HA40101V4-000U-999 Sunon
Hersteller: Sunon
DC Fans DC Fan, 40x10mm, 12VDC, 5.3CFM, 0.8W, 18.2dBA, 4500RPM, 0.06inch H2O, Vapo
Produktrezensionen
Produktbewertung abgeben
Technische Details HA40101V4-000U-999 Sunon
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 18.2dBA; Vapo; 1.52mmH2O, Type of fan: DC, Kind of fan: axial, Supply voltage: 12V DC, Operating voltage: 4.5...13.8V DC, Fan dimensions: 40x40x10mm, Power consumption: 0.8W, Current rating: 65mA, Fan efficiency: 9m3/h, Noise level: 18.2dBA, Kind of Bearing: Vapo, Rotational rate/speed: 4500 (±15%)rpm, Min. insulation resistance: 500MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Leads: leads x2, Lead length: 0.3m, Operating temperature: -10...70°C, Flammability rating: UL94V-0, Fan motor: brushless DC, Static pressure: 1.52mm H2O, Wire size: 28AWG, Current and power consumption tolerance: ±15%, Insulation class: E.
Weitere Produktangebote HA40101V4-000U-999 nach Preis ab 2.56 EUR bis 2.56 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
||
|---|---|---|---|---|---|---|---|
 |
HA40101V4 Produktcode: 67221
zu Favoriten hinzufügen
Lieblingsprodukt
|
Sunon |
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör Abmessungen, mm: 40x40x10 Spannung, V: 12 DC Luftvolumen, m3/Stunde: 9 Leistung, Watt: 0,8 Lärm, dB: 18,2 Rotationsgeschwindigkeit, r/min: 4500 Beschreibung: Lager Vapo (Magnetschwebe) |
Produkt ist nicht verfügbar
|
|
||
 |
HA40101V4-000U-999 | Sunon Fans |
Description: FAN AXIAL 40X10MM 12VDC WIRE Packaging: Bulk Voltage - Rated: 12VDC Size / Dimension: Square - 40mm L x 40mm H Bearing Type: Vapo-Bearing™ RPM: 4500 RPM Air Flow: 5.3 CFM (0.148m³/min) Width: 10.00mm Weight: 0.032 lb (14.51 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Tubeaxial Noise: 18.2dB(A) Static Pressure: 0.060 in H2O (14.9 Pa) Part Status: Obsolete Power (Watts): 800 mW |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | ||
 |
HA40101V4-000U-999 | SUNON |
Category: DC12V Fans Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 18.2dBA; Vapo; 1.52mmH2O Type of fan: DC Kind of fan: axial Supply voltage: 12V DC Operating voltage: 4.5...13.8V DC Fan dimensions: 40x40x10mm Power consumption: 0.8W Current rating: 65mA Fan efficiency: 9m3/h Noise level: 18.2dBA Kind of Bearing: Vapo Rotational rate/speed: 4500 (±15%)rpm Min. insulation resistance: 500MΩ Impeller material: thermoplastic Enclosure material: thermoplastic Leads: leads x2 Lead length: 0.3m Operating temperature: -10...70°C Flammability rating: UL94V-0 Fan motor: brushless DC Static pressure: 1.52mm H2O Wire size: 28AWG Current and power consumption tolerance: ±15% Insulation class: E |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH |
| HA40101V4 Produktcode: 67221
zu Favoriten hinzufügen
Lieblingsprodukt
|
|
Hersteller: Sunon
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör
Abmessungen, mm: 40x40x10
Spannung, V: 12 DC
Luftvolumen, m3/Stunde: 9
Leistung, Watt: 0,8
Lärm, dB: 18,2
Rotationsgeschwindigkeit, r/min: 4500
Beschreibung: Lager Vapo (Magnetschwebe)
Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör
Abmessungen, mm: 40x40x10
Spannung, V: 12 DC
Luftvolumen, m3/Stunde: 9
Leistung, Watt: 0,8
Lärm, dB: 18,2
Rotationsgeschwindigkeit, r/min: 4500
Beschreibung: Lager Vapo (Magnetschwebe)
Produkt ist nicht verfügbar
| Anzahl | Preis |
|---|---|
| 1+ | 2.56 EUR |
| HA40101V4-000U-999 |
|
Hersteller: Sunon Fans
Description: FAN AXIAL 40X10MM 12VDC WIRE
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 4500 RPM
Air Flow: 5.3 CFM (0.148m³/min)
Width: 10.00mm
Weight: 0.032 lb (14.51 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Tubeaxial
Noise: 18.2dB(A)
Static Pressure: 0.060 in H2O (14.9 Pa)
Part Status: Obsolete
Power (Watts): 800 mW
Description: FAN AXIAL 40X10MM 12VDC WIRE
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 4500 RPM
Air Flow: 5.3 CFM (0.148m³/min)
Width: 10.00mm
Weight: 0.032 lb (14.51 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Tubeaxial
Noise: 18.2dB(A)
Static Pressure: 0.060 in H2O (14.9 Pa)
Part Status: Obsolete
Power (Watts): 800 mW
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| HA40101V4-000U-999 |
|
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 18.2dBA; Vapo; 1.52mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 0.8W
Current rating: 65mA
Fan efficiency: 9m3/h
Noise level: 18.2dBA
Kind of Bearing: Vapo
Rotational rate/speed: 4500 (±15%)rpm
Min. insulation resistance: 500MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.3m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Static pressure: 1.52mm H2O
Wire size: 28AWG
Current and power consumption tolerance: ±15%
Insulation class: E
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 18.2dBA; Vapo; 1.52mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 0.8W
Current rating: 65mA
Fan efficiency: 9m3/h
Noise level: 18.2dBA
Kind of Bearing: Vapo
Rotational rate/speed: 4500 (±15%)rpm
Min. insulation resistance: 500MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.3m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Static pressure: 1.52mm H2O
Wire size: 28AWG
Current and power consumption tolerance: ±15%
Insulation class: E
