BB060-06-A-L-D GCT

Description: 06W, 0.8MMX1.2MM PITCH SOCKET, D, Features: Board Guide, Packaging: Tube, Connector Type: Receptacle, Bottom or Top Entry, Voltage Rating: 250VAC/DC, Current Rating (Amps): 500mA, Mounting Type: Surface Mount, Number of Positions: 6, Style: Board to Board, Operating Temperature: -40°C ~ 105°C, Contact Type: Female Socket, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Insulation Color: Black, Pitch - Mating: 0.031" (0.80mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: FLASH, Contact Finish - Post: Gold, Insulation Height: 0.128" (3.25mm), Row Spacing - Mating: 0.047" (1.20mm), Number of Rows: 2.
