V
Current Rating (Amps): 2.2A
Mounting Type: Through Hole
Number of Positions: 18
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Contact Shape: Circular
Contact Length - Post: 0.370" (9.40mm)
Insulation Height: 0.213" (5.40mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Polyamide (PA46), Nylon 4/6
Row Spacing - Mating: 0.079" (2.00mm)
Produkt ist nicht verfügbar
M80-7711045 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-7711045
Hersteller: Harwin Inc.
Description: CONN HEADER R/A 10POS 2MM
Produkt ist nicht verfügbar
M80-7711022 C005XX_M80_and_M83_Datamate_Series_Connectors.pdf
M80-7711022
Hersteller: Harwin Inc.
Description: DATAMATE L-TEK DIL MALE HORIZONT
Produkt ist nicht verfügbar
M7686-46 Harwin_Datasheet-INDESS.pdf
M7686-46
Hersteller: Harwin Inc.
Description: 10MM JUMPER SKT W/HNDL BLACK
Packaging: Bulk
Gender: Female Sockets
Contact Finish: Tin
Color: Black
Voltage Rating: 250V
Current Rating (Amps): 3A
Pitch: 0.100" (2.54mm)
Type: Closed Top, Grip
Height: 0.394" (10.00mm)
Number of Positions or Pins (Grid): 2 (1 x 2)
Contact Finish Thickness: 118.1µin (3.00µm)
Material Flammability Rating: UL94 V-0
Housing Material: Polyester
Part Status: Active
auf Bestellung 4377 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
26+0.69 EUR
30+ 0.6 EUR
33+ 0.55 EUR
50+ 0.51 EUR
100+ 0.49 EUR
250+ 0.45 EUR
500+ 0.43 EUR
1000+ 0.35 EUR
2500+ 0.32 EUR
Mindestbestellmenge: 26
M80-8562605 M80-856_Dwg.pdf
Hersteller: Harwin Inc.
Description: CONN HEADER VERT 26POS 2MM
Produkt ist nicht verfügbar
M22-2741505
Hersteller: Harwin Inc.
Description: CONN HDR 2MM 30POS
Produkt ist nicht verfügbar
Wählen Sie Seite:   [  << Vorherige Seite ]  1 21 42 63 84 105 126 147 168 178 179 180 181 182 183 184 185 186 187 188 189 210  [ Nächste Seite >> ]
