MSOX2002A MSOX2002A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 70MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2002A MSOX2002A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 70MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2002A/903 MSOX2002A/903 Keysight 5990_6618-2891587.pdf Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8 channel, 70MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A MSOX2004A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Supply voltage: 100...240V AC
Interface: Ethernet; GPIB; RS232; USB
Connectors for the country: Europe
Trigger: falling-edge; impulse width; rising-edge; video signal
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Rise time: ≤5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Vertical resolution: 8bit
Max. input voltage: 300V
Display resolution: 800x480
Memory record length: 100kpts/ch
Input impedance: 1MΩ/11pF
Band: 70MHz
Sampling: 2Gsps
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Kind of display used: colour; LCD 8,5"
Type of oscilloscope: mixed signal
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A MSOX2004A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Supply voltage: 100...240V AC
Interface: Ethernet; GPIB; RS232; USB
Connectors for the country: Europe
Trigger: falling-edge; impulse width; rising-edge; video signal
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Rise time: ≤5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Vertical resolution: 8bit
Max. input voltage: 300V
Display resolution: 800x480
Memory record length: 100kpts/ch
Input impedance: 1MΩ/11pF
Band: 70MHz
Sampling: 2Gsps
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Kind of display used: colour; LCD 8,5"
Type of oscilloscope: mixed signal
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A/903 MSOX2004A/903 Keysight 5990_6618-2891587.pdf Benchtop Oscilloscopes Oscilloscope, mixed signal, 4+8-channel, 70MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A MSOX2012A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A MSOX2012A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A/903 MSOX2012A/903 Keysight 5990_6618-2891587.pdf Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8 channel, 100MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A MSOX2014A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A MSOX2014A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A/903 MSOX2014A/903 Keysight 5990_6618-2891587.pdf Benchtop Oscilloscopes Oscilloscope, mixed signal, 4+8-channel, 100MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A MSOX2022A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A MSOX2022A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A/903 MSOX2022A/903 Keysight 5990_6618-2891587.pdf Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8-channel, 200MHz, US/Canada Power Cord
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+7576.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A MSOX2024A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A MSOX2024A KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50 Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A/DSO0000-903 MSOX2024A/DSO0000-903 Keysight 5990_6618EN-1143086.pdf Benchtop Oscilloscopes Mixed Signal, 4+8-Ch, 200MHz, BenchVue SW, Power cord - US / Canada 120V
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+8902.54 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012A MSOX3012A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 100 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012T MSOX3012T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 100 MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+11837.41 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012T KEYSIGHT MSOX3012T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014A MSOX3014A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 100 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+14281.4 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G/C13APWR-903 MSOX3014G/C13APWR-903 Keysight 5990_6619-2508132.pdf Benchtop Oscilloscopes 100 MHz, 4+16 Ch, with US Power Cord
auf Bestellung 2 Stücke:
Lieferzeit 10-14 Tag (e)
1+13463.07 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014T MSOX3014T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 100MHz, Power Cord, US / Canada (125V)
auf Bestellung 2 Stücke:
Lieferzeit 10-14 Tag (e)
1+13836.28 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014T KEYSIGHT MSOX3014T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G/C13APWR-903 MSOX3022G/C13APWR-903 Keysight 5990_6619-2508132.pdf Benchtop Oscilloscopes 200 Mz, 2+16 Ch. with US Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022T MSOX3022T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 200 MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+13419.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022T KEYSIGHT MSOX3022T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024A MSOX3024A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 200 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+15173.15 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G/C13APWR-903 MSOX3024G/C13APWR-903 Keysight InfiniiVision_3000G_X_Series_Oscilloscopes-2948542.pdf Benchtop Oscilloscopes 200 Mz, 4+16 Ch. with US Power Cord
auf Bestellung 5 Stücke:
Lieferzeit 10-14 Tag (e)
1+14557.58 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024T MSOX3024T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 200MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+14569.16 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024T KEYSIGHT MSOX3024T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032A MSOX3032A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 350 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032T MSOX3032T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 350 MHz, Power Cord, US / Canada (125V)
