BLY 8 SMD 24 B SM Fischer Elektronik
Hersteller: Fischer ElektronikDescription: for 0.5 mm and up to 0.56 mm
Packaging: Tube
Connector Type: Header
Voltage Rating: 100VDC
Current Rating (Amps): 2.5A
Mounting Type: Surface Mount
Number of Positions: 24
Operating Temperature: -40°C ~ 163°C
Contact Type: Precision
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Tin
Insulation Height: 0.165" (4.20mm)
Row Spacing - Mating: 0.079" (2.00mm)
Number of Rows: 2
auf Bestellung 1000 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 10+ | 13.25 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details BLY 8 SMD 24 B SM Fischer Elektronik
Category: Pin headers, Description: Connector: pin strips; socket; female; PIN: 24; SMT; 2.5A; 100V; 2mm, Manufacturer series: BLY 8 SMD, Operating temperature: -40...163°C, Rated voltage: 100V, Contact material: beryllium copper, Kind of connector: female, Contact plating: gold-plated, Connector variant: pick and place; precision; turned contacts, Type of connector: pin strips, Kind of package: tube, Electrical mounting: SMT, Connector: socket, Flammability rating: UL94V-0, Spatial orientation: vertical, Plating thickness: 0.254µm, Row pitch: 2mm, Contacts pitch: 2mm, Overall length: 5.7mm, Current rating: 2.5A, Number of pins: 24, Connector pinout layout: 2x12, Anzahl je Verpackung: 10 Stücke.
