Produkte > PEAKTECH > Alle Produkte des Herstellers PEAKTECH (739) > Seite 4 nach 13

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (4000); VDC: 400mV,4V,40V,400V,600V
Conform to the norm: CAT III 600V; EN 61010
Power supply: battery 6LR61 9V x1
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; temperature probe; test leads; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Measuring range: 4000lx...40000klx
Measuring instrument features: auto and manual ranging; HOLD function
Type of meter: digital multimeter
Continuity test: acoustic indication; <50Ω
Humidity measuring accuracy: ±3%
Sound level measuring accuracy: ±5dB
Sound level measuring range: 35...100dB
Temperature measuring range: -20...1300°C
Humidity measuring range: 33...99% RH
Measurement: AC current; AC voltage; ambient temperature; capacitance; continuity; DC current; DC voltage; frequency; humidity; illuminance; resistance; sound level
Dimensions (W x H x D): 78x170x48mm
AC current measuring range: 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 40MΩ
DC current measuring range: 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
DC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
AC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
Frequency measuring range: 5Hz; 50Hz; 500Hz; 5kHz; 50kHz; 500kHz; 10MHz
Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 100µF
Diode test: 1.4mA @2.8V
Display parameters: (4000)
Frequency measuring accuracy: ±(1.2%+3 digit)
Capacitance measuring accuracy: ±(3%+ 5 digit)
AC current measuring accuracy: ±(1.2% + 2 digit)
DC voltage measuring accuracy: ±(1% + 4 digit)
DC current measuring accuracy: ±(1% + 2 digit)
AC voltage measuring accuracy: ±(1% + 4 digit)
Resistance measuring accuracy: ±(1.2%+2 digit)
Temperature measurement accuracy: ±(3% + 3°C)
Kind of display used: LCD

Hersteller: PEAKTECH
Category: LCR Meter
Description: CR meter; LCD; 3,5 digit; C accuracy: ±(0.5%+10digit); 1mA@2.8V
Type of meter: CR meter
Kind of display used: LCD
Display parameters: 3,5 digit
Resistance measuring range: 20Ω; 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ; 200MΩ; 2GΩ
Resistance measuring accuracy: ±(0.8%+1 digit)
Capacitance measuring range: 20pF; 200pF; 2nF; 20nF; 200nF; 2µF; 20µF; 200µF; 2mF; 20mF
Capacitance measuring accuracy: ±(0.5%+ 10 digit)
Diode test: 1mA @2.8V
Continuity test: acoustic indication; <120Ω
Measurement: capacitance; continuity; resistance
Power supply: battery 6LR61 9V x1
Battery/ rechargeable battery: battery 6LR61 9V x1
Dimensions: 85x175x40mm
Measuring instrument features: socket for testing transistors' gain (hFE) parameter
Standard equipment: test leads; user's manual

Hersteller: PEAKTECH
Category: LCR Meter
Description: CR meter; LCD; (5999); R range: 600Ω,6kΩ,60kΩ,600kΩ,6MΩ,60MΩ
Type of meter: CR meter
Kind of display used: LCD
Display parameters: (5999)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF
Capacitance measuring accuracy: ±(3%+ 3 digit)
Resistance measuring accuracy: ±(1.2%+2 digit)
Diode test: 1mA @2.8V
Continuity test: acoustic indication; <30Ω
Measurement: capacitance; continuity; resistance
Battery/ rechargeable battery: battery LR44 1,5V x2
Power supply: battery LR44 1,5V x2
Dimensions: 181x35x20mm
Measuring instrument features: automatic power-off; low battery indicator
Standard equipment: user's manual

Hersteller: PEAKTECH
Category: LCR Meter
Description: LCR meter; LCD; 3,5 digit (1999); 2nF,20nF,200nF,2uF,20uF,200uF
Type of meter: LCR meter
Kind of display used: LCD
Display parameters: 3,5 digit (1999)
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ
Resistance measuring accuracy: ±(0.8%+1 digit)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 20µF; 200µF
Capacitance measuring accuracy: ±(1%+ 5 digit)
Inductance measuring range: 2mH; 20mH; 200mH; 2H; 20H
Inductance measuring accuracy: ±(2% + 8 digit)
Diode test: 1mA @5.8V
Continuity test: acoustic indication; <10Ω
Measurement: capacitance; continuity; inductance; resistance
Power supply: battery 6LR61 9V x1
Battery/ rechargeable battery: battery 6LR61 9V x1
Dimensions: 85x175x40mm
Measuring instrument features: impact resistant holster; low battery indicator; socket for testing transistors' gain (hFE) parameter
Standard equipment: test leads; user's manual

