Produkte > MINI-CIRCUITS > Alle Produkte des Herstellers MINI-CIRCUITS (10731) > Seite 67 nach 179

Hersteller: Mini-Circuits
Description: 2 WAY DC PASS PWR SPLTR 1-40GHZ
Packaging: Bulk

Hersteller: Mini-Circuits
Description: LUMPED LC BPF, 3 - 30 MHZ, 50
Packaging: Tray
Package / Case: Module, SMA Connectors
Filter Type: Band Pass
Size / Dimension: 2.300" L x 2.250" W (58.42mm x 57.15mm)
Mounting Type: Chassis Mount
Frequency: 16MHz Center
Insertion Loss: 3dB
Bandwidth: 27MHz
Height (Max): 0.750" (19.05mm)

Hersteller: Mini-Circuits
Description: LTCC LPF, DC - 3000 MHZ, 50
Packaging: Box
Package / Case: Inline, SMA Connection, F and M
Filter Type: Low Pass
Size / Dimension: 0.410" Dia (10.41mm)
Mounting Type: Chassis Mount
Frequency: 3.46GHz (Cutoff)
Insertion Loss: 2.2dB
Bandwidth: 3GHz

Hersteller: Mini-Circuits
Description: 3X MULTIPLIER, 10 TO 22 GHZ
Packaging: Tray
Package / Case: Module
Mounting Type: Chassis Mount
Function: Frequency Multiplier
Frequency: 10GHz ~ 22GHz
RF Type: Radar
Secondary Attributes: SMA Connectors

Hersteller: Mini-Circuits
Description: LINEAR AMP, 2400 MHZ - 2500 MHZ
Packaging: Box
Package / Case: Module
Mounting Type: Chassis Mount
Function: Coaxial Solid State
Frequency: 2.4GHz ~ 2.5GHz
RF Type: General Purpose
Secondary Attributes: 50W

Hersteller: Mini-Circuits
Description: 2 WAYS PWRSPLTR, 1900 - 4200 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 0.900" L x 0.740" W x 0.570" H (22.86mm x 18.80mm x 14.48mm)
Insertion Loss: 0.2dB
Specifications: Isolation (Min) 17dB, 5° Imbalance (Max)
Frequency: 1.9 GHz ~ 4.2 GHz

Hersteller: Mini-Circuits
Description: 17.5 DB DIR COUP, 5 - 2000 MHZ
Packaging: Tray
Package / Case: Module
Frequency: 5MHz ~ 2GHz
Applications: General Purpose
Coupling Factor: 18.5 ± 1dB
Coupler Type: Standard

Hersteller: Mini-Circuits
Description: CAVITY BPF, 37 - 40 GHZ, 50
Packaging: Tray
Package / Case: 2.92mm In-Line Module
Filter Type: Band Pass
Size / Dimension: 3.543" L x 0.630" W (90.00mm x 16.00mm)
Mounting Type: Chassis Mount
Frequency: 38.5GHz Center
Insertion Loss: 4dB
Bandwidth: 3GHz
Height (Max): 0.640" (16.26mm)

Hersteller: Mini-Circuits
Description: RF FILTER BAND PASS 38.5GHZ MOD
Packaging: Tray
Package / Case: Module
Filter Type: Band Pass
Size / Dimension: 3.543" L x 0.630" W (90.00mm x 16.00mm)
Mounting Type: Chassis Mount
Frequency: 38.5GHz Center
Insertion Loss: 4dB
Bandwidth: 3GHz
Height (Max): 0.315" (8.00mm)

