Produkte > BELDEN > 9501.01152
9501.01152

9501.01152 BELDEN


pVersion=0046&contRep=ZT&docId=E1C03C77FF6FD4F1A6F5005056AB5A8F&compId=9501_46775v4.pdf?ci_sign=f1c29255c9d4adac46d15e955ecdfe64f3caa76d Hersteller: BELDEN
Category: Serial Bus Cables
Description: Wire; 1x2x24AWG; RS232; stranded; Cu; shielded,Al-PET foil; PVC
Operating temperature: -30...80°C
Conform to the norm: UL 1685; UL 2464
Type of wire: data transmission
Wire insulation material: PVC
Insulation colour: chrome
Kind of core: Cu; tinned
Shield structure: Al-PET foil; shielded
Cable features: twisted pair conductors
Number of cores: 2
No. of pairs: 1
Core marking: colours with colour repetition
Cable application: indoor; RS232
Cable external diameter: 3.96mm
Core diameter: 24AWG
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Earth core: none
CPR standard: Eca
Package contents: 152m
Package contents - ft: 500ft
Kind of material: flame retardant; no flame propagation
Ground: tinned copper strand 24AWG
Cable structure: 1x2x24AWG
Rated voltage: 300V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 19 Stücke:

Lieferzeit 7-14 Tag (e)
Anzahl Preis
19+3.76 EUR
29+2.46 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
