GKS-112 306 150 R 0802 MC

GKS-112 306 150 R 0802 MC INGUN


pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A09FE8395540D6&compId=GKS-112-2870.pdf?ci_sign=36ccd7978fc7e092229845d234063fe67893c67c Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1.5mm
Mounting: screw-in
Operating temperature: -100...200°C
Test accessories features: magnetic
Contact plating: rhodium plated
Blade tip shape: serrated
Type of test accessories: test needle
Tip diameter: 1.5mm
Current rating: 5A
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Max. contact resistance:: 20mΩ
Length: 35.8mm
Spring compression force: 0.8N
Manufacturer series: GKS-112
Contact material: CuBe
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar

Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details GKS-112 306 150 R 0802 MC INGUN

Category: Contact Probes, Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1.5mm, Mounting: screw-in, Operating temperature: -100...200°C, Test accessories features: magnetic, Contact plating: rhodium plated, Blade tip shape: serrated, Type of test accessories: test needle, Tip diameter: 1.5mm, Current rating: 5A, Operational spring compression: 4mm, Maksimum spring compression: 5.3mm, Max. contact resistance:: 20mΩ, Length: 35.8mm, Spring compression force: 0.8N, Manufacturer series: GKS-112, Contact material: CuBe, Anzahl je Verpackung: 1 Stücke.