Hersteller: Mini-Circuits
Description: RF PWR DVDR 1.3GHZ-2GHZ 12VQFN
Packaging: Cut Tape (CT)
Package / Case: 12-VQFN Exposed Pad
Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Insertion Loss: 0.8dB
Specifications: Isolation (Min) 14dB, 1.5 VSWR (Typ), 5° Imbalance (Max)
Frequency: 1.3 GHz ~ 2 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PASS PS, 950-2150 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 2.000" L x 2.000" W x 0.780" H (50.80mm x 50.80mm x 19.81mm)
Insertion Loss: 0.3dB
Specifications: Isolation (Min) 20dB, 5° Imbalance (Max), 1.15 VSWR (Typ)
Frequency: 950 MHz ~ 2.15 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS PS, 800 - 2700 MHZ, 50
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 2.000" L x 2.000" W x 0.750" H (50.80mm x 50.80mm x 19.05mm)
Insertion Loss: 0.3dB
Specifications: Isolation (Min) 18dB, 3° Imbalance (Max), 1.5 VSWR (Max)
Frequency: 800 MHz ~ 2.7 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PASS PS, 950-2150 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 2.000" L x 2.000" W x 0.780" H (50.80mm x 50.80mm x 19.81mm)
Insertion Loss: 0.3dB
Specifications: Isolation (Min) 20dB, 5° Imbalance (Max), 1.15 VSWR (Typ)
Frequency: 950 MHz ~ 2.15 GHz

Hersteller: Mini-Circuits
Description: LTCC BPF, 2400 - 2500 MHZ, 50
Packaging: Tape & Reel (TR)
Package / Case: 4-SMD, No Lead
Filter Type: Band Pass
Size / Dimension: 0.079" L x 0.049" W (2.00mm x 1.25mm)
Mounting Type: Surface Mount
Frequency: 2.45GHz Center
Insertion Loss: 1.8dB
Bandwidth: 100MHz
Height (Max): 0.041" (1.04mm)

Hersteller: Mini-Circuits
Description: LTCC BPF, 2400 - 2500 MHZ, 50
Packaging: Cut Tape (CT)
Package / Case: 4-SMD, No Lead
Filter Type: Band Pass
Size / Dimension: 0.079" L x 0.049" W (2.00mm x 1.25mm)
Mounting Type: Surface Mount
Frequency: 2.45GHz Center
Insertion Loss: 1.8dB
Bandwidth: 100MHz
Height (Max): 0.041" (1.04mm)

Hersteller: Mini-Circuits
Description: 2-WAY MMIC SMT PS, 2800-6200 MHZ
Packaging: Tape & Reel (TR)
Package / Case: 12-VQFN Exposed Pad
Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Insertion Loss: 0.8dB
Specifications: Isolation (Min) 25dB, 37dB Return Loss, 8° Imbalance (Max)
Frequency: 2.8 GHz ~ 6.2 GHz

Hersteller: Mini-Circuits
Description: 2-WAY MMIC SMT PS, 2800-6200 MHZ
Packaging: Cut Tape (CT)
Package / Case: 12-VQFN Exposed Pad
Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Insertion Loss: 0.8dB
Specifications: Isolation (Min) 25dB, 37dB Return Loss, 8° Imbalance (Max)
Frequency: 2.8 GHz ~ 6.2 GHz

Hersteller: Mini-Circuits
Description: 4 WAYS DC PASS PS, 2000-26500MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 3.120" L x 2.030" W x 0.530" H (79.25mm x 51.56mm x 13.46mm)
Insertion Loss: 2.2dB
Specifications: Isolation (Min) 18dB, 5° Imbalance (Max), 1.6 VSWR (Max)
Frequency: 2 GHz ~ 26.5 GHz

Hersteller: Mini-Circuits
Description: MMIC, POWER AMP, 10 - 4000 MHZ
Packaging: Tape & Reel (TR)
Package / Case: 12-VQFN Exposed Pad
Mounting Type: Surface Mount
Frequency: 10MHz ~ 4GHz
RF Type: 5G, Radar, VSAT
Voltage - Supply: 10V ~ 12.5V
Gain: 20.2dB
Current - Supply: 190mA
Noise Figure: 2.5dB
P1dB: 32.4dBm
Test Frequency: 3GHz
Supplier Device Package: 12-MCLP (3x3)

Hersteller: Mini-Circuits
Description: MMIC, POWER AMP, 10 - 4000 MHZ
Packaging: Cut Tape (CT)
Package / Case: 12-VQFN Exposed Pad
Mounting Type: Surface Mount
Frequency: 10MHz ~ 4GHz
RF Type: 5G, Radar, VSAT
Voltage - Supply: 10V ~ 12.5V
Gain: 20.2dB
Current - Supply: 190mA
Noise Figure: 2.5dB
P1dB: 32.4dBm
Test Frequency: 3GHz
Supplier Device Package: 12-MCLP (3x3)