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 4,3"; Ch: 2; 1Mpts; 0÷40°C
Type of generator: arbitrary, function
Maximum waveform frequency: 160MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...30MHz (arbitrary waveform); 1µHz...50MHz (pulse waveform); 1µHz...50MHz (rectangular waveform); 1µHz...160MHz (sinus waveform)
Kind of display used: LCD TFT 4,3"
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Sweep mode: mode: linear or logarithmic; period: 1m...500s
Arbitrary waveform: sampling: 500Msps; vertical resolution: 14 bit
Dimensions: 367x256x106mm
Interface: LAN; USB
Kind of modulation: 4FSK; 4PSK; AM; ASK; FM; FSK; OSK; PM; PSK; PWM; QFSK; QPSK; SUM
Waveforms: arbitrary; impulse; rectangular; sinus
Sampling: 500Msps
Operating temperature: 0...40°C
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Software: included
Supply voltage frequency: 45...65Hz
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: function; Maximum waveform frequency: 3MHz; LED; Ch: 1
Type of generator: function
Maximum waveform frequency: 3MHz
Waveform frequency range: 10µHz...1MHz (other waveforms); 10µHz...3MHz (rectangular waveform); 10µHz...3MHz (sinus waveform)
Kind of display used: LED
Display parameters: 6 digits
Number of channels: 1
Memory record length: 1024pts
Vertical resolution: 8bit
Sweep mode: mode: linear or logarithmic; period: 50m...500s
Dimensions: 255x100x310mm
Interface: USB
Kind of modulation: AM; FM; FSK; PM; PWM
Waveforms: rectangular; sinus; triangle
Sampling: 100Msps
Operating temperature: 0...40°C
Additional functions: included mocy 10W Power Amplifier
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Software: included
Supply voltage frequency: 50...60Hz
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: function; Maximum waveform frequency: 20MHz; LED; Ch: 1
Operating temperature: 0...40°C
Kind of display used: LED
Supply voltage: 100...240V AC
Type of generator: function
Interface: USB
Number of channels: 1
Supply voltage frequency: 50...60Hz
Dimensions: 255x100x310mm
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Additional functions: included mocy 10W Power Amplifier
Sampling: 100Msps
Waveform frequency range: 10µHz...1MHz (other waveforms); 10µHz...5MHz (rectangular waveform); 10µHz...20MHz (sinus waveform)
Sweep mode: mode: linear or logarithmic; period: 50m...500s
Vertical resolution: 8bit
Kind of modulation: AM; FM; FSK; PM; PWM
Waveforms: rectangular; sinus; triangle
Maximum waveform frequency: 20MHz
Software: included
Memory record length: 1024pts
Display parameters: 6 digits

Hersteller: PEAKTECH
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LED; 4,83 digit (63000); True RMS
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE046; SE047; SE048; SE049; SE050; SE051; SE052; SE053; SE054; SE055; SE056; SE057; SE058; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06280027; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Body dimensions: 240x100x350mm
Interface: Bluetooth; LAN; RS232; USB
Supply voltage: 100...240V AC
True effective value measurement: True RMS
Measurement: AC current; AC voltage; capacitance; continuity; crest factor; DC current; DC voltage; frequency; resistance; temperature (external probe required)
AC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
Frequency measuring range: 4...60kHz; 4...60MHz
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF
Diode test: 1mA @2.2V
Display parameters: 4,83 digit (63000)
Frequency measuring accuracy: ±(0.01%+10 digit)
Capacitance measuring accuracy: ±(2%+ 150 digit)
AC current measuring accuracy: ±(0.8% + 80 digit)
DC voltage measuring accuracy: ±(0.03% + 6 digit)
DC current measuring accuracy: ±(0.15% + 10 digit)
AC voltage measuring accuracy: ±(0.7% + 80 digit)
Resistance measuring accuracy: ±(0.1%+5 digit)
Temperature measurement accuracy: ±0.7°C
Kind of display used: LED
Conform to the norm: CAT II 600V; EN 61010
Standard equipment: 4GB SD memory card; mains cable; RS232 cable; test leads; thermocouple; USB cable; user's manual
Measuring instrument features: auto and manual ranging; data logger function; for use with type-K, J, E, N, T, B, R, S thermocouple; for use with type Pt 100, Pt 500, Pt 1000 thermocouple; MIN/MAX/REL function; PEAK function
Type of meter: benchtop multimeter
Continuity test: acoustic indication; <7Ω
Temperature measuring range: -200...1370°C

Hersteller: PEAKTECH
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD; 4,5 digit (22000); Illumin: yes; 230VAC
Body dimensions: 268x108x322mm
Conform to the norm: CAT I 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Frequency measuring range: 20...220MHz
Capacitance measuring range: 22nF; 220nF; 2.2µF; 22µF; 220µF; 2.2mF; 22mF
Diode test: 2V
Software: included
Display parameters: 4,5 digit (22000)
Frequency measuring accuracy: ±(0.06%+10 digit)
Capacitance measuring accuracy: ±(2%+ 5 digit)
AC current measuring accuracy: ±(0.8% + 30 digit)
DC voltage measuring accuracy: ±(0.05% + 6 digit)
DC current measuring accuracy: ±(0.2% + 15 digit)
AC voltage measuring accuracy: ±(0.5% + 30 digit)
Resistance measuring accuracy: ±(0.1%+10 digit)
Temperature measurement accuracy: ±(1.5% + 3°C)
Kind of display used: LCD
Power supply: battery R14 1,5V x6
Supply voltage: 230V AC
Interface: USB
Illumination: yes
Standard equipment: case; mains cable; test leads; USB cable; user's manual
Measuring instrument features: auto and manual ranging; for use with type-K thermocouple; HOLD function; MIN/MAX/REL function
Type of meter: benchtop multimeter
Continuity test: acoustic indication; <30Ω
Temperature measuring range: -20...1000°C
True effective value measurement: True RMS
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature (external probe required)
AC current measuring range: 220µA; 2.2mA; 22mA; 220mA; 10A
Resistance measuring range: 220Ω; 2.2kΩ; 22kΩ; 220kΩ; 2.2MΩ; 22MΩ; 220MΩ
DC current measuring range: 220µA; 2.2mA; 22mA; 220mA; 10A
DC voltage measuring range: 220mV; 2.2V; 22V; 220V; 600V
AC voltage measuring range: 220mV; 2.2V; 22V; 220V; 600V

