GQ22-L-11ZE/J/W/24V/S ONPOW
Hersteller: ONPOWCategory: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 2
Contacts configuration: SPDT
AC contacts rating @R: 3A / 220V AC
DC contacts rating @R: 5A / 24V DC
IP rating: IP65
Switching method: ON-ON
Illumination: LED; ring
Test voltage: 1.5kV
Leads: for soldering
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø22mm
Body material: stainless steel
Related items: M12-22F
Operating temperature: -25...55°C
Backlight colour: white
Mechanical impact resistance: IK09
Dimensions: Ø25x41.5mm
Illumination voltage: 24V
Manufacturer series: GQ22-L
Anzahl je Verpackung: 1 Stücke
auf Bestellung 5 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 5+ | 14.3 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details GQ22-L-11ZE/J/W/24V/S ONPOW
Category: Push Button Switches, Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65, Type of switch: vandal resistant, Number of positions: 2, Stable positions number: 2, Contacts configuration: SPDT, AC contacts rating @R: 3A / 220V AC, DC contacts rating @R: 5A / 24V DC, IP rating: IP65, Switching method: ON-ON, Illumination: LED; ring, Test voltage: 1.5kV, Leads: for soldering, Electrical life: 50000 cycles, Max. contact resistance:: 50mΩ, Mechanical durability: 1000000 cycles, Button shape: flat; round, Mounting hole diameter: Ø22mm, Body material: stainless steel, Related items: M12-22F, Operating temperature: -25...55°C, Backlight colour: white, Mechanical impact resistance: IK09, Dimensions: Ø25x41.5mm, Illumination voltage: 24V, Manufacturer series: GQ22-L, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote GQ22-L-11ZE/J/W/24V/S nach Preis ab 14.3 EUR bis 14.3 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||
|---|---|---|---|---|---|---|---|---|---|
|
|
GQ22-L-11ZE/J/W/24V/S | Hersteller : ONPOW |
Category: Push Button Switches Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/220VAC; 5A/24VDC; IP65 Type of switch: vandal resistant Number of positions: 2 Stable positions number: 2 Contacts configuration: SPDT AC contacts rating @R: 3A / 220V AC DC contacts rating @R: 5A / 24V DC IP rating: IP65 Switching method: ON-ON Illumination: LED; ring Test voltage: 1.5kV Leads: for soldering Electrical life: 50000 cycles Max. contact resistance:: 50mΩ Mechanical durability: 1000000 cycles Button shape: flat; round Mounting hole diameter: Ø22mm Body material: stainless steel Related items: M12-22F Operating temperature: -25...55°C Backlight colour: white Mechanical impact resistance: IK09 Dimensions: Ø25x41.5mm Illumination voltage: 24V Manufacturer series: GQ22-L |
auf Bestellung 5 Stücke: Lieferzeit 14-21 Tag (e) |
|
