PHU 80-340D GW INSTEK
Hersteller: GW INSTEK
Category: One Channel Power Supplies
Description: Laboratory power supply: programmable; DC,single-channel; 340A
Kind of display used: LCD TFT 5"
Dimensions: 442x130x675mm
Measuring instrument features: adjustable fall time; adjustable voltage and current slew rates; APC (Adaptive Parallel Connection); automatic CV/CC crossover operation; panel locking function; soft start/stop; The AWS (Advanced Web Server)
Standard equipment: adapter AC; adapter DC; mounting holder x2; user's manual
Interface: analog; CAN (option); GPIB (option); LAN; RS232 (option); RS485 (option); USB
Manufacturer series: PHU
Optional equipment: GPW-021; GPW-022; GTL-133; GTL-218; GTL-219; GTL-220; GTL-221; GTL-222; GTL-223; PHU-PC01; PHU-PC02; PHU-PC03; PHU-PC04; PHU-PC05; PHU-PC06; PHU-PC07; PHU-PC08; PHU-PC09
Type of laboratory power supply: programmable
Mounting: rack 19"
Output voltage: 0...80V DC
Number of channels: 1
Output current: 340A
Output power: 10kW
Kind of power supply: DC; single-channel
Category: One Channel Power Supplies
Description: Laboratory power supply: programmable; DC,single-channel; 340A
Kind of display used: LCD TFT 5"
Dimensions: 442x130x675mm
Measuring instrument features: adjustable fall time; adjustable voltage and current slew rates; APC (Adaptive Parallel Connection); automatic CV/CC crossover operation; panel locking function; soft start/stop; The AWS (Advanced Web Server)
Standard equipment: adapter AC; adapter DC; mounting holder x2; user's manual
Interface: analog; CAN (option); GPIB (option); LAN; RS232 (option); RS485 (option); USB
Manufacturer series: PHU
Optional equipment: GPW-021; GPW-022; GTL-133; GTL-218; GTL-219; GTL-220; GTL-221; GTL-222; GTL-223; PHU-PC01; PHU-PC02; PHU-PC03; PHU-PC04; PHU-PC05; PHU-PC06; PHU-PC07; PHU-PC08; PHU-PC09
Type of laboratory power supply: programmable
Mounting: rack 19"
Output voltage: 0...80V DC
Number of channels: 1
Output current: 340A
Output power: 10kW
Kind of power supply: DC; single-channel
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details PHU 80-340D GW INSTEK
Category: One Channel Power Supplies, Description: Laboratory power supply: programmable; DC,single-channel; 340A, Kind of display used: LCD TFT 5", Dimensions: 442x130x675mm, Measuring instrument features: adjustable fall time; adjustable voltage and current slew rates; APC (Adaptive Parallel Connection); automatic CV/CC crossover operation; panel locking function; soft start/stop; The AWS (Advanced Web Server), Standard equipment: adapter AC; adapter DC; mounting holder x2; user's manual, Interface: analog; CAN (option); GPIB (option); LAN; RS232 (option); RS485 (option); USB, Manufacturer series: PHU, Optional equipment: GPW-021; GPW-022; GTL-133; GTL-218; GTL-219; GTL-220; GTL-221; GTL-222; GTL-223; PHU-PC01; PHU-PC02; PHU-PC03; PHU-PC04; PHU-PC05; PHU-PC06; PHU-PC07; PHU-PC08; PHU-PC09, Type of laboratory power supply: programmable, Mounting: rack 19", Output voltage: 0...80V DC, Number of channels: 1, Output current: 340A, Output power: 10kW, Kind of power supply: DC; single-channel.