Hersteller: Mini-Circuits
Description: PHASE SHFT SURF MT ROHS
Packaging: Tape & Reel (TR)
Package / Case: 14-SMD Module
Mounting Type: Surface Mount
Function: Phase Shifter
Frequency: 10MHz ~ 16MHz
RF Type: Cellular, DCS, PCS
Secondary Attributes: 360° Phase Shift

Hersteller: Mini-Circuits
Description: PHASE SHFT SURF MT ROHS
Packaging: Cut Tape (CT)
Package / Case: 14-SMD Module
Mounting Type: Surface Mount
Function: Phase Shifter
Frequency: 10MHz ~ 16MHz
RF Type: Cellular, DCS, PCS
Secondary Attributes: 360° Phase Shift

Hersteller: Mini-Circuits
Description: MODULE
Power (Watts): 1.5W
Packaging: Bulk
Package / Case: 4-SMD, No Lead
Attenuation Value: 20dB
Impedance: 50 Ohms
Frequency Range: 0 Hz ~ 20 GHz

Hersteller: Mini-Circuits
Description: EVAL BOARD FOR TCM1-83X+
Packaging: Tray
Frequency: 10MHz ~ 8GHz
Type: Balun
Contents: Board(s)
Utilized IC / Part: TCM1-83X+

Hersteller: Mini-Circuits
Description: 1:1.5 C&W XFMR, 200 - 6000 MHZ
Packaging: Tape & Reel (TR)
Package / Case: 6-SMD, Flat Leads
Mounting Type: Surface Mount
Frequency Range: 200MHz ~ 6GHz
Impedance - Unbalanced/Balanced: 1:1.5, 75 / 50Ohm
Insertion Loss (Max): 2.6dB
Return Loss (Min): 12dB

Hersteller: Mini-Circuits
Description: 1:1.5 C&W XFMR, 200 - 6000 MHZ
Packaging: Cut Tape (CT)
Package / Case: 6-SMD, Flat Leads
Mounting Type: Surface Mount
Frequency Range: 200MHz ~ 6GHz
Impedance - Unbalanced/Balanced: 1:1.5, 75 / 50Ohm
Insertion Loss (Max): 2.6dB
Return Loss (Min): 12dB

Hersteller: Mini-Circuits
Description: 20 DB FIXED ATT, DC - 40000 MHZ
Power (Watts): 2W
Packaging: Box
Package / Case: 2.92mm In-Line Module
Attenuation Value: 20dB
Impedance: 50 Ohms
Frequency Range: 0 Hz ~ 40 GHz

Hersteller: Mini-Circuits
Description: MMIC DC PASS PS, 800-2100 MHZ
Packaging: Tape & Reel (TR)
Package / Case: 12-VQFN Exposed Pad
Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Insertion Loss: 1.3dB
Specifications: Isolation (Min) 20dB, 3° Imbalance (Max), 26dB Return Loss
Frequency: 800 MHz ~ 2.1 GHz

