77311-446-06LF FCI

Description: CONN HEADER VERT 6POS 2.54MM, Packaging: Bag, Connector Type: Header, Current Rating (Amps): 3A per Contact, Mounting Type: Through Hole, Number of Positions: 6, Number of Rows: 1, Style: Board to Board, Operating Temperature: -65°C ~ 125°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.100" (2.54mm), Contact Finish - Mating: Tin, Contact Finish Thickness - Mating: 78.7µin (2.00µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Square, Contact Length - Post: 0.117" (2.97mm), Insulation Height: 0.100" (2.54mm), Shrouding: Unshrouded, Overall Contact Length: 0.535" (13.59mm), Insulation Material: Thermoplastic, Contact Length - Mating: 0.318" (8.08mm).