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032T KEYSIGHT MSOX3032T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034A MSOX3034A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 350 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+24958.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034T MSOX3034T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 350MHz,Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+24056.7 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034T KEYSIGHT MSOX3034T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052A MSOX3052A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 500 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052T MSOX3052T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 500 MHz. Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+25171.2 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052T KEYSIGHT MSOX3052T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054G KEYSIGHT pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054T MSOX3054T Keysight 5992_0140EN-1602072.pdf Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 500MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
1+32231.37 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054T KEYSIGHT MSOX3054T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3102A MSOX3102A Keysight 5990_6619EN-1602089.pdf Benchtop Oscilloscopes Mixed Signal 2+16 Ch, 1 GHz, Power cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2002A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2002A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 70MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2002A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2002A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 70MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2002A/903 5990_6618-2891587.pdf
MSOX2002A/903
Hersteller: Keysight
Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8 channel, 70MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2004A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Supply voltage: 100...240V AC
Interface: Ethernet; GPIB; RS232; USB
Connectors for the country: Europe
Trigger: falling-edge; impulse width; rising-edge; video signal
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Rise time: ≤5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Vertical resolution: 8bit
Max. input voltage: 300V
Display resolution: 800x480
Memory record length: 100kpts/ch
Input impedance: 1MΩ/11pF
Band: 70MHz
Sampling: 2Gsps
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Kind of display used: colour; LCD 8,5"
Type of oscilloscope: mixed signal
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2004A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 70MHz; 2Gsps; 100kpts/ch; ≤5ns
Supply voltage: 100...240V AC
Interface: Ethernet; GPIB; RS232; USB
Connectors for the country: Europe
Trigger: falling-edge; impulse width; rising-edge; video signal
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Rise time: ≤5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Vertical resolution: 8bit
Max. input voltage: 300V
Display resolution: 800x480
Memory record length: 100kpts/ch
Input impedance: 1MΩ/11pF
Band: 70MHz
Sampling: 2Gsps
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Kind of display used: colour; LCD 8,5"
Type of oscilloscope: mixed signal
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2004A/903 5990_6618-2891587.pdf
MSOX2004A/903
Hersteller: Keysight
Benchtop Oscilloscopes Oscilloscope, mixed signal, 4+8-channel, 70MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2012A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2012A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2012A/903 5990_6618-2891587.pdf
MSOX2012A/903
Hersteller: Keysight
Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8 channel, 100MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2014A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2014A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 100MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 100MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤3.5ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2014A/903 5990_6618-2891587.pdf
MSOX2014A/903
Hersteller: Keysight
Benchtop Oscilloscopes Oscilloscope, mixed signal, 4+8-channel, 100MHz, US/Canada Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2022A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2022A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 2; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 2
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2022A/903 5990_6618-2891587.pdf
MSOX2022A/903
Hersteller: Keysight
Benchtop Oscilloscopes Oscilloscope, mixed signal, 2+8-channel, 200MHz, US/Canada Power Cord
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+7576.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2024A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A pVersion=0046&contRep=ZT&docId=005056AB752F1EE590CDA8C7200FA469&compId=5990-6618EN.pdf?ci_sign=c95d144bb2e0c1a403e32d6a1f5a03cad73d2d40 pVersion=0046&contRep=ZT&docId=005056AB5A8F1ED3A3B3CE22EF03F26B&compId=5990-8184EN.pdf?ci_sign=fb9428d15c36adf068dac8d244e9663af659eb50
MSOX2024A
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; Ch: 4; 200MHz; 2Gsps; 100kpts/ch
Type of oscilloscope: mixed signal
Number of channels: 4
Band: 200MHz
Sampling: 2Gsps
Memory record length: 100kpts/ch
Kind of display used: colour; LCD 8,5"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; rising-edge; video signal
Time base: 5n...50s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC
Trigger coupling: AC; DC; highpass; lowpass
Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket
Interface: Ethernet; GPIB; RS232; USB
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Manufacturer series: InfiniiVision 2000 X-SERIES MSO
Rise time: ≤1.75ns
Input impedance: 1MΩ/11pF
Input sensitivity: 1mV/div...5V/div
Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel)
Body dimensions: 381x204x142mm
Supply voltage: 100...240V AC
Display resolution: 800x480
Connectors for the country: Europe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX2024A/DSO0000-903 5990_6618EN-1143086.pdf
MSOX2024A/DSO0000-903
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+8-Ch, 200MHz, BenchVue SW, Power cord - US / Canada 120V
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+8902.54 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012A 5990_6619EN-1602089.pdf
MSOX3012A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 100 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012T 5992_0140EN-1602072.pdf
MSOX3012T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 100 MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+11837.41 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3012T
Hersteller: KEYSIGHT
MSOX3012T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014A 5990_6619EN-1602089.pdf
