GKS-112 306 150 R 0607 INGUN
Hersteller: INGUNCategory: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1.5mm
Current rating: 5A
Mounting: push-in
Manufacturer series: GKS-112
Operating temperature: -40...80°C
Maksimum spring compression: 5.3mm
Operational spring compression: 4mm
Tip diameter: 1.5mm
Test accessories features: magnetic
Blade tip shape: serrated
Length: 37.3mm
Max. contact resistance:: 20mΩ
Spring compression force: 0.6N
Contact plating: rhodium plated
Type of test accessories: test needle
Contact material: CuBe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details GKS-112 306 150 R 0607 INGUN
Category: Contact Probes, Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1.5mm, Current rating: 5A, Mounting: push-in, Manufacturer series: GKS-112, Operating temperature: -40...80°C, Maksimum spring compression: 5.3mm, Operational spring compression: 4mm, Tip diameter: 1.5mm, Test accessories features: magnetic, Blade tip shape: serrated, Length: 37.3mm, Max. contact resistance:: 20mΩ, Spring compression force: 0.6N, Contact plating: rhodium plated, Type of test accessories: test needle, Contact material: CuBe, Anzahl je Verpackung: 1 Stücke.
