CPEX2017S-3R0MC CODACA
Hersteller: CODACADescription: THT HIGH CURRENT POWER INDUCTOR
Packaging: Tray
Tolerance: ±20%
Package / Case: Vertical, 2 PC Pin
Size / Dimension: 0.807" L x 0.689" W (20.50mm x 17.50mm)
Mounting Type: Through Hole
Shielding: Shielded
Type: Wirewound
Operating Temperature: -55°C ~ 155°C
DC Resistance (DCR): 1.38mOhm Max
Current - Saturation (Isat): 88A
Material - Core: Metal Composite
Inductance Frequency - Test: 100 kHz
Height - Seated (Max): 0.807" (20.50mm)
Inductance: 3 µH
Current Rating (Amps): 41.8 A
auf Bestellung 30 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 18.55 EUR |
| 30+ | 13.9 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details CPEX2017S-3R0MC CODACA
Description: THT HIGH CURRENT POWER INDUCTOR, Packaging: Tray, Tolerance: ±20%, Package / Case: Vertical, 2 PC Pin, Size / Dimension: 0.807" L x 0.689" W (20.50mm x 17.50mm), Mounting Type: Through Hole, Shielding: Shielded, Type: Wirewound, Operating Temperature: -55°C ~ 155°C, DC Resistance (DCR): 1.38mOhm Max, Current - Saturation (Isat): 88A, Material - Core: Metal Composite, Inductance Frequency - Test: 100 kHz, Height - Seated (Max): 0.807" (20.50mm), Inductance: 3 µH, Current Rating (Amps): 41.8 A.
