3570.1210.051 COMUS
Hersteller: COMUS
Category: Reed Electromagnetic Relays
Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 500mA; max.150VDC; 10W
Case: DIP14
Mounting: THT
Operating temperature: -20...85°C
Coil resistance: 500Ω
Contacts configuration: SPST-NO
Type of relay: reed switch
Relay series: 3570
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 7V DC
Switched voltage: max. 150V DC
Contact current max.: 0.5A
Switching capacity: 10W
Contact resistance: 0.15Ω
Terminal pitch: 2.54mm
Body dimensions: 19.5x6.9x6.9mm
Anzahl je Verpackung: 1 Stücke
Category: Reed Electromagnetic Relays
Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 500mA; max.150VDC; 10W
Case: DIP14
Mounting: THT
Operating temperature: -20...85°C
Coil resistance: 500Ω
Contacts configuration: SPST-NO
Type of relay: reed switch
Relay series: 3570
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 7V DC
Switched voltage: max. 150V DC
Contact current max.: 0.5A
Switching capacity: 10W
Contact resistance: 0.15Ω
Terminal pitch: 2.54mm
Body dimensions: 19.5x6.9x6.9mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 108 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
28+ | 2.6 EUR |
32+ | 2.3 EUR |
33+ | 2.17 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 3570.1210.051 COMUS
Category: Reed Electromagnetic Relays, Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 500mA; max.150VDC; 10W, Case: DIP14, Mounting: THT, Operating temperature: -20...85°C, Coil resistance: 500Ω, Contacts configuration: SPST-NO, Type of relay: reed switch, Relay series: 3570, Rated coil voltage: 5V DC, Coil voltage min.: 3.75V DC, Coil voltage max.: 7V DC, Switched voltage: max. 150V DC, Contact current max.: 0.5A, Switching capacity: 10W, Contact resistance: 0.15Ω, Terminal pitch: 2.54mm, Body dimensions: 19.5x6.9x6.9mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote 3570.1210.051 nach Preis ab 2.17 EUR bis 2.6 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3570.1210.051 | Hersteller : COMUS |
Category: Reed Electromagnetic Relays Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 500mA; max.150VDC; 10W Case: DIP14 Mounting: THT Operating temperature: -20...85°C Coil resistance: 500Ω Contacts configuration: SPST-NO Type of relay: reed switch Relay series: 3570 Rated coil voltage: 5V DC Coil voltage min.: 3.75V DC Coil voltage max.: 7V DC Switched voltage: max. 150V DC Contact current max.: 0.5A Switching capacity: 10W Contact resistance: 0.15Ω Terminal pitch: 2.54mm Body dimensions: 19.5x6.9x6.9mm |
auf Bestellung 108 Stücke: Lieferzeit 14-21 Tag (e) |
|