Hersteller: Mini-Circuits
Description: MMIC DC PASS PS, 800-2100 MHZ
Packaging: Cut Tape (CT)
Package / Case: 12-VQFN Exposed Pad
Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Insertion Loss: 1.3dB
Specifications: Isolation (Min) 20dB, 3° Imbalance (Max), 26dB Return Loss
Frequency: 800 MHz ~ 2.1 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS RESISTIVE PS, DC 4200 MHZ
Packaging: Bag
Package / Case: Module, SMA Connectors
Size / Dimension: 1.250" L x 1.250" W x 0.780" H (31.75mm x 31.75mm x 19.81mm)
Insertion Loss: 0.4dB
Specifications: Isolation (Typ) 7dB, 5° Imbalance (Max)
Frequency: 0 Hz ~ 4.2 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWRSPLTR, 800 - 2000 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 3.500" L x 2.130" W x 0.910" H (88.90mm x 54.10mm x 23.11mm)
Insertion Loss: 0.6dB
Specifications: Isolation (Min) 18dB, 5° Imbalance (Max)
Frequency: 800 MHz ~ 2 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWRSPLTR, 500 - 6000 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 8.250" L x 5.000" W x 0.630" H (209.55mm x 127.00mm x 16.00mm)
Insertion Loss: 1.7dB
Specifications: Isolation (Min) 19dB, 1.8 VSWR, 12° Imbalance (Max)
Frequency: 500 MHz ~ 6 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWRSPLTR, 7400-12600 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 0.900" L x 0.740" W x 0.570" H (22.86mm x 18.80mm x 14.48mm)
Insertion Loss: 0.6dB
Specifications: Isolation (Min) 16dB, 10° Imbalance (Max)
Frequency: 7.4 GHz ~ 12.6 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWR SPLTR, 500-10500 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 4.500" L x 2.500" W x 0.670" H (114.30mm x 63.50mm x 17.02mm)
Insertion Loss: 1dB
Specifications: Isolation (Min) 11dB, 6° Imbalance (Max)
Frequency: 500 MHz ~ 10.5 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PASS PS, 2950-7100 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 0.900" L x 0.740" W x 0.570" H (22.86mm x 18.80mm x 14.48mm)
Insertion Loss: 0.3dB
Specifications: Isolation (Min) 18dB, 3° Imbalance (Max)
Frequency: 2.95 GHz ~ 7.1 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PASS PS, 1 - 750 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 1.250" L x 1.250" W x 0.780" H (31.75mm x 31.75mm x 19.81mm)
Insertion Loss: 0.8dB
Specifications: Isolation (Min) 20dB, 4° Imbalance (Max), 1.29 VSWR (Typ)
Frequency: 1 MHz ~ 750 MHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PPS, 4000 - 14000 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 0.900" L x 0.740" W x 0.570" H (22.86mm x 18.80mm x 14.48mm)
Insertion Loss: 0.8dB
Frequency: 4 GHz ~ 14 GHz

Hersteller: Mini-Circuits
Description: 2 WAYS DC PASS PS, 3500-9000 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 1.250" L x 1.250" W x 0.780" H (31.75mm x 31.75mm x 19.81mm)
Insertion Loss: 0.6dB
Specifications: Isolation (Min) 12dB, 10° Imbalance (Max)
Frequency: 3.5 GHz ~ 9 GHz

Hersteller: Mini-Circuits
Description: 3 WAYS DC PASS PS, 1000-2000 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 2.000" L x 2.000" W x 0.780" H (50.80mm x 50.80mm x 19.81mm)
Insertion Loss: 0.3dB
Specifications: Isolation (Min) 15dB
Frequency: 1 GHz ~ 2 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWRSPLTR, 800 - 2000 MHZ
Packaging: Bulk
Package / Case: Module
Size / Dimension: 3.500" L x 2.130" W x 0.910" H (88.90mm x 54.10mm x 23.11mm)
Insertion Loss: 0.6dB
Specifications: Isolation (Min) 18dB, 1.6 VSWR (Max), 5° Imbalance (Max)
Frequency: 800 MHz ~ 2 GHz

Hersteller: Mini-Circuits
Description: 4 WAYS DC PASS PS, 380-4600 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 5.000" L x 5.000" W x 0.910" H (127.00mm x 127.00mm x 23.11mm)
Insertion Loss: 1.3dB
Specifications: Isolation (Min) 16dB, 9° Imbalance (Max), 1.9 VSWR (Max)
Frequency: 380 MHz ~ 4.6 GHz

Hersteller: Mini-Circuits
Description: 4 WAYS DC PPS, 380-4600 MHZ, 50
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 5.000" L x 5.000" W x 0.910" H (127.00mm x 127.00mm x 23.11mm)
Insertion Loss: 1.3dB
Specifications: Isolation (Min) 16dB, 9° Imbalance (Max), 1.9 VSWR (Max)
Frequency: 380 MHz ~ 4.6 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWR SPLTR, 2100-8400 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 3.875" L x 2.625" W x 0.650" H (98.43mm x 66.68mm x 16.51mm)
Insertion Loss: 1.3dB
Specifications: Isolation (Min) 18dB, 9° Imbalance (Max), 1.6 VSWR (Typ)
Frequency: 2.1 GHz ~ 8.4 GHz