Hersteller: PEAKTECH
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD TFT 4"; 4,5 digit (55000); 480x320
Standard equipment: crocodile clip; fuse; mains cable; test probe x1
Supply voltage: 110...240V AC
Body dimensions: 235x110x295mm
Kind of display used: LCD TFT 4"
Interface: RS232
Conform to the norm: CAT I 1000V; EN 61010
Display resolution: 480x320
Measuring instrument features: data logger function; for use with type-K thermocouple; for use with type Pt 100 thermocouple
Type of meter: benchtop multimeter
Continuity test: acoustic indication
Temperature measuring range: -270...1372°C
True effective value measurement: True RMS
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; period; resistance; temperature (external probe required)
AC current measuring range: 500µA...500mA; 5...10A
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
AC voltage measuring range: 500mV...750V
Frequency measuring range: 10kHz...60MHz
Capacitance measuring range: 50nF...500µF; 5...50mF
Diode test: 1mA @3V
Software: included
Display parameters: 4,5 digit (55000)
Frequency measuring accuracy: ±(0.2%+8 digit)
Capacitance measuring accuracy: ±(2.5%+5 digit) @ 50nF...500µF; ±(5%+8 digit) @ 5mF...50mF
AC current measuring accuracy: ±(0.5% + 20 digit)@(500µA...500mA); ±(1.5% + 10 digit)@(5A...10A)
DC voltage measuring accuracy: ±(0.025% + 5 digit) @(500mV...5V); ±(0.03% + 5 digit) @50V; ±(0.1% + 5 digit) @(500V...1kV); ±(0.1% + 10 digit) @50mV
DC current measuring accuracy: ±(0.15% + 10 digit) @(5mA...500mA); ±(0.15% + 20 digit) @(500µA...50mA); ±(0.5% + 10 digit) @(5A...10A)
AC voltage measuring accuracy: ±(0.5% + 30 digit); ±(0.7% + 30 digit); ±(1% + 30 digit)
Resistance measuring accuracy: ±(0.1%+5 digit)@(5kΩ); ±(0.1%+5 digit)@(50kΩ); ±(0.1%+5 digit)@(500kΩ); ±(0.1%+10 digit)@(500Ω); ±(0.25%+5 digit)@(5MΩ); ±(1%+10 digit)@(50MΩ)
Temperature measurement accuracy: ±0.5°C

Hersteller: PEAKTECH
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD TFT 4"; 4,5 digit (60000); 480x320
Type of meter: benchtop multimeter
Kind of display used: LCD TFT 4"
Display parameters: 4,5 digit (60000)
Display resolution: 480x320
True effective value measurement: True RMS
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.02% + 0.01% range)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.06% range)
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.06% + 0.02% range)
AC current measuring range: 60mA; 600mA; 6A; 10A
AC current measuring accuracy: ±(0.5% + 0.1% range)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ
Resistance measuring accuracy: ±(0.02%+6 digit); ±(0.03%+0.01% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Temperature measuring range: -20...1372°C
Temperature measurement accuracy: ±0.5°C
Diode test: 1mA @3V
Continuity test: acoustic indication; <30Ω
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; period; resistance; temperature (external probe required)
Interface: LAN; RS232; USB
Conform to the norm: CAT I 1000V; CAT II 600V; EN 61010
Body dimensions: 235x110x295mm
Measuring instrument features: data logger function; for use with type-K, J, E, N, T, B, R, S thermocouple; for use with type Pt 385, Pt 100 thermocouple; MIN/MAX/AVG function; REL function
Standard equipment: mains cable; temperature probe; test leads; USB cable; user's manual
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE046; SE047; SE048; SE049; SE050; SE051; SE052; SE053; SE054; SE055; SE056; SE057; SE058; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06280027; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD TFT 4"; 5,5 digit (200000); 480x320
Type of meter: benchtop multimeter
Kind of display used: LCD TFT 4"
Display parameters: 5,5 digit (200000)
Display resolution: 480x320
True effective value measurement: True RMS
DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV
DC voltage measuring accuracy: ±(0.0015% + 0.0005% range)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V
AC voltage measuring accuracy: ±(0.01% + 0.005% range)
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A
DC current measuring accuracy: ±(0.002% + 0.001% range)
AC current measuring range: 20mA; 200mA; 2A; 10A
AC current measuring accuracy: ±(0.015% + 0.005% range)
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.003%+0.0005% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(0.02%+ 0.001% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.002% + 0.001% range)
Temperature measuring range: -20...1372°C
Temperature measurement accuracy: ±0.5°C
Diode test: 1mA @2V
Continuity test: acoustic indication; <30Ω
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; period; resistance; temperature (external probe required)
Interface: LAN; RS232; USB
Conform to the norm: CAT I 1000V; CAT II 600V; EN 61010
Body dimensions: 235x110x295mm
Measuring instrument features: data logger function; for use with type-K, J, E, N, T, B, R, S thermocouple; for use with type Pt 385, Pt 100 thermocouple; MIN/MAX/AVG function; REL function
Standard equipment: mains cable; temperature probe; test leads; USB cable; user's manual
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE046; SE047; SE048; SE049; SE050; SE051; SE052; SE053; SE054; SE055; SE056; SE057; SE058; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06280027; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 4,3"; Ch: 2; 4096pts
Operating temperature: 0...40°C
Dimensions: 256x102x322mm
Interface: LAN; USB
Number of channels: 2
Supply voltage frequency: 50...60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Additional functions: frequency meter
Sampling: 120Msps
Waveform frequency range: 1µHz...5MHz (other waveforms); 1µHz...10MHz (pulse waveform); 1µHz...10MHz (rectangular waveform); 1µHz...30MHz (sinus waveform)
Sweep mode: mode: linear or logarithmic; period: 5m...500s
Vertical resolution: 14bit
Kind of modulation: AM; BPSK; FM; FSK; PM; PSK; PWM; SUM
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 30MHz
Software: included
Memory record length: 4096pts
Kind of display used: LCD TFT 4,3"
Supply voltage: 100...240V AC
Type of generator: arbitrary, function