MSOX3014A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 100 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+14281.4 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 100MHz; 5Gsps; 4Mpts; ≤3.5ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤3.5ns
Time base: 5n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 100MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014G/C13APWR-903 5990_6619-2508132.pdf
MSOX3014G/C13APWR-903
Hersteller: Keysight
Benchtop Oscilloscopes 100 MHz, 4+16 Ch, with US Power Cord
auf Bestellung 2 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+13463.07 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014T 5992_0140EN-1602072.pdf
MSOX3014T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 100MHz, Power Cord, US / Canada (125V)
auf Bestellung 2 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+13836.28 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3014T
Hersteller: KEYSIGHT
MSOX3014T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022G/C13APWR-903 5990_6619-2508132.pdf
MSOX3022G/C13APWR-903
Hersteller: Keysight
Benchtop Oscilloscopes 200 Mz, 2+16 Ch. with US Power Cord
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022T 5992_0140EN-1602072.pdf
MSOX3022T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 200 MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+13419.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3022T
Hersteller: KEYSIGHT
MSOX3022T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024A 5990_6619EN-1602089.pdf
MSOX3024A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 200 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+15173.15 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 200MHz; 5Gsps; 4Mpts; 5÷50°C
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1.75ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 200MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024G/C13APWR-903 InfiniiVision_3000G_X_Series_Oscilloscopes-2948542.pdf
MSOX3024G/C13APWR-903
Hersteller: Keysight
Benchtop Oscilloscopes 200 Mz, 4+16 Ch. with US Power Cord
auf Bestellung 5 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+14557.58 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024T 5992_0140EN-1602072.pdf
MSOX3024T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 200MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+14569.16 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3024T
Hersteller: KEYSIGHT
MSOX3024T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032A 5990_6619EN-1602089.pdf
MSOX3032A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 350 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032T 5992_0140EN-1602072.pdf
MSOX3032T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 350 MHz, Power Cord, US / Canada (125V)
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3032T
Hersteller: KEYSIGHT
MSOX3032T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034A 5990_6619EN-1602089.pdf
MSOX3034A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16-Ch, 350 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+24958.24 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 350MHz; 5Gsps; 4Mpts; ≤1ns
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤1ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 350MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034T 5992_0140EN-1602072.pdf
MSOX3034T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 350MHz,Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+24056.7 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3034T
Hersteller: KEYSIGHT
MSOX3034T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052A 5990_6619EN-1602089.pdf
MSOX3052A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 500 MHz, Pwr Cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 2; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x2
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052T 5992_0140EN-1602072.pdf
MSOX3052T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 2+16-Ch, 500 MHz. Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+25171.2 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3052T
Hersteller: KEYSIGHT
MSOX3052T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054G pVersion=0046&contRep=ZT&docId=005056AB281E1EDD8987C57925D400D2&compId=InfiniiVision-3000G-X-Series.pdf?ci_sign=57ed67ea09e6ac85e0c59deebb53ce4844fc81fb
Hersteller: KEYSIGHT
Category: Digital Oscilloscopes
Description: Oscilloscope: mixed signal; MSO; Ch: 4; 500MHz; 5Gsps; 4Mpts; ≤700ps
Interface: I2C; I2S; NFC; RS232; RS422; RS485; SPI; USB
Additional functions: arbitrary waveform generator
Trigger modes: automatic; normal; single
Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe x4
Trigger source: CH1; CH2; external signal; supply voltage source
Type of oscilloscope: mixed signal
Kind of oscilloscope: MSO
Trigger: falling-edge; impulse width; risetime; rising-edge; runt; video signal
Manufacturer series: InfiniiVision 3000G X-SERIES
Kind of display used: LCD 8,5"
Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use.
Touchpad: yes
Operating temperature: 5...50°C
Rise time: ≤0.7ns
Time base: 1n...50s/div
Input sensitivity: 1mV/div...5V/div
Body dimensions: 381x204x142mm
Number of channels: 4
Supply voltage: 100...240V AC
Vertical resolution: 8bit
Max. input voltage: 190V
Display resolution: 800x480
Input impedance: 1MΩ/14pF
Memory record length: 4Mpts
Band: 500MHz
Sampling: 5Gsps
Measuring instrument features: 16 digital channels; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; Y-T, X-Y, ROLL operation mode
Related items: D3000AERB; D3000AUTB; D3000BDLB; D3000PWRB; D3000USBB; DP0010A; DP0012A; N2750A; N2870A
Trigger coupling: AC; DC; highpass; lowpass
Input coupling: AC, DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054T 5992_0140EN-1602072.pdf
MSOX3054T
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal, 4+16 Ch, 500MHz, Power Cord, US / Canada (125V)
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+32231.37 EUR
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3054T
Hersteller: KEYSIGHT
MSOX3054T Digital Oscilloscopes
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
MSOX3102A 5990_6619EN-1602089.pdf
MSOX3102A
Hersteller: Keysight
Benchtop Oscilloscopes Mixed Signal 2+16 Ch, 1 GHz, Power cord - US / Canada 120V, NEMA 5-15P male
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 3 6 9 12 13 14 15 16 17 18 19 20 21 22 23 24 27 30 31  [ Nächste Seite >> ]