Hersteller: Mini-Circuits
Description: 8 WAYS DC PPS, 3200 - 6200 MHZ
Packaging: Tray
Package / Case: Module
Size / Dimension: 7.060" L x 3.130" W x 0.910" H (179.32mm x 79.50mm x 23.11mm)
Insertion Loss: 0.8dB
Specifications: Isolation (Min) 16dB, 6° Imbalance (Max)
Frequency: 3.2 GHz ~ 6.2 GHz

Hersteller: Mini-Circuits
Description: PWR SPLTR, DC - 8400 MHZ, 50
Packaging: Bag
Package / Case: Module
Size / Dimension: 1.250" L x 1.250" W x 0.750" H (31.75mm x 31.75mm x 19.05mm)
Insertion Loss: 0.6dB
Specifications: Isolation (Typ) 6.4dB, 10° Imbalance (Max)
Frequency: 0 Hz ~ 8.4 GHz

Hersteller: Mini-Circuits
Description: 3 WAYS DC PASS PS
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 4.460" L x 2.474" W x 0.410" H (113.28mm x 62.84mm x 10.41mm)
Insertion Loss: 0.9dB
Specifications: Isolation (Min) 16dB, 8° Imbalance (Max), 1.85 VSWR (Max)
Frequency: 2 GHz ~ 18 GHz

Hersteller: Mini-Circuits
Description: DC PASS PWRSPLTR, 6000-26500 MHZ
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 2.035" L x 1.500" W x 0.530" H (51.70mm x 38.10mm x 13.46mm)
Insertion Loss: 1.5dB
Specifications: Isolation (Min) 17dB, 1.7 VSWR, 6° Imbalance (Max)
Frequency: 6 GHz ~ 26.5 GHz

Hersteller: Mini-Circuits
Description: 4 WAYS DC PASS PS
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 2.035" L x 1.000" W x 0.530" H (51.70mm x 25.40mm x 13.46mm)
Insertion Loss: 1.6dB
Specifications: Isolation (Min) 18dB, 8° Imbalance (Max), 1.6 VSWR (Max)
Frequency: 18 GHz ~ 40 GHz

Hersteller: Mini-Circuits
Description: RF FILTER LOW PASS 2.5MHZ 8DIP
Packaging: Tube
Package / Case: 8-DIP Module
Filter Type: Low Pass
Size / Dimension: 0.785" L x 0.385" W (19.94mm x 9.78mm)
Mounting Type: Through Hole
Frequency: 2.5MHz (Cutoff)
Insertion Loss: 1dB
Height (Max): 0.400" (10.16mm)

Hersteller: Mini-Circuits
Description: CER FILTER 230MHZ LOW PASS
Packaging: Tape & Reel (TR)
Package / Case: 4-SMD, No Lead
Filter Type: Low Pass
Size / Dimension: 0.126" L x 0.063" W (3.20mm x 1.60mm)
Impedance: 50Ohm
Mounting Type: Surface Mount
Frequency: 230MHz
Insertion Loss: 1dB
Height (Max): 0.037" (0.94mm)

Hersteller: Mini-Circuits
Description: CER FILTER 230MHZ LOW PASS
Packaging: Cut Tape (CT)
Package / Case: 4-SMD, No Lead
Filter Type: Low Pass
Size / Dimension: 0.126" L x 0.063" W (3.20mm x 1.60mm)
Impedance: 50Ohm
Mounting Type: Surface Mount
Frequency: 230MHz
Insertion Loss: 1dB
Height (Max): 0.037" (0.94mm)