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 4,3"; Ch: 2; 4096pts
Type of generator: arbitrary, function
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...5MHz (other waveforms); 1µHz...10MHz (pulse waveform); 1µHz...10MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: LCD TFT 4,3"
Number of channels: 2
Memory record length: 4096pts
Vertical resolution: 14bit
Sweep mode: mode: linear or logarithmic; period: 5m...500s
Dimensions: 256x102x322mm
Interface: LAN; USB
Kind of modulation: AM; BPSK; FM; FSK; PM; PSK; PWM; SUM
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Sampling: 150Msps
Operating temperature: 0...40°C
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Software: included
Supply voltage frequency: 50...60Hz
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 1
Kind of display used: LCD TFT 3,9"
Display resolution: 480x320
Dimensions: 235x110x295mm
Supply voltage: 110V AC; 230V AC
Operating temperature: 0...40°C
Interface: USB
Software: LabVIEW
Memory record length: 8kpts
Type of generator: arbitrary, function
Number of channels: 1
Supply voltage frequency: 50/60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 125Msps
Amplitude: 1mVpp...12,5Vpp @ 50Ω
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...5MHz (arbitrary waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...5MHz (sinus waveform)
Vertical resolution: 14bit
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 5MHz

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 1
Kind of display used: LCD TFT 3,9"
Display resolution: 480x320
Dimensions: 235x110x295mm
Supply voltage: 110V AC; 230V AC
Operating temperature: 0...40°C
Interface: USB
Software: included
Memory record length: 8kpts
Type of generator: arbitrary, function
Number of channels: 1
Supply voltage frequency: 50/60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 125Msps
Waveform frequency range: 1µHz...5MHz (arbitrary waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...5MHz (sinus waveform); 10µHz...1MHz (ramp waveform)
Vertical resolution: 14bit
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 5MHz

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 1
Kind of display used: LCD TFT 3,9"
Display resolution: 480x320
Dimensions: 235x110x295mm
Supply voltage: 110V AC; 230V AC
Operating temperature: 0...40°C
Interface: USB
Software: LabVIEW
Memory record length: 8kpts
Type of generator: arbitrary, function
Number of channels: 1
Supply voltage frequency: 50/60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 125Msps
Amplitude: 1mVpp...12,5Vpp @ 50Ω
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...5MHz (arbitrary waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...10MHz (sinus waveform)
Vertical resolution: 14bit
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 10MHz

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 2
Kind of display used: LCD TFT 3,9"
Display resolution: 480x320
Dimensions: 235x110x295mm
Supply voltage: 110V AC; 230V AC
Operating temperature: 0...40°C
Interface: USB
Software: included
Memory record length: 8kpts
Type of generator: arbitrary, function
Number of channels: 2
Supply voltage frequency: 50/60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 125Msps
Amplitude: 1mVpp...12,5Vpp @ 50Ω
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...10MHz (arbitrary waveform); 1µHz...10MHz (sinus waveform)
Vertical resolution: 14bit
Kind of modulation: AM; FM; FSK; PM
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 10MHz

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 2
Operating temperature: 0...40°C
Display resolution: 480x320
Supply voltage frequency: 50/60Hz
Dimensions: 235x110x295mm
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 125Msps
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...10MHz (arbitrary waveform); 1µHz...10MHz (sinus waveform)
Vertical resolution: 14bit
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 10MHz
Software: included
Memory record length: 8kpts
Kind of display used: LCD TFT 3,9"
Supply voltage: 110V AC; 230V AC
Type of generator: arbitrary, function
Interface: USB
Number of channels: 2

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 2
Number of channels: 2
Operating temperature: 0...40°C
Dimensions: 235x110x295mm
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Interface: RS232; USB
Sampling: 125Msps
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 25MHz
Software: included
Memory record length: 8kpts
Kind of display used: LCD TFT 3,9"
Supply voltage: 110V AC; 230V AC
Type of generator: arbitrary, function
Display resolution: 480x320
Supply voltage frequency: 50/60Hz
Additional functions: frequency meter
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...10MHz (arbitrary waveform); 1µHz...25MHz (sinus waveform)
Sweep mode: mode: linear or logarithmic; period: 1m...500s
Vertical resolution: 14bit
Kind of modulation: AM; FM; FSK; PM

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷1.5GHz; In.imp: 50Ω; 9kHz÷1.5GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Additional functions: built-in tracking generator
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...1.5GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...1.5GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷1.5GHz; In.imp: 50Ω; 9kHz÷1.5GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...1.5GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...1.5GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷2.2GHz; In.imp: 50Ω; 9kHz÷2.2GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Additional functions: built-in tracking generator
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...2.2GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...2.2GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷2.2GHz; In.imp: 50Ω; 9kHz÷2.2GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...2.2GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...2.2GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷3GHz; In.imp: 50Ω; 9kHz÷3GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Additional functions: built-in tracking generator
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...3GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...3GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Spectrum Analyzers
Description: Spectrum analyzer; Band: 10MHz÷3GHz; In.imp: 50Ω; 9kHz÷3GHz
Kind of display used: LCD TFT 7"
Interface: LAN; RS232; USB; VGA
Kind of input connector: N female
Kind of output connector: N female
Dimensions: 365x155x300mm
Standard equipment: mains cable; USB cable; user's manual
Type of meter: spectrum analyzer
Trigger: external; free; video signal
Band: 10MHz...3GHz
Software: included
Supply voltage: 100...240V AC
Frequency: 9kHz...3GHz
Display resolution: 800x480
Input impedance: 50Ω

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Display resolution: 320x240
Dimensions: 175x260x65mm
Related items: PKT-P4145-5A; PKT-P4145-50A; PKT-P4145-100A; PKT-P4145-1000A; PKT-P4145-3000A
Standard equipment: adapter DC; aligator clip x5; Rogowski coil x4; test leads ( 5pcs.); user's manual
Measuring instrument features: built in 8GB microSD memory card; data logger function; graphical display of measurement results
Type of meter: power quality analyser
Measurement: AC current; active power; AC voltage; apparent power; frequency; inrush current; power factor; reactive power; THD
AC voltage measuring range: 1kV
Software: included
Kind of display used: LCD TFT 5,6"
Power supply: rechargeable battery Ni-MH x1
Kind of network: single-phase; three-phase
Interface: LAN; USB

