LIYCY4X0.25 Helukabel

Hersteller: LAPP
Category: Multicore Cables - Shielded
Description: Wire; LiYCY; UNITRONIC® LiYCY; 4x0.25mm2; PVC; grey; 500V; 100m
Cable external diameter: 5mm
Manufacturer series: UNITRONIC® LiYCY
Trade name: multi core cable
Operating temperature: -40...80°C
Number of cores: 4
Earth core: none
Cable application: assembly line tools; control for machines; machine terminals; production line tools
Type of wire: data transmission
Flexibility class: 5
Cable structure: 4x0.25mm²
Wire insulation material: PVC
Insulation colour: grey
Kind of material: no flame propagation
Shield structure: shielded; tinned copper braid
CPR standard: E_ca
Conform to the norm: IEC 60332-1-2
Core marking: colours without colour repetition
Kind of core: Cu
Package contents: 100m
Resistance to: moisture
Rated voltage: 0.5kV
Core structure: stranded
Cable features: low-capacitance
Kind of cable: LiYCY
Core section: 0.25mm²

Hersteller: HELU
Category: Multicore Cables - Shielded
Description: Wire; LiY-CY; TRONIC CY; 4x0.25mm2; shielded,tinned copper braid
Kind of cable: LiY-CY
Cable structure: 4x0.25mm²
Wire insulation material: PVC
Insulation colour: grey
Number of cores: 4
Core section: 0.25mm²
Rated voltage: 0.5kV
Manufacturer series: TRONIC CY
Minimal wire bend radius: 10xØ
Earth core: none
Operating temperature: -40...80°C
Cable application: assembly line tools; control for machines; machine terminals; production line tools
Type of wire: data transmission
Flexibility class: 5
Kind of material: no flame propagation
Shield structure: shielded; tinned copper braid
CPR standard: E_ca
Core marking: colours without colour repetition
Kind of core: Cu
Resistance to: most of chemical compounds; most of oils
Cable external diameter: 4.8mm
Ground: tinned copper strand Ø0,4mm
Core structure: stranded
