ONPOW7116B1-11/2/41RGB/12V/A

Category: Toggle Switches, Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 5A/250VAC; -40÷85°C; IP67; brass, Type of switch: toggle, Number of positions: 2, Stable positions number: 2, Contacts configuration: SPDT, Switching method: ON-ON, AC contacts rating @R: 5A / 250V AC, Leads: connectors; for soldering, Operating temperature: -40...85°C, Kind of toggle: with flat head, Mounting hole diameter: Ø16mm, Max. contact resistance:: 50mΩ, Min. insulation resistance: 0.1GΩ, IP rating: IP67, Mechanical durability: 500000 cycles, Panel thickness: max. 8mm, Mounting: on panel, Body material: brass, Body colour: black, Dimensions: Ø18x46.8mm, Illumination: LED, Illumination voltage: 12V DC, Backlight colour: red/green/blue; RGB, Lever length: 14.6mm, Indexed positions: 24°, Leads dimensions: 2.8x0.5mm.