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Current clamp; Øcable: 52mm; 50÷60Hz; 500mA÷1kA; 1%; BNC (m)
Conform to the norm: CAT III 600V; EN 61010
Related items: PKT-P4145
Cable length: 2.9m
Type of test accessories: current clamp
Dimensions: 110x215x45mm
Max. diameter of measured cable: 52mm
Accuracy: 1%
AC current measuring range: 500mA...1kA
Bandwidth for AC current measurements: 50...60Hz
Kind of connector: BNC (m)

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Current clamp; Øcable: 13mm; 50÷400Hz; 0÷100A; 0.2%; BNC (m)
Related items: PKT-P4145
Cable length: 2.8m
Type of test accessories: current clamp
Dimensions: 45x175x27mm
Max. diameter of measured cable: 13mm
Accuracy: 0.2%
AC current measuring range: 0...100A
Bandwidth for AC current measurements: 50...400Hz
Kind of connector: BNC (m)

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Current clamp; Øcable: 160mm; 50÷60Hz; 0÷3kA; 1%; BNC (m)
Related items: PKT-P4145
Type of test accessories: current clamp
Max. diameter of measured cable: 160mm
Accuracy: 1%
AC current measuring range: 0...3kA
Bandwidth for AC current measurements: 50...60Hz
Kind of connector: BNC (m)

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Current clamp; Øcable: 8mm; 50÷400Hz; 0÷50A; 0.2%; BNC (m)
Related items: PKT-P4145
Cable length: 2.8m
Type of test accessories: current clamp
Dimensions: 52x174x35mm
Max. diameter of measured cable: 8mm
Accuracy: 0.2%
AC current measuring range: 0...50A
Bandwidth for AC current measurements: 50...400Hz
Kind of connector: BNC (m)

Hersteller: PEAKTECH
Category: Power Quality Analyzers
Description: Current clamp; Øcable: 8mm; 45÷60Hz; 0÷5A; 0.2%; BNC (m); Len: 1.9m
Related items: PKT-P4145
Cable length: 1.9m
Type of test accessories: current clamp
Dimensions: 45x160x25mm
Max. diameter of measured cable: 8mm
Accuracy: 0.2%
AC current measuring range: 0...5A
Bandwidth for AC current measurements: 45...60Hz
Kind of connector: BNC (m)

Hersteller: PEAKTECH
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; LCD TFT 3,9"; 480x320; Ch: 2
Kind of display used: LCD TFT 3,9"
Display resolution: 480x320
Dimensions: 235x110x295mm
Supply voltage: 110V AC; 230V AC
Operating temperature: 0...40°C
Interface: RS232; USB
Additional functions: frequency meter
Software: included
Memory record length: 1Mpts
Type of generator: arbitrary, function
Number of channels: 2
Supply voltage frequency: 50/60Hz
Standard equipment: BNC cable; mains cable; USB cable; user's manual
Sampling: 250Msps
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...10MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Sweep mode: mode: linear or logarithmic; period: 1m...500s
Vertical resolution: 14bit
Kind of modulation: AM; FM; FSK; PM; PWM
Waveforms: arbitrary; impulse; noise; ramp; rectangular; sinus
Maximum waveform frequency: 60MHz

Hersteller: PEAKTECH
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; digital,pincers type; Øcable: 16mm
Type of test accessories: AC current clamp adapter
Kind of meter: digital; pincers type
Max. diameter of measured cable: 16mm
AC current measuring range: 200A
Bandwidth for AC current measurements: 40...400Hz
Dimensions: 111x50x33mm
Standard equipment: case; user's manual
Conform to the norm: CAT II 600V; EN 61010
Kind of connector: 2x tip with 4mm banana plug

Hersteller: PEAKTECH
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 160mm; I AC: 30A,300A,3kA
Type of test accessories: AC current clamp adapter
Max. diameter of measured cable: 160mm
AC current measuring range: 30A; 300A; 3kA
Power supply: battery AAA 1,5V x2
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Cable length: 1m
Kind of connector: banana 4mm plug x2
Battery/ rechargeable battery: battery AAA 1,5V x2

Hersteller: PEAKTECH
Category: Meters and AC/DC Clamp Probes
Description: AC/DC current clamp adapter; Øcable: 9mm; I DC: 60A; I AC: 60A
Conform to the norm: CAT II 300V; EN 61010
Type of test accessories: AC/DC current clamp adapter
Dimensions: 65x195x32mm
Standard equipment: user's manual
Max. diameter of measured cable: 9mm
Measurement: AC current; DC current
AC current measuring range: 60A
Bandwidth for AC current measurements: 40Hz...2kHz
DC current measuring range: 60A
Battery/ rechargeable battery: battery 6LR61 9V x1
AC current measuring accuracy: ±(2% + 5mA)
DC current measuring accuracy: ±(1.5% + 5mA)
Power supply: battery 6LR61 9V x1

Hersteller: PEAKTECH
Category: Meters and AC/DC Clamp Probes
Description: AC/DC current clamp adapter; Øcable: 57mm; I DC: 200A,1kA
Type of test accessories: AC/DC current clamp adapter
Max. diameter of measured cable: 57mm
DC current measuring range: 200A; 1kA
AC current measuring range: 200A; 1kA
DC current measuring accuracy: ±(1.5% + 2A)
AC current measuring accuracy: ±(1.5% + 2A)
Dimensions: 100x240x43mm
Power supply: battery 6LR61 9V x1
Standard equipment: user's manual
Measurement: AC current; DC current
Conform to the norm: CAT II 1000V; EN 61010
Battery/ rechargeable battery: battery 6LR61 9V x1

