Produkte > DANFOSS > FC-051PK75T4E20H3XXCXXXSXXX
FC-051PK75T4E20H3XXCXXXSXXX

FC-051PK75T4E20H3XXCXXXSXXX DANFOSS

pVersion=0046&contRep=ZT&docId=005056AB90B41EDAB3B00149A91AA0C7&compId=VLT-Micro-Drive-FC-51-INS-EN.pdf?ci_sign=5ffd2092dc32d153b1abf420cf6bc3c0a92a569c Hersteller: DANFOSS
Category: Three Phase Inverters
Description: Vector inverter; 0.75kW; 3x400VAC; 3x380÷480VAC; 0÷10V; IN: 6
Type of module: vector inverter
Max motor power: 0.75kW
Inverter output voltage: 3 x 400V AC
Voltage between phases (for three phase system): 3 x 380...480V AC
Input 1 properties: current analog
Voltage output: 0...10V
Current output: 0/4mA...20mA
Electrical connection: screw terminals
Mounting: for DIN rail mounting; for wall mounting
The programming method: keypad; PC
Protection: anti-overload OPP; short circuit protection SCP
Number of inputs: 6
Number of analog inputs: 1
Operating temperature: 0...50°C
Output frequency: 0...400Hz
Current rating: 2.2A
Number of analog outputs: 2
Body dimensions: 150x70x148mm
Manufacturer series: VLT Micro Drive FC 51
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
1+518.73 EUR
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details FC-051PK75T4E20H3XXCXXXSXXX DANFOSS

Category: Three Phase Inverters, Description: Vector inverter; 0.75kW; 3x400VAC; 3x380÷480VAC; 0÷10V; IN: 6, Type of module: vector inverter, Max motor power: 0.75kW, Inverter output voltage: 3 x 400V AC, Voltage between phases (for three phase system): 3 x 380...480V AC, Input 1 properties: current analog, Voltage output: 0...10V, Current output: 0/4mA...20mA, Electrical connection: screw terminals, Mounting: for DIN rail mounting; for wall mounting, The programming method: keypad; PC, Protection: anti-overload OPP; short circuit protection SCP, Number of inputs: 6, Number of analog inputs: 1, Operating temperature: 0...50°C, Output frequency: 0...400Hz, Current rating: 2.2A, Number of analog outputs: 2, Body dimensions: 150x70x148mm, Manufacturer series: VLT Micro Drive FC 51, Anzahl je Verpackung: 1 Stücke.
