GQ22-L-11E/J/Y/24V/S ONPOW
Hersteller: ONPOWCategory: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: yellow
Illumination voltage: 24V
Test voltage: 1.5kV
Leads: for soldering
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø22mm
Body material: stainless steel
Manufacturer series: GQ22-L
Operating temperature: -25...55°C
Related items: M12-22F
Dimensions: Ø25x35.5mm
Mechanical impact resistance: IK09
Anzahl je Verpackung: 1 Stücke
auf Bestellung 6 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 6+ | 11.91 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details GQ22-L-11E/J/Y/24V/S ONPOW
Category: Push Button Switches, Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65, Type of switch: vandal resistant, Number of positions: 2, Stable positions number: 1, Contacts configuration: SPDT, AC contacts rating @R: 3A / 220V AC, DC contacts rating @R: 5A / 24V DC, IP rating: IP65, Switching method: ON-(ON), Illumination: LED; ring, Backlight colour: yellow, Illumination voltage: 24V, Test voltage: 1.5kV, Leads: for soldering, Electrical life: 50000 cycles, Max. contact resistance:: 50mΩ, Mechanical durability: 1000000 cycles, Button shape: flat; round, Mounting hole diameter: Ø22mm, Body material: stainless steel, Manufacturer series: GQ22-L, Operating temperature: -25...55°C, Related items: M12-22F, Dimensions: Ø25x35.5mm, Mechanical impact resistance: IK09, Anzahl je Verpackung: 1 Stücke.
