EEC0252B1-000U-A99 SUNON
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; Len: 330mm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball bearing
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x2
Operating temperature: -10...70°C
Cable length: 0.33m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 7.11mm H2O
Wire size: 24AWG
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; Len: 330mm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball bearing
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x2
Operating temperature: -10...70°C
Cable length: 0.33m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 7.11mm H2O
Wire size: 24AWG
auf Bestellung 1430 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
6+ | 12.08 EUR |
10+ | 8.84 EUR |
40+ | 7.61 EUR |
240+ | 7.34 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details EEC0252B1-000U-A99 SUNON
Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; Len: 330mm, Type of fan: DC, Kind of fan: axial, Supply voltage: 24V DC, Operating voltage: 10...27.6V, Fan dimensions: 120x120x25mm, Power consumption: 5.3W, Current rating: 0.445A, Fan efficiency: 183.8m3/h, Noise level: 44.5dBA, Kind of Bearing: ball bearing, Rotational rate/speed: 3100 (±10%)rpm, Current and power consumption tolerance: ±15%, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: lead x2, Operating temperature: -10...70°C, Cable length: 0.33m, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Static pressure: 7.11mm H2O, Wire size: 24AWG, Anzahl je Verpackung: 1 Stücke.
Möglichen Substitutionen EEC0252B1-000U-A99 SUNON
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||
---|---|---|---|---|---|---|---|---|---|
Вентилятор 120x120x25, 24V (GT2-7015 24VDC) Produktcode: 114920 |
Hersteller : Global Tone |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Abmessungen, mm: 120x120x25 mm Spannung, V: 24 DC Leistung, Watt: 4,08 Вт Beschreibung: Підшипник ковзання "втулка" |
auf Bestellung 9 Stück: Lieferzeit 21-28 Tag (e)erwartet 200 Stück: 200 Stück - erwartet 15.06.2024 |
|
|||||
MEC0252V1-G99 Produktcode: 160120 |
Hersteller : Sunon |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Abmessungen, mm: 120x120x25 mm Spannung, V: 24 DC Luftvolumen, m3/Stunde: 183,83 м³/год. Leistung, Watt: 5 Вт Lärm, dB: 44,5 дБ Rotationsgeschwindigkeit, r/min: 3100 об/хв Beschreibung: Підшипник Vapo (магнітна підвіска) |
auf Bestellung 2 Stück: Lieferzeit 21-28 Tag (e) |
Verwandte Produkte EEC0252B1-000U-A99 SUNON
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|
+3 |
Befestigung für Ventilatore und Gitter, Plastikklammer FSP-1 Produktcode: 62414 |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Beschreibung: Befestigung |
verfügbar: 318 Stück
|
|
|||||||
+1 |
Befestigung für Ventilatore und Gitter, Plastikklammer FSP-2 Produktcode: 26792 |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Beschreibung: Befestigung |
verfügbar: 80 Stück
|
|
|||||||
Еврошуруп для крепления вентилятора 5x13 Produktcode: 112692 |
Verstärkungs- und Metallstangen > Schrauben Опис: Матеріал: сталь, покриття: цинк, шліц: Pozidriv Довжина, мм: 13 Матеріал: Метал Вид головки: Потайна Тип, шліц: Хрестоподібний |
auf Bestellung 1992 Stück: Lieferzeit 21-28 Tag (e) |
Weitere Produktangebote EEC0252B1-000U-A99 nach Preis ab 7.34 EUR bis 35.02 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
EEC0252B1-000U-A99 | Hersteller : SUNON |
Category: DC24V Fans Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; Len: 330mm Type of fan: DC Kind of fan: axial Supply voltage: 24V DC Operating voltage: 10...27.6V Fan dimensions: 120x120x25mm Power consumption: 5.3W Current rating: 0.445A Fan efficiency: 183.8m3/h Noise level: 44.5dBA Kind of Bearing: ball bearing Rotational rate/speed: 3100 (±10%)rpm Current and power consumption tolerance: ±15% Min. insulation resistance: 10MΩ Impeller material: thermoplastic Enclosure material: thermoplastic Insulation class: A Leads: lead x2 Operating temperature: -10...70°C Cable length: 0.33m Flammability rating: UL94V-0 Additional functions: autorestart Fan motor: brushless DC Static pressure: 7.11mm H2O Wire size: 24AWG Anzahl je Verpackung: 1 Stücke |
auf Bestellung 1430 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||||||||||
EEC0252B1-000U-A99 | Hersteller : Sunon | DC Fans Axial Fan, 120x120x25mm, 24VDC, 108.2CFM, 0.28"H2O, Ball, Wire, Auto Restart |
auf Bestellung 321 Stücke: Lieferzeit 14-28 Tag (e) |
|
|||||||||||||||||
EEC0252B1-000U-A99 | Hersteller : Sunon Fans |
Description: FAN AXIAL 120X25MM 24VDC WIRE Features: Auto Restart Packaging: Bulk Voltage - Rated: 24VDC Size / Dimension: Square - 120mm L x 120mm H Bearing Type: Ball RPM: 3100 RPM Air Flow: 108.2 CFM (3.03m³/min) Width: 25.00mm Weight: 0.346 lb (156.94 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Tubeaxial Noise: 44.5dB(A) Static Pressure: 0.280 in H2O (69.7 Pa) Part Status: Active Power (Watts): 5 W |
auf Bestellung 2320 Stücke: Lieferzeit 21-28 Tag (e) |
|
|||||||||||||||||
EEC0252B1-000U-A99 | Hersteller : Sunon | DC Fan Axial Ball Bearing 24V 108.2CFM 44.5dB 120 X 120 X 25mm High Speed |
auf Bestellung 1440 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
EEC0252B1-000U-A99 | Hersteller : Sunon | DC Fan Axial Ball Bearing 24V 108.2CFM 44.5dB 120 X 120 X 25mm High Speed |
auf Bestellung 940 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
EEC0252B1-A99 (EEC0252B1-000U-A99) Produktcode: 32718 |
Hersteller : Sunon |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Abmessungen, mm: 120x120x25 Spannung, V: 24 DC Luftvolumen, m3/Stunde: 183,8 Leistung, Watt: 5,3 Lärm, dB: 44,5 Rotationsgeschwindigkeit, r/min: 3100 Beschreibung: Lager roll-on- ZCODE: 8414 51 00 90 |
Produkt ist nicht verfügbar
|
