Produkte > SCHNEIDER ELECTRIC > ATV212HU22N4
ATV212HU22N4

ATV212HU22N4 SCHNEIDER ELECTRIC


pVersion=0046&contRep=ZT&docId=005056AB281E1EDE808D77B8C53740D5&compId=ATV212HU22N4_EN.pdf?ci_sign=88a789e8578f2ccb885278141a15266f4490056f Hersteller: SCHNEIDER ELECTRIC
Category: Three Phase Inverters
Description: Vector inverter; 2.2kW; 3x400VAC; 3x380÷480VAC; 0÷10VDC; IP21
Related items: TCSMCNAM3M002P
Manufacturer series: ATV212
Electrical connection: screw terminals
Current rating: 5.1A
IP rating: IP21
Application: fans; for pump
Dimensions: 150x107x143mm
Type of module: vector inverter
Number of analog inputs: 2
Number of analog outputs: 1
The programming method: PC; push-buttons
Additional functions: PID regulator
Max motor power: 2.2kW
Protection: anti-overload OLP; anti-overload OPP; anti-overvoltage OVP; motor blockade; motor earth fault; overheating OTP; undervoltage UVP
Output frequency: 0.5...200Hz
Communictions protocol: BACnet/IP; Modbus
Voltage between phases (for three phase system): 3 x 380...480V AC
Inverter output voltage: 3 x 400V AC
Driver features: integrated EMC filter
Number of digital inputs: 3
Number of digital outputs: 2
Current output: 0...20mA
Voltage output: 0...10V DC
Trade name: Altivar
Mounting: for wall mounting
Operating temperature: -10...40°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1 Stücke:

Lieferzeit 7-14 Tag (e)
Anzahl Preis
1+747.85 EUR
3+719.08 EUR
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details ATV212HU22N4 SCHNEIDER ELECTRIC

Category: Three Phase Inverters, Description: Vector inverter; 2.2kW; 3x400VAC; 3x380÷480VAC; 0÷10VDC; IP21, Related items: TCSMCNAM3M002P, Manufacturer series: ATV212, Electrical connection: screw terminals, Current rating: 5.1A, IP rating: IP21, Application: fans; for pump, Dimensions: 150x107x143mm, Type of module: vector inverter, Number of analog inputs: 2, Number of analog outputs: 1, The programming method: PC; push-buttons, Additional functions: PID regulator, Max motor power: 2.2kW, Protection: anti-overload OLP; anti-overload OPP; anti-overvoltage OVP; motor blockade; motor earth fault; overheating OTP; undervoltage UVP, Output frequency: 0.5...200Hz, Communictions protocol: BACnet/IP; Modbus, Voltage between phases (for three phase system): 3 x 380...480V AC, Inverter output voltage: 3 x 400V AC, Driver features: integrated EMC filter, Number of digital inputs: 3, Number of digital outputs: 2, Current output: 0...20mA, Voltage output: 0...10V DC, Trade name: Altivar, Mounting: for wall mounting, Operating temperature: -10...40°C, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote ATV212HU22N4 nach Preis ab 747.85 EUR bis 1329.61 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
ATV212HU22N4 ATV212HU22N4 Hersteller : SCHNEIDER ELECTRIC pVersion=0046&contRep=ZT&docId=005056AB281E1EDE808D77B8C53740D5&compId=ATV212HU22N4_EN.pdf?ci_sign=88a789e8578f2ccb885278141a15266f4490056f Category: Three Phase Inverters
Description: Vector inverter; 2.2kW; 3x400VAC; 3x380÷480VAC; 0÷10VDC; IP21
Related items: TCSMCNAM3M002P
Manufacturer series: ATV212
Electrical connection: screw terminals
Current rating: 5.1A
IP rating: IP21
Application: fans; for pump
Dimensions: 150x107x143mm
Type of module: vector inverter
Number of analog inputs: 2
Number of analog outputs: 1
The programming method: PC; push-buttons
Additional functions: PID regulator
Max motor power: 2.2kW
Protection: anti-overload OLP; anti-overload OPP; anti-overvoltage OVP; motor blockade; motor earth fault; overheating OTP; undervoltage UVP
Output frequency: 0.5...200Hz
Communictions protocol: BACnet/IP; Modbus
Voltage between phases (for three phase system): 3 x 380...480V AC
Inverter output voltage: 3 x 400V AC
Driver features: integrated EMC filter
Number of digital inputs: 3
Number of digital outputs: 2
Current output: 0...20mA
Voltage output: 0...10V DC
Trade name: Altivar
Mounting: for wall mounting
Operating temperature: -10...40°C
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+747.85 EUR
Im Einkaufswagen  Stück im Wert von  UAH
ATV212HU22N4 ATV212HU22N4 Hersteller : Schneider Electric 5c99447f1ac34b2c58878cdee03bfa95f3e45ebc.pdf Description: VARIABLE SPEED DRIVE ATV212 - 2.
Packaging: Box
Mounting Type: Chassis Mount
Current - Output: 5.1A
Interface: RS-485
Type: Module
Operating Temperature: -10°C ~ 50°C
Voltage - Supply: 323V ~ 528V
Voltage - Load: 380 ~ 480V
Number of Motors: 1
Motor Type: AC Motor
Control / Drive Type: Variable Frequency Drive (VFD)
Part Status: Active
Wattage - Load: 2200 W
auf Bestellung 8 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+1131.84 EUR
Im Einkaufswagen  Stück im Wert von  UAH
ATV212HU22N4 ATV212HU22N4 Hersteller : Schneider Electric 5c99447f1ac34b2c58878cdee03bfa95f3e45ebc.pdf Motor Drives SPEEDDRIVE 380-480VAC 3HP,ATV212
auf Bestellung 3 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+1329.61 EUR
