Produkte > PIZZATO ELETTRICA > NF B112KA-DN2
NF B112KA-DN2

NF B112KA-DN2 PIZZATO ELETTRICA

PIZZATO-NA-EN.pdf PIZZATO-NA-DE.pdf
Hersteller: PIZZATO ELETTRICA
Category: Limit Switches
Description: Limit switch; lever R 35mm, plastic roller Ø18mm; NO + NC; 10A
Type of sensor: limit switch
Kind of actuator: lever R 35mm, plastic roller Ø18mm
Output configuration: NO + NC
Contact current max.: 10A
Switched voltage: max. 250V AC; max. 250V DC
Connection: cables
IP rating: IP67
Body dimensions: 39x30x16mm
Number of mounting holes: 2
Operating temperature: -25...80°C
Body material: plastic
AC contacts rating @R: 4A / 250V AC
DC contacts rating @R: 0.3A / 250V DC
Switching frequency max: 1Hz
Mounting holes pitch: 20mm
Switches features: snap action contacts
Lead length: 2m
auf Bestellung 39 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details NF B112KA-DN2 PIZZATO ELETTRICA

Category: Limit Switches, Description: Limit switch; lever R 35mm, plastic roller Ø18mm; NO + NC; 10A, Type of sensor: limit switch, Kind of actuator: lever R 35mm, plastic roller Ø18mm, Output configuration: NO + NC, Contact current max.: 10A, Switched voltage: max. 250V AC; max. 250V DC, Connection: cables, IP rating: IP67, Body dimensions: 39x30x16mm, Number of mounting holes: 2, Operating temperature: -25...80°C, Body material: plastic, AC contacts rating @R: 4A / 250V AC, DC contacts rating @R: 0.3A / 250V DC, Switching frequency max: 1Hz, Mounting holes pitch: 20mm, Switches features: snap action contacts, Lead length: 2m.
