Produkte > DANFOSS > FC-051PK37T4E20H3XXCXXXSXXX
FC-051PK37T4E20H3XXCXXXSXXX

FC-051PK37T4E20H3XXCXXXSXXX DANFOSS


pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB3B00149A91AA0C7&compId=VLT-Micro-Drive-FC-51-INS-EN.pdf?ci_sign=5ffd2092dc32d153b1abf420cf6bc3c0a92a569c Hersteller: DANFOSS
Category: Three Phase Inverters
Description: Vector inverter; 0.37kW; 3x400VAC; 3x380÷480VAC; 0÷10V; IN: 6
Type of module: vector inverter
Max motor power: 0.37kW
Inverter output voltage: 3 x 400V AC
Input 1 properties: current analog
The programming method: keypad; PC
Electrical connection: screw terminals
Protection: anti-overload OPP; short circuit protection SCP
Mounting: for DIN rail mounting; for wall mounting
Current output: 0/4mA...20mA
Manufacturer series: VLT Micro Drive FC 51
Voltage output: 0...10V
Number of analog inputs: 1
Number of analog outputs: 2
Output frequency: 0...400Hz
Voltage between phases (for three phase system): 3 x 380...480V AC
Operating temperature: 0...50°C
Number of inputs: 6
Current rating: 1.2A
Body dimensions: 150x70x148mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 7 Stücke:

Lieferzeit 7-14 Tag (e)
Anzahl Preis
1+437.28 EUR
5+424.97 EUR
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details FC-051PK37T4E20H3XXCXXXSXXX DANFOSS

Category: Three Phase Inverters, Description: Vector inverter; 0.37kW; 3x400VAC; 3x380÷480VAC; 0÷10V; IN: 6, Type of module: vector inverter, Max motor power: 0.37kW, Inverter output voltage: 3 x 400V AC, Input 1 properties: current analog, The programming method: keypad; PC, Electrical connection: screw terminals, Protection: anti-overload OPP; short circuit protection SCP, Mounting: for DIN rail mounting; for wall mounting, Current output: 0/4mA...20mA, Manufacturer series: VLT Micro Drive FC 51, Voltage output: 0...10V, Number of analog inputs: 1, Number of analog outputs: 2, Output frequency: 0...400Hz, Voltage between phases (for three phase system): 3 x 380...480V AC, Operating temperature: 0...50°C, Number of inputs: 6, Current rating: 1.2A, Body dimensions: 150x70x148mm, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote FC-051PK37T4E20H3XXCXXXSXXX nach Preis ab 424.97 EUR bis 437.28 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
FC-051PK37T4E20H3XXCXXXSXXX FC-051PK37T4E20H3XXCXXXSXXX Hersteller : DANFOSS pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB3B00149A91AA0C7&compId=VLT-Micro-Drive-FC-51-INS-EN.pdf?ci_sign=5ffd2092dc32d153b1abf420cf6bc3c0a92a569c Category: Three Phase Inverters
Description: Vector inverter; 0.37kW; 3x400VAC; 3x380÷480VAC; 0÷10V; IN: 6
Type of module: vector inverter
Max motor power: 0.37kW
Inverter output voltage: 3 x 400V AC
Input 1 properties: current analog
The programming method: keypad; PC
Electrical connection: screw terminals
Protection: anti-overload OPP; short circuit protection SCP
Mounting: for DIN rail mounting; for wall mounting
Current output: 0/4mA...20mA
Manufacturer series: VLT Micro Drive FC 51
Voltage output: 0...10V
Number of analog inputs: 1
Number of analog outputs: 2
Output frequency: 0...400Hz
Voltage between phases (for three phase system): 3 x 380...480V AC
Operating temperature: 0...50°C
Number of inputs: 6
Current rating: 1.2A
Body dimensions: 150x70x148mm
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+437.28 EUR
5+424.97 EUR
Im Einkaufswagen  Stück im Wert von  UAH