Hersteller: PEAKTECH
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 12mm; LCD
Kind of display used: LCD
Illumination: yes
Dimensions: 70x210x37mm
Max. diameter of measured cable: 12mm
Temperature measuring range: -20...760°C
True effective value measurement: True RMS
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; leakage current; resistance; temperature
Kind of meter: digital; pincers type
AC current measuring range: 5...80A
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
Bandwidth for AC current measurements: 40...400Hz
DC current measuring range: 5...80A
DC voltage measuring range: 500mV; 5V; 50V; 500V; 600V
AC voltage measuring range: 500mV; 5V; 50V; 500V; 600V
Frequency measuring range: 5...10MHz
Capacitance measuring range: 50nF; 500nF; 5µF; 50µF; 500µF
Diode test: 1.5mA @3V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Display parameters: 3,8 digit (4999)
Frequency measuring accuracy: ±(1.2%+3 digit)
Capacitance measuring accuracy: ±(3.5%+ 10 digit)
AC current measuring accuracy: ±(2.5% + 25 digit)
DC voltage measuring accuracy: ±(1.5% + 2 digit)
DC current measuring accuracy: ±(2.5% + 30 digit)
AC voltage measuring accuracy: ±(2% + 4 digit)
Resistance measuring accuracy: ±(1.5%+2 digit)
Temperature measurement accuracy: ±(2% + 3 digit)
Power supply: battery LR03 AAA 1,5V x2
Conform to the norm: CAT III 600V; EN 61010
Standard equipment: case; K-type thermocouple; test leads; user's manual
Measuring instrument features: automatic power-off; HOLD function; MIN/MAX/REL function
Type of meter: multifunction
Continuity test: acoustic indication; <50Ω
Sampling: 2x/s

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; USB; LCD; (6000); VDC: 600mV,6V,60V,600V
Type of meter: digital multimeter
Interface: USB
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature; transistors' gain h_FE
Kind of display used: LCD
Display parameters: (6000)
Bargraph: yes
DC voltage measuring range: 600mV; 6V; 60V; 600V
DC voltage measuring accuracy: ±(0.5% + 5 digit)
AC voltage measuring range: 6V; 60V; 600V
AC voltage measuring accuracy: ±(1.5% + 10 digit)
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(1% + 7 digit)
AC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
AC current measuring accuracy: ±(1.8% + 10 digit)
True effective value measurement: True RMS
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 400µF; 1mF
Capacitance measuring accuracy: ±(2.5%+ 5 digit)
Frequency measuring range: 9.999...9.999MHz
Frequency measuring accuracy: ±(1%+5 digit)
Temperature measuring range: -20...1000°C
Temperature measurement accuracy: ±(1.5% + 4 digit)
Resistance measuring accuracy: ±(0.8%+5 digit)
Diode test: 0.8mA @3V
Continuity test: acoustic indication; 20Ω...150Ω
Power supply: battery 6LR61 9V x1
Standard equipment: adapters; case; K-type thermocouple; test leads; USB cable; user's manual
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 90x190x50mm
Measuring instrument features: auto and manual ranging; automatic power-off; HOLD function; low battery indicator; MIN/MAX/REL function; socket for testing transistors' gain (hFE) parameter
Battery/ rechargeable battery: battery 6LR61 9V x1
Software: included
Illumination: yes

Hersteller: PEAKTECH
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; 3,75 digit (4000)
Type of meter: insulation resistance
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; frequency; insulation resistance; resistance
Kind of display used: LCD
Display parameters: 3,75 digit (4000)
DC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
DC voltage measuring accuracy: ±(0.8% + 3 digit)
AC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
AC voltage measuring accuracy: ±(1% + 5 digit)
Bandwidth for AC voltage measurements: 40...400Hz
DC current measuring range: 40mA; 400mA
DC current measuring accuracy: ±(1.2% + 3 digit)
AC current measuring range: 40mA; 400mA
AC current measuring accuracy: ±(1.5% + 3 digit)
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Frequency measuring range: 4kHz; 40kHz; 400kHz; 4MHz; 40MHz; 100MHz
Frequency measuring accuracy: ±(0.8%+3 digit)
Resistance measuring accuracy: ±(1%+3 digit)
Insulation resistance measuring accuracy: ±(5% + 5digit)
Diode test: 0.3mA @3V
Continuity test: acoustic indication; <30Ω
Power supply: battery LR6 AA 1,5V x6
Standard equipment: case; test leads; user's manual
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 100x200x56mm
Measuring instrument features: auto and manual ranging; automatic power-off; HOLD function; MIN/MAX/REL function
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Insulation resistance measuring ranges: 0.1...4000MΩ

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,5 digit; -50÷380°C; Opt.resol: 10: 1
Type of meter: infrared thermometer
Kind of display used: LCD
Display parameters: 3,5 digit
Non-contact temperature measuring range: -50...380°C
Non-contact temperature measuring accuracy: ±(2% + 2°C)
Non-contact temperature measuring resolution: 0.1°C
Optical resolution: 10:1
Emissivity value: 0,95
Measurement: non-contact temeprature (IR)
Measuring unit: °C; °F
Sampling: 2,5x/s
Dimensions: 50x200x124mm
Power supply: battery 6LR61 9V x1
Measuring instrument features: automatic power-off; HOLD function
Standard equipment: case; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,5 digit; -50÷850°C; -50÷1370°C
Illumination: yes
Measuring unit: °C; °F
Dimensions: 47x180x100mm
Standard equipment: case; K-type thermocouple; user's manual
Measuring instrument features: alarms breach of limit values; automatic power-off; HOLD function; MIN/MAX/AVG function
Type of meter: infrared thermometer
Sampling: 6x/s
Optical resolution: 30:1
Response time: <0.15s
Non-contact temperature measuring range: -50...850°C
Emissivity value: 0,1...1
Temperature measuring range (with K-type thermocouple): -50...1370°C
Measurement: non-contact temeprature (IR); temperature (external probe required)
Non-contact temperature measuring resolution: 0.1°C
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,5 digit
Non-contact temperature measuring accuracy: ±(1.5% + 2°C)
Kind of display used: LCD
Power supply: battery 6LR61 9V x1

