Produkte > CROMPTON / TE CONNECTIVITY > 039-90252-0000-5/10A-0-500/1000A
039-90252-0000-5/10A-0-500/1000A
  • 039-90252-0000-5/10A-0-500/1000A
  • 039-90252-0000-5/10A-0-500/1000A

039-90252-0000-5/10A-0-500/1000A CROMPTON / TE CONNECTIVITY

Analogue meters.pdf
Hersteller: CROMPTON / TE CONNECTIVITY
Category: Ammeters
Description: Ammeter; on panel; I AC: 0÷500A,1kA; True RMS; Class: 1.5; 50÷60Hz
IP rating: IP52
Mounting: on panel
True effective value measurement: True RMS
Input current: 5A; 10A
AC current measuring range: 0...500A; 1kA
Dimensions (W x H x D): 48x48mm
Accuracy class: 1.5
Frequency: 50...60Hz
Measurement: AC current
Type of meter: ammeter
Kind of meter: analogue; mounting
Kind of measurement: indirect with 5A current transformer
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details 039-90252-0000-5/10A-0-500/1000A CROMPTON / TE CONNECTIVITY

Category: Ammeters, Description: Ammeter; on panel; I AC: 0÷500A,1kA; True RMS; Class: 1.5; 50÷60Hz, IP rating: IP52, Mounting: on panel, True effective value measurement: True RMS, Input current: 5A; 10A, AC current measuring range: 0...500A; 1kA, Dimensions (W x H x D): 48x48mm, Accuracy class: 1.5, Frequency: 50...60Hz, Measurement: AC current, Type of meter: ammeter, Kind of meter: analogue; mounting, Kind of measurement: indirect with 5A current transformer.
