Hersteller: LOVATO ELECTRIC
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; on panel; digital,mounting; LCD; 1A,5A
Type of meter: network parameters
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
Mounting: on panel
Kind of meter: digital; mounting
Kind of display used: LCD
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; power factor; reactive electric energy; reactive power; THD
Kind of network: three-phase
AC voltage measuring range: 50...720V
Input current: 1A; 5A
Frequency measuring range: 45...65Hz
AC voltage measuring accuracy: ±0.2%
AC current measuring accuracy: ±0.2%
Accuracy class: 0,5S
True effective value measurement: True RMS
Interface: optical port; RS485
Communictions protocol: Modbus ASCII; Modbus RTU; Modbus TCP
Measuring instrument features: multilanguage menu
Related items: EXP8000
IP rating: IP54
Supply voltage: 100...440V AC; 120...250V DC
Dimensions (W x H x D): 96x96x73.5mm
Mounting hole diameter: 92x92mm
Active power measuring accuracy: ±0.5%