Hersteller: Mini-Circuits
Description: LTCC LOW PASS FILTER, DC - 120 M
Packaging: Tape & Reel (TR)
Package / Case: 1206 (3216 Metric), 4 PC Pad
Filter Type: Low Pass
Size / Dimension: 0.126" L x 0.063" W (3.20mm x 1.60mm)
Mounting Type: Surface Mount
Frequency: 120MHz
Insertion Loss: 1dB
Height (Max): 0.037" (0.95mm)

Hersteller: Mini-Circuits
Description: LTCC LOW PASS FILTER, DC - 120 M
Packaging: Cut Tape (CT)
Package / Case: 1206 (3216 Metric), 4 PC Pad
Filter Type: Low Pass
Size / Dimension: 0.126" L x 0.063" W (3.20mm x 1.60mm)
Mounting Type: Surface Mount
Frequency: 120MHz
Insertion Loss: 1dB
Height (Max): 0.037" (0.95mm)

Hersteller: Mini-Circuits
Description: LEVEL 18, COAXIAL IQ MIXER
Packaging: Tray
Package / Case: Module, SMA Connectors
Mounting Type: Chassis Mount
Frequency: 5GHz ~ 14GHz
RF Type: Radar
Secondary Attributes: Up/Down Converter
Number of Mixers: 2

Hersteller: Mini-Circuits
Description: LEVEL 7, RF/LO 3800 - 12000 MHZ
Packaging: Cut Tape (CT)
Package / Case: 10-SMD, No Lead
Mounting Type: Surface Mount
Frequency: 300MHz ~ 12GHz
RF Type: Radar
Current - Supply: 40mA
Secondary Attributes: Up/Down Converter
Number of Mixers: 1

Hersteller: Mini-Circuits
Description: DIPLEXER / SURF MOUNT / ROHS
Packaging: Cut Tape (CT)
Package / Case: 16-SMD, No Lead
Mounting Type: Surface Mount
Type: Diplexer
Frequency Bands (Low / High): 0Hz ~ 20MHz / 950MHz ~ 2.15GHz
Return Loss (Low Band / High Band): 15.0dB / 15.0dB

Hersteller: Mini-Circuits
Description: LUMPED LC LPF, DC - 50 MHZ, 50
Packaging: Cut Tape (CT)
Package / Case: 6-SMD Module
Filter Type: Low Pass
Size / Dimension: 0.250" L x 0.250" W (6.35mm x 6.35mm)
Mounting Type: Surface Mount
Frequency: 59MHz (Cutoff)
Insertion Loss: 2dB
Bandwidth: 50MHz
Height (Max): 0.100" (2.54mm)

Hersteller: Mini-Circuits
Description: IC RF SWITCH
Features: DC Blocked
Packaging: Bulk
Package / Case: Module, SMA Connectors
Impedance: 50Ohm
Mounting Type: Chassis Mount
Circuit: SP8T
RF Type: 5G, ATE, WiFi
Operating Temperature: -10°C ~ 60°C
Voltage - Supply: 4.75V ~ 5.25V
Insertion Loss: 7dB
Frequency Range: 10MHz ~ 8.5GHz
Topology: Absorptive
P1dB: 35dBm
Test Frequency: 8.5GHz
Isolation: 55dB
IIP3: 50dBm

Hersteller: Mini-Circuits
Description: USB-1SP8T-63H
Features: DC Blocked
Packaging: Bulk
Package / Case: Module, SMA Connectors
Impedance: 50Ohm
Mounting Type: Chassis Mount
Circuit: SP8T
RF Type: ATE, Cellular
Operating Temperature: 0°C ~ 50°C
Voltage - Supply: 4.75V ~ 5.25V
Insertion Loss: 5.8dB
Frequency Range: 10MHz ~ 6GHz
Topology: Absorptive
P1dB: 35dBm
Test Frequency: 6GHz
Isolation: 60dB
IIP3: 50dBm

Hersteller: Mini-Circuits
Description: 90 HYBRID, 330 - 580 MHZ, 50
Packaging: Tray
Package / Case: Module, SMA Connectors
Size / Dimension: 1.040" L x 0.600" W x 0.780" H (26.42mm x 15.24mm x 19.81mm)
Insertion Loss: 0.5dB
Frequency: 330 MHz ~ 580 MHz
