R76PI22204030J KEMET
Hersteller: KEMET
Description: CAP FILM 0.022UF 5% 630VDC RAD
Tolerance: ±5%
Packaging: Bulk
Package / Case: Radial
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 110°C
Applications: Automotive; High Frequency, Switching; High Pulse, DV/DT
Lead Spacing: 0.591" (15.00mm)
Termination: PC Pins
Ratings: AEC-Q200
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - AC: 400V
Voltage Rating - DC: 630V
Height - Seated (Max): 0.437" (11.10mm)
Capacitance: 0.022 µF
Size / Dimension: 0.709" L x 0.197" W (18.00mm x 5.00mm)
| Anzahl | Preis |
|---|---|
| 11+ | 1.74 EUR |
| 15+ | 1.2 EUR |
| 50+ | 0.96 EUR |
| 100+ | 0.88 EUR |
| 500+ | 0.73 EUR |
| 1000+ | 0.68 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details R76PI22204030J KEMET
Category: THT Film Capacitors, Description: Capacitor: polypropylene; R76; 22nF; Uoper: 630VDC; 400VAC; THT; ±5%, Mounting: THT, Operating temperature: -55...105°C, Capacitance: 22nF, Terminal pitch: 15mm, Body dimensions: 18x5x11mm, Lead length: 30mm, Tolerance: ±5%, Pulse resistance: 2.5kV/μs, Max. operating voltage: 400V AC; 630V DC, Operating voltage: 630V DC, Flammability rating: UL94V-0, Climate class: 55/105/56; IEC 60068-1, Conform to the norm: AEC-Q200, Kind of material: flame retardant, Type of capacitor: polypropylene, Manufacturer series: R76.
Weitere Produktangebote R76PI22204030J nach Preis ab 0.55 EUR bis 1.88 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
R76PI22204030J | KEMET |
Film Capacitors 630V 0.022 uF 110C 5% 2 Pin LS=15 mm AEC-Q200 |
auf Bestellung 2600 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
R76PI22204030J | KEMET |
Category: THT Film Capacitors Description: Capacitor: polypropylene; R76; 22nF; Uoper: 630VDC; 400VAC; THT; ±5% Mounting: THT Operating temperature: -55...105°C Capacitance: 22nF Terminal pitch: 15mm Body dimensions: 18x5x11mm Lead length: 30mm Tolerance: ±5% Pulse resistance: 2.5kV/μs Max. operating voltage: 400V AC; 630V DC Operating voltage: 630V DC Flammability rating: UL94V-0 Climate class: 55/105/56; IEC 60068-1 Conform to the norm: AEC-Q200 Kind of material: flame retardant Type of capacitor: polypropylene Manufacturer series: R76 |
auf Bestellung 7 Stücke: Lieferzeit 14-21 Tag (e) |
Mindestbestellmenge: 5 Stücke Im Einkaufswagen Stück im Wert von UAH |
| R76PI22204030J |
|
Hersteller: KEMET
Film Capacitors 630V 0.022 uF 110C 5% 2 Pin LS=15 mm AEC-Q200
Film Capacitors 630V 0.022 uF 110C 5% 2 Pin LS=15 mm AEC-Q200
auf Bestellung 2600 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 2+ | 1.88 EUR |
| 10+ | 0.97 EUR |
| 100+ | 0.87 EUR |
| 500+ | 0.71 EUR |
| 1000+ | 0.64 EUR |
| 2000+ | 0.57 EUR |
| 10000+ | 0.55 EUR |
| R76PI22204030J |
|
Hersteller: KEMET
Category: THT Film Capacitors
Description: Capacitor: polypropylene; R76; 22nF; Uoper: 630VDC; 400VAC; THT; ±5%
Mounting: THT
Operating temperature: -55...105°C
Capacitance: 22nF
Terminal pitch: 15mm
Body dimensions: 18x5x11mm
Lead length: 30mm
Tolerance: ±5%
Pulse resistance: 2.5kV/μs
Max. operating voltage: 400V AC; 630V DC
Operating voltage: 630V DC
Flammability rating: UL94V-0
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
Kind of material: flame retardant
Type of capacitor: polypropylene
Manufacturer series: R76
Category: THT Film Capacitors
Description: Capacitor: polypropylene; R76; 22nF; Uoper: 630VDC; 400VAC; THT; ±5%
Mounting: THT
Operating temperature: -55...105°C
Capacitance: 22nF
Terminal pitch: 15mm
Body dimensions: 18x5x11mm
Lead length: 30mm
Tolerance: ±5%
Pulse resistance: 2.5kV/μs
Max. operating voltage: 400V AC; 630V DC
Operating voltage: 630V DC
Flammability rating: UL94V-0
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
Kind of material: flame retardant
Type of capacitor: polypropylene
Manufacturer series: R76
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
