MTX 3290 METRIX

Category: Portable digital multimeters, Description: Multimeter calibrator; LCD; (6000); Bargraph: 61segm; 5x/s; IP67, Type of meter: multimeter calibrator, Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature, Kind of display used: LCD, Display parameters: (6000), DC voltage measuring range: 600mV; 6V; 60V; 600V, AC voltage measuring range: 600mV; 6V; 60V; 600V, DC current measuring range: 6mA; 60mA; 600mA; 6A; 10A, DC current measuring accuracy: ±(1.2% + 2 digit), AC current measuring range: 6mA; 60mA; 600mA; 6A; 10A, True effective value measurement: True RMS, Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ, Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF, Capacitance measuring accuracy: ±(1.5%+ 5 digit), Frequency measuring range: 60Hz; 600Hz; 6kHz; 60kHz; 600kHz, Frequency measuring accuracy: ±(0.1%+1 digit), Temperature measuring range: -200...800°C, Temperature measurement accuracy: ±(0.07% + 1°C), Resistance measuring accuracy: ±(0.5%+2 digit), Test: diodes, Continuity test: acoustic indication, IP rating: IP67, Power supply: rechargeable battery Ni-MH AA 1,2V x4, Standard equipment: test leads; test probes, Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010, Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12, Dimensions (W x H x D): 90x196x47.1mm, Producer guarantee (months): 36, Kind of temperature sensor: Pt100; Pt1000, Measuring instrument features: auto and manual ranging; automatic power-off; HOLD function; low input impedance function (LoZ); MIN/MAX/DIF/AVG function; PEAK function; selection of AC or AC+DC measurement, Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4, Bargraph: 61 segm., Manufacturer series: ASYC IV, Sampling: 5x/s, AC current measuring accuracy: ±(1.5% + 3 digit), Anzahl je Verpackung: 1 Stücke.