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD TFT 2,2"; 640x480; -50÷2200°C; ε: 0,1÷1
Type of meter: infrared thermometer
Kind of display used: LCD TFT 2,2"
Dimensions: 62x205x155mm
Power supply: rechargeable battery Li-Ion 3,7V 1400mAh x1
Measuring instrument features: data logger function
Standard equipment: case; K-type thermocouple; microSD 2GB memory card; power supply AC 230V; stand; USB cable; user's manual
Emissivity value: 0,1...1
Measurement: dew point; humidity; non-contact temeprature (IR); temperature (external probe required); wet bulb
Interface: USB
Measuring unit: °C; °F
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V 1400mAh x1
Display resolution: 640x480
Supported formats: 3GP; JPEG
Optical resolution: 50:1
Response time: <0.15s
Non-contact temperature measuring range: -50...2200°C
Temperature measuring range (with K-type thermocouple): -50...1370°C
Non-contact temperature measuring resolution: 0.1°C
Non-contact temperature measuring accuracy: ±(1% + 1°C)

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; -50÷1200°C; Accur.(IR): ±(1%+1°C)
Kind of display used: LCD
Power supply: battery 6LR61 9V x1
Interface: USB
Measuring unit: °C; °F
Dimensions: 55x225x155mm
Standard equipment: case; K-type thermocouple; stand; USB cable; user's manual
Measuring instrument features: acoustic alarm; alarms breach of limit values; automatic power-off; data logger function; HOLD function; MIN/MAX/AVG function
Type of meter: infrared thermometer
Optical resolution: 50:1
Response time: <0.15s
Non-contact temperature measuring range: -50...1200°C
Emissivity value: 0,1...1
Temperature measuring range (with K-type thermocouple): -50...1370°C
Measurement: non-contact temeprature (IR); temperature (external probe required)
Non-contact temperature measuring resolution: 0.1°C
Battery/ rechargeable battery: battery 6LR61 9V x1
Software: included
Non-contact temperature measuring accuracy: ±(1% + 1°C)

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,5 digit; -50÷380°C; Opt.resol: 12: 1
Type of meter: infrared thermometer
Kind of display used: LCD
Display parameters: 3,5 digit
Non-contact temperature measuring range: -50...380°C
Non-contact temperature measuring accuracy: ±(2% + 2°C)
Non-contact temperature measuring resolution: 0.1°C
Optical resolution: 12:1
Emissivity value: 0,95
Response time: <1s
Measurement: non-contact temeprature (IR)
Measuring unit: °C; °F
Dimensions: 45x160x82mm
Power supply: battery 6LR61 9V x1
Measuring instrument features: automatic power-off; HOLD function; MIN/MAX function; overflow indication
Standard equipment: case; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; -35÷260°C; Accur.(IR): ±2%,±2°C
Standard equipment: case; user's manual
Measuring unit: °C; °F
Dimensions: 52x183x25mm
Measuring instrument features: automatic power-off; built-in clamp for temperature measurement; embedded probe; HOLD function; LOCK function (settings lock); manual HOLD function or automatic PRE-HOLD; MIN/MAX function; overflow indication
Type of meter: infrared thermometer
Optical resolution: 1:1
Response time: <0.5s
Non-contact temperature measuring range: -35...260°C
Emissivity value: 0,1...1
Measurement: non-contact temeprature (IR)
Non-contact temperature measuring resolution: 0.1°C
Battery/ rechargeable battery: battery CR2032 3V x2
Non-contact temperature measuring accuracy: ±2%; ±2°C
Kind of display used: LCD
Power supply: battery CR2032 3V x2

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,5 digit; -50÷650°C; Opt.resol: 12: 1
Type of meter: infrared thermometer
Kind of display used: LCD
Display parameters: 3,5 digit
Non-contact temperature measuring range: -50...650°C
Non-contact temperature measuring accuracy: ±1%; ±2°C
Non-contact temperature measuring resolution: 0.1°C
Optical resolution: 12:1
Emissivity value: 0,1...1
Response time: <0.15s
Measurement: non-contact temeprature (IR)
Measuring unit: °C; °F
Sampling: 6x/s
Dimensions: 104x146x43mm
Power supply: battery 6LR61 9V x1
Measuring instrument features: alarms breach of limit values; MAX function
Standard equipment: case; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,5 digit; -50÷800°C; Opt.resol: 20: 1
Type of meter: infrared thermometer
Kind of display used: LCD
Display parameters: 3,5 digit
Non-contact temperature measuring range: -50...800°C
Non-contact temperature measuring accuracy: ±1%; ±2°C
Non-contact temperature measuring resolution: 0.1°C
Optical resolution: 20:1
Emissivity value: 0,1...1
Response time: <0.15s
Measurement: non-contact temeprature (IR)
Measuring unit: °C; °F
Sampling: 6x/s
Dimensions: 104x146x43mm
Power supply: battery 6LR61 9V x1
Measuring instrument features: alarms breach of limit values; HOLD function; MAX function
Standard equipment: case; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes

