H-OLD P.34 25MM 66M ŻÓŁTA

H-OLD P.34 25MM 66M ŻÓŁTA

pVersion=0046&contRep=ZT&docId=005056AB90B41EDAAFEC363E7F04C0C7&compId=P.34.pdf?ci_sign=8c4d254d5a489189acac5ab35b28e26be14ef421 Hersteller: H-OLD
Category: Insulating tapes
Description: Tape: electrical insulating; W: 25mm; L: 66m; Thk: 0.06mm; yellow
Operating temperature: 130°C; max. 180°C
Width: 25mm
Length: 66m
Resistance to: electrical insulating varnishes; most of solvents
Thickness: 60µm
Dielectric strength: 4.5kV
Type of tape: electrical insulating
Kind of adhesive: acrylic
Adhesion to steel: 2.5N/cm
Tape features: good insulating properties
Tape application: coils; motor windings; transformers
Tensile strength: 40N/cm
Elongation at rupture: 80%
Tape material: polyester
Colour: yellow
auf Bestellung 4 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
4+17.88 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details H-OLD P.34 25MM 66M ŻÓŁTA H-OLD

Category: Insulating tapes, Description: Tape: electrical insulating; W: 25mm; L: 66m; Thk: 0.06mm; yellow, Operating temperature: 130°C; max. 180°C, Width: 25mm, Length: 66m, Resistance to: electrical insulating varnishes; most of solvents, Thickness: 60µm, Dielectric strength: 4.5kV, Type of tape: electrical insulating, Kind of adhesive: acrylic, Adhesion to steel: 2.5N/cm, Tape features: good insulating properties, Tape application: coils; motor windings; transformers, Tensile strength: 40N/cm, Elongation at rupture: 80%, Tape material: polyester, Colour: yellow.