Hersteller: PEAKTECH
Category: Laboratory instruments - Others
Description: Tester: tester; LED; 25mA; 0÷300VDC; 100÷240VAC
Output voltage: 0...300V DC
Type of tester: tester
Maximum output current: 25mA
Dimensions: 126x77x36m
Standard equipment: case; crocodile clips; mains cable; test leads; test probes
Measuring instrument features: automatic and safe test; robust structure
Measuring instruments application: electrolytic capacitors; single LEDs or LED panels; Zener diodes
Kind of display used: LED
Supply voltage: 100...240V AC

Hersteller: PEAKTECH
Category: Luxmeters
Description: Light meter; 200/2000/20000/50000lx; 5%; lux; 65x115x25mm
Measurement accuracy: 5%
Measuring unit: lux
Measuring range: 200/2000/20000/50000lx
Dimensions: 65x115x25mm
Measuring instrument features: low battery indicator
Type of meter: light meter
Measurement: illuminance
Display parameters: 3,5 digit (1999)
Kind of display used: LCD
Power supply: battery A23 12V x1

Hersteller: PEAKTECH
Category: Meters of Env. Conditions - Others
Description: Meter: environmental conditions; LCD; 3,5 digit; 20/200/2k/20klx
Measuring range: 20/200/2k/20klx
Standard equipment: case; test probe x1; user's manual
Measuring instrument features: automatic power-off; HOLD function; MAX function; overflow indicator
Type of meter: environmental conditions
Humidity measuring accuracy: ±5%
Sound level measuring range: 35...130dB
Temperature measuring range measured by probe: -20...750°C
Humidity measuring range: 25...95% RH
Measurement: humidity; illuminance; sound level; temperature (external probe required)
Dimensions (W x H x D): 64x251x40mm
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,5 digit
Temperature measuring accuracy (measurement with probe): ±(3% + 2°C)
Kind of display used: LCD
Power supply: battery 6LR61 9V x1

Hersteller: PEAKTECH
Category: Thermohygrometers
Description: Thermo-hygrometer; LCD; -20÷100°C; 0÷100%RH; Accur: ±(0.5%+0.1°C)
Type of meter: thermo-hygrometer
Kind of display used: LCD
Measurement: ambient temperature; dew point; humidity; wet bulb
Power supply: battery LR03 AAA 1,5V x3
Standard equipment: case; user's manual
Measuring instrument features: HOLD function; low battery indicator; MIN/MAX function
Temperature measuring range: -20...100°C
Battery/ rechargeable battery: battery LR03 AAA 1,5V x3
Dimensions (W x H x D): 63x220x28mm
Temperature measurement accuracy: ±(0.5% + 0.1°C)
Operating temperature: 0...50°C
Humidity measuring accuracy: ±2%
Humidity measuring range: 0...100% RH
Storage temperature: -40...85°C

Hersteller: PEAKTECH
Category: Pirometers
Description: Infrared thermometer; LCD; 3,75 digit; -30÷550°C; -200÷1372°C
Dimensions: 75x201x50mm
Measuring unit: °C; °F
Standard equipment: case; IR-temperature sensor; K-type thermocouple x2; stand; user's manual
Measuring instrument features: automatic power-off; HOLD function; MAX function; T1-T2 function
Type of meter: infrared thermometer
Sampling: 2,5x/s
Optical resolution: 8:1
Non-contact temperature measuring range: -30...550°C
Emissivity value: 0,95
Temperature measuring range (with K-type thermocouple): -200...1372°C
Measurement: non-contact temeprature (IR); temperature (external probe required)
Non-contact temperature measuring resolution: 0.1°C
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,75 digit
Non-contact temperature measuring accuracy: ±(2.5% + 2°C)
Kind of display used: LCD
Power supply: battery 6LR61 9V x1
Illumination: yes

Hersteller: PEAKTECH
Category: Sound Meters
Description: Meter: sound level; LCD; 3,5 digit; Sound level: 35÷130dB
Operating frequency: 0.0315...8kHz
Standard equipment: case; user's manual
Measuring instrument features: built-in calibration check; HOLD function; low battery indicator; MAX function
Type of meter: sound level
Sound level measuring accuracy: ±1.5dB
Sound level measuring range: 35...130dB
Sound level measuring resolution: 0.1dB
Measurement: sound level
Dimensions (W x H x D): 64x251x40mm
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,5 digit
Kind of display used: LCD
Power supply: battery 6LR61 9V x1

Hersteller: PEAKTECH
Category: Luxmeters
Description: Light meter; 0÷100000lx; 4%; lux,foot-candle; 60x121x30mm; 180g
Illumination: yes
Dimensions: 60x121x30mm
Measuring range: 0...100000lx
Measuring instrument features: automatic power-off; HOLD function; low battery indicator; MIN/MAX function
Battery/ rechargeable battery: battery LR03 AAA 1,5V x3
Measurement accuracy: 4%
Display parameters: 5,5 digit (100000)
Type of meter: light meter
Measurement: illuminance
Kind of display used: LCD
Power supply: battery LR03 AAA 1,5V x3
Standard equipment: case
Measuring unit: foot-candle; lux

Hersteller: PEAKTECH
Category: Luxmeters
Description: Light meter; 40/400/4000/40000/400000lx,40/400/4k/40kfc; 3%
Type of meter: light meter
Kind of display used: LCD
Display parameters: 3,75 digit (3999)
Measuring range: 40/400/4k/40kfc; 40/400/4000/40000/400000lx
Measurement accuracy: 3%
Measurement: illuminance
Dimensions: 58x160x27mm
Power supply: battery LR03 AAA 1,5V x3
Standard equipment: case
Measuring instrument features: HOLD function; MIN/MAX/AVG function
Battery/ rechargeable battery: battery LR03 AAA 1,5V x3
Measurement memory: 99
Measuring unit: foot-candle; lux
Kind of measured light: standard
Sampling: 2,5x/s
